Facilities & equipment

Water Bath for incubation and inactivation of cultures. With internal circulating system Cover frame (more) and lid have mirror finish. Lift-up, insulating lid with inner camber, no dripping back of condensate into the tubes. Corrosion-resistant outer housing, made of electrolytically galvanised sheet steel, powder-coated. Drain dock at the back. The circulation system of the water bath ensures optimum temperature uniformity throughout the whole bath. An electric motor with rotary magnet is flanged to the bath floor. Its torque is transmitted to a PTFE coated stirring magnet in the bath. The stirring magnet forces the water into the centre of the bath and then evenly back again. Max. temp: 100°C Capacity: 14L Dimensions (w x d x h): 500mm x 440mm x 325mm Interior dimensions (w x d x h): 400mm x 245mm x 145mm Weight: 14.6kg 230V / 50-60Hz / 1500W

The peristaltic pump of the Cole Parmer type Masterflex L/S is ideal for pumping corrosive, abrasive (more) and viscous liquids without damaging the pump. The Cole Parmer Masterflex L/S can also be used in the pharmaceutical and biopharmaceutical industry. This peristaltic pump can be used in combination with the L/S 13, L/S 14, L/S 16, L/S 25, L/S 17 and L/S 18 tubing. Speed: 10 – 600 rpm Pump head type: 2x 7518-00 Tube range: L/S 13: 0.6 – 36 mL/min L/S 14: 2.0 – 130 mL/min L/S 16: 8.0 – 480 mL/min L/S 25: 20 – 1000 mL/min L/S 17: 30 – 1700 mL/min L/S 18: 40 – 2300 mL/min

SONOPULS ultrasonic homogenisers generate high-performance ultrasound with high intensities and ultr (more)asonic amplitudes, which are transferred into liquid media using working tools called probes. They are used in laboratories, clinics, and in industrial research, and they perform diverse tasks during sample preparation in Quality Assurance, scientific experiments, analyses, and in pilot or short-series manufacture. Application examples: Cell disruption for paternity tests Cell disruption (extraction of microorganisms, tissue cells) Homogenising of liquids Emulsifying hard-to-mix liquids Dispersion of agglomerates Acceleration of chemical reactions Degassing of fluids Sample preparation in environmental analytics (waste water tests, soil samples) SONOPULS ultrasonic homogenisers are also used for in-vitro diagnostic lab procedures, toprocure information from the handling of organic materials with ultrasound. Therefore, they areclassified and treated in accordance with the Directive 98/79/EC on in-vitro diagnostic medical devices. Ultrasound frequency: 20 kHz ± 500 Hz Frequency control: Automatic Timer setting: 0:00:01 to 99:59 (h:mm:ss) or continuous Ultrasound operating mode: Pulsating or continuous Amplitude setting: 10 to 100% in 1% steps Generator dimensions (DxWxH): 257 x 180 x 115 mm Probe dimensions (ØxL): 70 x120 mm Probe tip: MS 73 Probe tip (Ø): 6 mm Sonification volume: 2 to 50 mL Amplitude: 245 µm Weight: 3.7 kg

Weighing stone with Frame 500x400x760

Recirculation air volume: 725 m3/h Exhaust air volume: 383 m3/h Total air volume: 1348 m3/h In flow: (more) 0.45 m/s Standard lighting : 2x 36 W Internal dimensions (WxDxH): 1190 x 600 x 655 mm Dimensions (WxDxH): 1280 x 790 x 2180 mm Weight: 240 kg Equipped with: Adjustable ellectric base stand (225 mm range) UV light

Partly functional No longer serviceable Mainly for parts only

Getinge 46-series washer-disinfectors combine hygienic and ergonomic solutions with well-proven tech (more)nology for maximum user safety. Getinge 46-series Washer-Disinfectors offer a large chamber size with a minimal external footprint. Thanks to the built-in heat exchanger, the 46-series dries items effectively on both the inside and outside. Drying time and temperature can be preset for each program via the control panel. The display uses plain language to explain what’s happening in every stage of the washing and disinfecting processes. Simply select one of the six preset programs and press the start button. Wash levels (up to): 4 pcs Chamber volume: 201 L Internal dimensions (WxDxH): 550 x 620 x 590 mm Dimensions (WxDxH): 650 x 690 x 1860 mm

Low profile laboratory orbital shaker with large mounting surface and load capacity of up to 15 kg.  (more)Infinitely variable speed control from 0 – 300 rpm Digital display Orbital diameter 30 mm Ideal for vessels with a volume of more than 250 ml, e.g. round flasks, Erlenmeyer flasks, culture flasks and bottles Ideal for biological and microbiological growth tests and for production of stock solutions Continuous operation (endless) even under extreme loads Timer function Type of movement: orbital Shaking stroke: 30 mm Permissible shaking weight (incl. attachment): 15 kg Permissible ON time: 100 % Speed range: 0 – 300 rpm Speed display: 7 segment LED Timer: yes Timer display: scale Time setting range: 1 – 55 min Operating mode: timer and continuous operation Dimensions (WxHxD): 505 x 120 x 585 mm Weight: 26 kg Equipped with a AS 501.1 Universal attachment

Potteau Plinth cabinet Double door L.Gray 1500x500x1085

Potteau Plinth cabinet L. Gray 900x500x650

Vinitex Door cabinet high DD wheels White 900

Isotope sensitivity (1 s-1 per Bq x cm-2) 14C: 0.2 60Co: 0.07 99mTc: 0.3 125I: 0.3 131I: 0.04  (more)241Am: 0.3 Isotope sensitivity (1 s-1 per 10-4 µCi/cm2) 14C: 005 60Co: 0.02 99mTc: 0.08 125I: 0.08 131I: 0.01 241Am: 0.08 Threshold setting 3.7 Bq x cm-2 (10-4 µCi/cm2) 14C: 20 s-1 60Co: 50 s-1 99mTc: 13 s-1 125I: 13 s-1 131I: 100 s-1 241Am: 13 s-1

Technopolymer casing resists chemicals White surface for visualization of particles and color change (more)s Speed regulation up to 1100 rpm Accepts up to 5 liter flasks Remains cold, even after days of continuous use Ideal for microtitration, BOD, microbiology and biochemistry

Stirring speed: up to 2200 rpm Suitable for volumes up to 5 liters (H2O) Plate diameter: 104 mm Idea (more)lly suited for titrations Dimensions (WxHxD): 126 x 80 x 140 mm Weight: 1.2 kg

Can be operated with one hand Internal Buffer Detection Automatic/Manual Temperature Compensation In (more) Autolock mode, stable readings are held on the display mV – accuracy: ±0.1% ±1 digit mV – resolution: 1 pH – calibration: 1, 2 or 3 points pH – Accuracy: ±0.1% ±2 Digit Temperature Accuracy (°C): ±0.3 ±2 digits Temperature resolution (°C): 0.1 Memory – Logging Function: No

Temperature range: 3°C to 16°C Dimensions (WxDxH): 597 x 615 x 820 mm Internal dimensions (WxDxH): 4 (more)40 x 435 x 670 mm Capacity: 130 litres

Speed range: 60 – 1600 rpm Maximum stirring capacity (H2O): 2500 ml Speed stability: ±2% Plate mater (more)ial: Ceramic Plate dimensions: 180 x 180 mm Dimensions (WxDxH): 250 x 375 x 108 mm Weight: 4.2 kg

Dimensions (HxWxD): 1920 x 900 x 360 mm

Measurement of viable cell volume. Real-time monitoring of morphological and physiology of cells. Re (more)solution : 0.02 g/l dry weight for yeast, 104 cells/ml for animal cells Conductivity range : 0.5 – 100 mS/cm Concentration range : 0 – 200 g/l dry weight for yeast, 104 – 109 cells/ml for animal cells, 0 – 200 g/L bacteria (5 – 200 g/L for highly aerated media)

The sensor allows the measurement of size changes in original formulations of suspensions and emulsi (more)ons under inline conditions. Dynamic measuring ranges: < 125 µm Temperature ranges: 5°C to 85°C Pressure ranges: up to 6 bar Diameter of the sensor: 18 mm Sensor length: 100 mm Scanner speed: 1 m/s

QIAcube HT enables automated mid- to high-throughput nucleic acid purification in 96-well format usi (more)ng silica membrane technology. A variety of QIAcube HT Purification Kits lets users quickly and easily purify DNA, RNA and miRNA from almost any type of sample – including cells, tissues and stool samples, as well as from bacteria and viruses in animal samples. Automated protocols and dedicated accessories and consumables increase reliability and convenience and save valuable time. The system provides the same high-quality results as other trusted QIAGEN purification technologies. Reliable DNA, RNA and miRNA extraction from virtually any sample type Mid- to high-throughput solution with dedicated purification kits saves costs and time User-friendly software allows for easy data management and documentation Innovative design features increase safety and minimize cross-contamination Convenient, flexible and easy-to-use instrument with small footprint Accessories: Vacuum Control Station Precision: 20 – 200 µl, less than 4% coefficient of variation HEPA filter: Preinstalled dual-cartridge HEPA filter system provides positive pressure clean air within the closed hood. Communications: RS232 and USB Throughput: 24 – 96 samples in increments of 8 samples UV lamp: Preinstalled UV lamp for worktable decontamination Tip disposal: All used tips ejected externally; no waste accumulation on the worktable Software: Supplied with unlimited user license with free upgrades by web download Pipetting system: 8 pipetting channels, pipetting volume (20-200 µl) Notebook (supplied): QIAcube HT comes with a notebook computer for added flexibility. Table capacity: 4 x SBS positions (127.76 x 85.48 mm), compatible with 96-well plates or tip racks 1 custom adapter for a reagent trough plate compatible to accept reagent troughs vacuum chamber with chambers for waste and elution Dimensions (WxHxD): Instrument 540 x 450 x 630 mm, vacuum control station 495 x 520 x 400 mm Weight: QIAcube HT instrument 41 kg, vacuum control station 19 kg

Seat height: 460 – 600 mm

Maximum capacity: 4 x 100 ml Maximum density: 1.2 kg/dm3 Maximum speed: 6000 RPM Maximum force: 4186 (more) RCF Maximum kinetic energy: 3000 Nm Noise level (dependent on rotor): ≤ 65 dB(A) Dimensions (WxDxH): 368 x 437 x 261 mm Weight: 15.6 kg No rotor included

Temperature range: 12°C to 2°C Gross capacity: 425 liters Usable net content: 303 litres Material: s (more)tainless steel Dimensions (WxDxH): 600 x 731 x 2000 mm Weight: 114 kg

Equipped with a removable shaking platform. Maximum temperature: 100°C Dimensions (WxDxH): 580 x 440 (more) x 450 mm Internal dimensions (WxDxH): 350 x 290 x 230 mm Shake range: 35 – 160 RPM

miVac is a range of centrifugal concentrators capable of removing water and organic solvents from a  (more)variety of sample formats including tubes, microplates and vials. miVac systems are suitable for use with a wide range of solvents, from volatile organic types through to water and many medium boiling point solvents. The system is very simple to use, allowing samples to be safely concentrated or taken to complete dryness. The large clear display enables easy monitoring of time and temperature. The intuitive controls allow inexperienced users to get first-class results, while allowing more sophisticated programming for experienced workers. The simple, robust design ensures years of reliable service even when used intensively, such as in teaching or multi-user laboratories. To improve performance there are built-in special modes for working with water and alcohols. Performance is further enhanced through the use of the miVac SpeedTrap refrigerated condenser. Simplified operation with optimized programs for water, alcohol and other solvents Precise temperature control with timer and digital display up to a max of 60°C Various heating functions (preheating and heating of the interior) Plastic coated aluminum chamber and acrylic glass cover for better chemical resistance The rotors are easily interchangeable Compact systems are quiet when in use and up to 40% faster than comparable machines
