Fast and Stable Measurement It only takes a second for the balance to display the final measurement  (more)result. Weighing Heavy Loads with High Accuracy On the large weighing pan of a PM balance, you can weigh a load of 120 kg with a readability of 0.2 g and second-to-none repeatability. Minimum Eccentricity Error Over the Entire Range PM balances can be used to determine the mass of irregularly shaped components with a centre of gravity that is significantly shifted from the weighing pan axis. Parameter Stability Over Time and After Transport The mechanical design is resistant and robust, allowing you to maintain the correct metrological parameters after transport and despite long and intensive use. Weighing Pan Dimensions Adapted to the Accuracy of the Balance Weigh with the highest readability of 0.01 g on the 200 x 185 mm weighing pan and with a readability of 0.2 g on the 500 x 400 mm weighing pan. 21 CFR Part 11 Do you work in the pharmaceutical industry? Do you need a digital signature? We are offering the laboratory balance which as a standalone fully meets the requirements of 21 CFR Part 11/ EU GMP Annex 11. - Full data security - Electronic signatures - Validations - Electronic records - Audit trails New, lmproved The new, taller and larger MONOBLOCK® enables the best repeatability and speed in its class of weighing platforms. 5Y Terminal With Terminal 5Y you get a 10-inch display, Digital Weighing Auditor, multi-step user verification, ambient light alerts, hotspot, RFID*, live note voice and text notes, voice commands for the balance and handy measurement history within the handy library widgets Modbus TCP/IP is one of the most popular communication protocols in industrial automation. Implementing it in the 5Y balances and CY10 scales makes the devices of this series friendly to automation integrators. A balance or scale in a Modbus system is a slave device and performs tasks specified by the master device which is most often a PLC. Protocol Modbus TCP/IP in the 5Y balances and C10 scales enables, among other things, the realization of mass readout, zeroing and tare functions of the device, as well as tare settings and MIN and MAX thresholds. Under-pan weighing Weighing instruments purchased after 15th February 2023 will allow under-pan weighing at any time after the purchase. All you need to do is just to order a dedicated hook. THBR 2.0 System Cooperation with THBR 2.0 System for ambient conditions monitoring. * RFID ISO/IEC 14443 Type A, 13,56 MHz

Fast and Stable Measurement It only takes a second for the balance to display the final measurement  (more)result. Weighing Heavy Loads with High Accuracy On the large weighing pan of a PM balance, you can weigh a load of 120 kg with a readability of 0.2 g and second-to-none repeatability. Minimum Eccentricity Error Over the Entire Range PM balances can be used to determine the mass of irregularly shaped components with a centre of gravity that is significantly shifted from the weighing pan axis. Parameter Stability Over Time and After Transport The mechanical design is resistant and robust, allowing you to maintain the correct metrological parameters after transport and despite long and intensive use. Weighing Pan Dimensions Adapted to the Accuracy of the Balance Weigh with the highest readability of 0.01 g on the 200 x 185 mm weighing pan and with a readability of 0.2 g on the 500 x 400 mm weighing pan. 21 CFR Part 11 Do you work in the pharmaceutical industry? Do you need a digital signature? We are offering the laboratory balance which as a standalone fully meets the requirements of 21 CFR Part 11/ EU GMP Annex 11. - Full data security - Electronic signatures - Validations - Electronic records - Audit trails New, lmproved The new, taller and larger MONOBLOCK® enables the best repeatability and speed in its class of weighing platforms. 5Y Terminal With Terminal 5Y you get a 10-inch display, Digital Weighing Auditor, multi-step user verification, ambient light alerts, hotspot, RFID*, live note voice and text notes, voice commands for the balance and handy measurement history within the handy library widgets Modbus TCP/IP is one of the most popular communication protocols in industrial automation. Implementing it in the 5Y balances and CY10 scales makes the devices of this series friendly to automation integrators. A balance or scale in a Modbus system is a slave device and performs tasks specified by the master device which is most often a PLC. Protocol Modbus TCP/IP in the 5Y balances and C10 scales enables, among other things, the realization of mass readout, zeroing and tare functions of the device, as well as tare settings and MIN and MAX thresholds. Under-pan weighing Weighing instruments purchased after 15th February 2023 will allow under-pan weighing at any time after the purchase. All you need to do is just to order a dedicated hook. THBR 2.0 System Cooperation with THBR 2.0 System for ambient conditions monitoring. * RFID ISO/IEC 14443 Type A, 13,56 MHz

Fast and Stable Measurement It only takes a second for the balance to display the final measurement  (more)result. Weighing Heavy Loads with High Accuracy On the large weighing pan of a PM balance, you can weigh a load of 120 kg with a readability of 0.2 g and second-to-none repeatability. Minimum Eccentricity Error Over the Entire Range PM balances can be used to determine the mass of irregularly shaped components with a centre of gravity that is significantly shifted from the weighing pan axis. Parameter Stability Over Time and After Transport The mechanical design is resistant and robust, allowing you to maintain the correct metrological parameters after transport and despite long and intensive use. Weighing Pan Dimensions Adapted to the Accuracy of the Balance Weigh with the highest readability of 0.01 g on the 200 x 185 mm weighing pan and with a readability of 0.2 g on the 500 x 400 mm weighing pan. 21 CFR Part 11 Do you work in the pharmaceutical industry? Do you need a digital signature? We are offering the laboratory balance which as a standalone fully meets the requirements of 21 CFR Part 11/ EU GMP Annex 11. - Full data security - Electronic signatures - Validations - Electronic records - Audit trails New, lmproved The new, taller and larger MONOBLOCK® enables the best repeatability and speed in its class of weighing platforms. 5Y Terminal With Terminal 5Y you get a 10-inch display, Digital Weighing Auditor, multi-step user verification, ambient light alerts, hotspot, RFID*, live note voice and text notes, voice commands for the balance and handy measurement history within the handy library widgets Modbus TCP/IP is one of the most popular communication protocols in industrial automation. Implementing it in the 5Y balances and CY10 scales makes the devices of this series friendly to automation integrators. A balance or scale in a Modbus system is a slave device and performs tasks specified by the master device which is most often a PLC. Protocol Modbus TCP/IP in the 5Y balances and C10 scales enables, among other things, the realization of mass readout, zeroing and tare functions of the device, as well as tare settings and MIN and MAX thresholds. Under-pan weighing Weighing instruments purchased after 15th February 2023 will allow under-pan weighing at any time after the purchase. All you need to do is just to order a dedicated hook. THBR 2.0 System Cooperation with THBR 2.0 System for ambient conditions monitoring. * RFID ISO/IEC 14443 Type A, 13,56 MHz

Fast and Stable Measurement It only takes a second for the balance to display the final measurement  (more)result. Weighing Heavy Loads with High Accuracy On the large weighing pan of a PM balance, you can weigh a load of 120 kg with a readability of 0.2 g and second-to-none repeatability. Minimum Eccentricity Error Over the Entire Range PM balances can be used to determine the mass of irregularly shaped components with a centre of gravity that is significantly shifted from the weighing pan axis. Parameter Stability Over Time and After Transport The mechanical design is resistant and robust, allowing you to maintain the correct metrological parameters after transport and despite long and intensive use. Weighing Pan Dimensions Adapted to the Accuracy of the Balance Weigh with the highest readability of 0.01 g on the 200 x 185 mm weighing pan and with a readability of 0.2 g on the 500 x 400 mm weighing pan. 21 CFR Part 11 Do you work in the pharmaceutical industry? Do you need a digital signature? We are offering the laboratory balance which as a standalone fully meets the requirements of 21 CFR Part 11/ EU GMP Annex 11. - Full data security - Electronic signatures - Validations - Electronic records - Audit trails New, lmproved The new, taller and larger MONOBLOCK® enables the best repeatability and speed in its class of weighing platforms. 5Y Terminal With Terminal 5Y you get a 10-inch display, Digital Weighing Auditor, multi-step user verification, ambient light alerts, hotspot, RFID*, live note voice and text notes, voice commands for the balance and handy measurement history within the handy library widgets Modbus TCP/IP is one of the most popular communication protocols in industrial automation. Implementing it in the 5Y balances and CY10 scales makes the devices of this series friendly to automation integrators. A balance or scale in a Modbus system is a slave device and performs tasks specified by the master device which is most often a PLC. Protocol Modbus TCP/IP in the 5Y balances and C10 scales enables, among other things, the realization of mass readout, zeroing and tare functions of the device, as well as tare settings and MIN and MAX thresholds. THBR 2.0 System Cooperation with THBR 2.0 System for ambient conditions monitoring. * RFID ISO/IEC 14443 Type A, 13,56 MHz

Fast and Stable Measurement It only takes a second for the balance to display the final measurement  (more)result. Weighing Heavy Loads with High Accuracy On the large weighing pan of a PM balance, you can weigh a load of 120 kg with a readability of 0.2 g and second-to-none repeatability. Minimum Eccentricity Error Over the Entire Range PM balances can be used to determine the mass of irregularly shaped components with a centre of gravity that is significantly shifted from the weighing pan axis. Parameter Stability Over Time and After Transport The mechanical design is resistant and robust, allowing you to maintain the correct metrological parameters after transport and despite long and intensive use. Weighing Pan Dimensions Adapted to the Accuracy of the Balance Weigh with the highest readability of 0.01 g on the 200 x 185 mm weighing pan and with a readability of 0.2 g on the 500 x 400 mm weighing pan. 21 CFR Part 11 Do you work in the pharmaceutical industry? Do you need a digital signature? We are offering the laboratory balance which as a standalone fully meets the requirements of 21 CFR Part 11/ EU GMP Annex 11. - Full data security - Electronic signatures - Validations - Electronic records - Audit trails New, lmproved The new, taller and larger MONOBLOCK® enables the best repeatability and speed in its class of weighing platforms. 5Y Terminal With Terminal 5Y you get a 10-inch display, Digital Weighing Auditor, multi-step user verification, ambient light alerts, hotspot, RFID*, live note voice and text notes, voice commands for the balance and handy measurement history within the handy library widgets Modbus TCP/IP is one of the most popular communication protocols in industrial automation. Implementing it in the 5Y balances and CY10 scales makes the devices of this series friendly to automation integrators. A balance or scale in a Modbus system is a slave device and performs tasks specified by the master device which is most often a PLC. Protocol Modbus TCP/IP in the 5Y balances and C10 scales enables, among other things, the realization of mass readout, zeroing and tare functions of the device, as well as tare settings and MIN and MAX thresholds. Under-pan weighing Weighing instruments purchased after 15th February 2023 will allow under-pan weighing at any time after the purchase. All you need to do is just to order a dedicated hook. THBR 2.0 System Cooperation with THBR 2.0 System for ambient conditions monitoring. * RFID ISO/IEC 14443 Type A, 13,56 MHz

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Profinet – an open communication system based on the industrial Ethernet standard. It is a cer (more)tain combination of features of PROFIBUS DB standard and industrial Ethernet. The Profinet interface application ensures compatibility of RADWAG weighing systems with industrial automation elements of other manufacturers. This approach results in easier and faster scales integration with PLCs, HMI operator panels or industrial robots. Profinet is featured in the IM01.EX-5 communication module and MW-01-A5 weighing module, and as an option at an extra charge in PUE HX7 and PUE HY10 terminals, and in HRP platforms (and is not included in HRP.EX platforms).

Profibus – a real-time industrial network standard. It is based on the physical layer of the s (more)erial interface known as RS485. Communication takes place on a master/ slave basis and in this correlation the scale acts as a slave device. The use of the Profibus interface allows RADWAG scales to integrate with older generation automation systems using the Profibus network, which is still widely used in industry. Profibus is featured in the IM01.EX-4 communication module as well as in MW-01-A4 and MW-04-3 weighing modules, and as an option at an extra charge in PUE HX7 and PUE HY10 terminals.

IN/OUT module – semiconductor digital inputs/outputs which can take two binary states: “ (more)0” (inactive) or “1” (active). The input ativation performs the assigned function of the scale, for example, zeroing, tare or process start. The output activation informs about the execution of the assigned function, for example, a certain weight threshold exceeding, scale stability or the process continuation. The IN/OUT module comes for an extra charge in PUE H315 (4 IN/ 4 OUT).

IN/OUT module – semiconductor digital inputs/outputs which can take two binary states: “ (more)0” (inactive) or “1” (active). The input ativation performs the assigned function of the scale, for example, zeroing, tare or process start. The output activation informs about the execution of the assigned function, for example, a certain weight threshold exceeding, scale stability or the process continuation. The IN/OUT module comes for an extra charge in PUE HX7 and PUE HY10 (12 IN/ 12 OUT) terminals.

EtherNet/IP - (Ethernet Industrial Protocol), an industrial communication protocol using Ethernet. E (more)therNet/IP is based on CIP (Common Industrial Protocol) and is widely used in industrial automation. The use of the EtherNet/IP interface ensures compatibility of Radwag weighing systems with other manufacturers' industrial automation components. This approach results in easier and faster integration of scales with PLCs, HMI operator panels or industrial robots.

The analog output module converts the scale output signal (mass) into an analog signal. The mass val (more)ue is most often represented in the form of a 4-20 mA current signal. Due to the low resolution of the module (several thousand), such a signal is used in automation for processes that do not require high precision. Analog output module is available in: IM01.EX-2 communication module and MW01-A7 weighing module, and for an extra charge in PUE H315 terminals.

The analog output module converts the scale output signal (mass) into an analog signal. The mass val (more)ue is most often represented in the form of a 4-20 mA current signal. Due to the low resolution of the module (several thousand), such a signal is used in automation for processes that do not require high precision. Analog output module is available in: IM01.EX-2 communication module and MW01-A7 weighing module, and for an extra charge in PUE HX7 and PUE HY10 terminals.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

ZD421t (ZD4A042-30EM00EZ) - printer suitable for printing thermal and thermal transfer self-adhesive (more) labels. The maximum width of the media is 108 mm, with the maximum print on the width of 104 mm. As standard, it has a built-in movable label sensor. Printing takes place at speeds up to 152 mm / s, printing resolution 203 dpi. The printer is equipped with a USB port. The basic version of the printer does not include a dispenser and a cutter.

The water vapour permeability determination set is used in moisture analyzers of max capacity greate (more)r than 50g. Water vapour permeability is a feature that determines the quality and practicality of application of a given fabric. Clothes or footwear made of materials of inadequate permeability may be unhealthy and uncomfortable. In order to determine water vapour permeability, RADWAG moisture analyzer has to be equipped with a water vapour permeability determination set. The developed method of testing water vapour permeability consists in placing required amount of water in a vessel made of aluminium alloy, inside which a fabric sample, cut using a blanking die, is clamped. Prior to the test, the sample should be left in a room with stable ambient conditions for 24 hours. It is recommended to place the vessel containing water and sample in the moisture analyzer and start the drying process at 40°C. The advantage of this method is a very short drying time. It takes up to 50 minutes to obtain the result. In contrast, measurement carried out using standard method takes up to 72 hours. Measurement results are presented in mg H2O / 1000 mm2 / 24h or as the percentage amount of water vapour passed through the material to the amount of water vapour passed without the tested fabric.

The set is an ideal solution for drying large volume samples, e.g. textiles, or products that placed (more) on the weighing pan tend to increase their volume. The container allows to enclose the sample within a limited space wherein the possibility to determine the moisture content value remains unaffected. In the case of large-volume samples, the kit prevents the sample from coming into contact with solid elements of the moisture analyzer (such as the heating element or its cover) and protects it from damage. Closing a large-volume, low-density sample in the container also reduces the risk of errors resulting from the effect of the sample being raised by warm air. The accessory gives the user full control of the sample and an error-free result. The set consists of 2 components made of steel. It is compatible with all moisture analyzers.

The case has been designed for safe transportation of the PMV PLUS moisture analyzer. It is equipped (more) with two handles for convenient carrying so that the device can be transported by two people at the same time (recommended). The interior of the case has been adapted to fit all device components, with this it can be carried without the risk of damage. The case is made of 6 mm thick plywood. It features reinforced corners, aluminium trim, and hard dark foam filling. The case comes as an accessory.

The case has been designed for safe transportation of the MA X2, MAR moisture analyzer. It is equipp (more)ed with two handles for convenient carrying. The interior of the case has been adapted to fit all device components, with this it can be carried without the risk of damage. The case is made of 6 mm thick plywood. It features reinforced corners, aluminium trim, and hard dark foam filling. The case comes as an accessory.

This is the first receipt printer of RADWAG production. We offer two models which differ in terms of (more) communication interfaces: RTP-RU80 – RS 232* and USB, RTP-UEW80 – USB, Ethernet and Wi-Fi. The printers communicate with all RADWAG laboratory balances and industry scales. Their connection and configuration is intuitively easy and takes barely few moments (Plug and Play). Communication via Wi-Fi enables remote printing. The printers are equipped with a paper cutter ensuring operation ergonomics. The set includes: RTP-RU80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; RS232 cable, female/ male; 80 mm thermal paper, 1 roll; RTP-UEW80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; 80 mm thermal paper, 1 roll. *RS 232 port comes in a female version

This is the first receipt printer of RADWAG production. We offer two models which differ in terms of (more) communication interfaces: RTP-RU80 – RS 232* and USB, RTP-UEW80 – USB, Ethernet and Wi-Fi. The printers communicate with all RADWAG laboratory balances and industry scales. Their connection and configuration is intuitively easy and takes barely few moments (Plug and Play). Communication via Wi-Fi enables remote printing. The printers are equipped with a paper cutter ensuring operation ergonomics. The set includes: RTP-RU80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; RS232 cable, female/ male; 80 mm thermal paper, 1 roll; RTP-UEW80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; 80 mm thermal paper, 1 roll. *RS 232 port comes in a female version

RFID is a proximity (contactless) tag with a microprocessor (chip) and an antenna. It does not emit  (more)a signal by iitself - it uses radio waves of a specific frequency for identification (passive tag). Application The RFID tag* allows access to defined capabilities by radio-frequency identification of a: • Specific person - Simply close the RFID tag to the terminal to access the data. This way don't have to enter your name and password every time you want to log in. This means data security and time saving; • Spiecific access code - You can use the RFID tag to mark specific goods or recipe ingredients in the database. This solution guarantees error-free formulation and reduces the procedure time. *RFID ISO/IEC 14443 Type A, 13,56 MHz How to Use RFID Tag with ELLIPSIS Balances? 1. Click the Parameters field and then the Operators field. 2. Add an operator and fill in your data. 3. Click the Card no. field and close the tag to the terminal. 4. Click to confirm the settings. Benefits In short, RFID technology ensures data security through 100% user identification and eliminates errors due to the "human factor". In addition, it optimizes work time and improves effciency, and above all, it offers endless possibilities.

Reference material Sodium Chloride (NaCl) at a concentration of 9 or 10%. It is colourless, clear l (more)iquid with the density of 1.07 g/cm3 and certified moisture content. The substance is used for verification of each moisture analyzer operation.

PT0455 Cable is used to connect the 5Y series balance or the PUE CY10 terminal to a RADWAG RTP print (more)er. Its standard length is 1,8m.

PT0454 Cable is used to connect the 5Y and CY10 series balance to a communication module Media Box  (more)IM02.1. Its standard length is 0,6 m.

PT0443 Cable is used to connect the 5Y series balance or the PUE CY10 terminal to a computer. Its st (more)andard length is 1,8 m. Optionally, the cable is used to connect the 5Y series balance or the PUE CY10 terminal to: AS X2 and AS R series balances PS X2 i PS R series balances PM C32 series balances WLC and WTC series balances, and C315 series scales MAS and MPS series weighing modules
