Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Profinet – an open communication system based on the industrial Ethernet standard. It is a cer (more)tain combination of features of PROFIBUS DB standard and industrial Ethernet. The Profinet interface application ensures compatibility of RADWAG weighing systems with industrial automation elements of other manufacturers. This approach results in easier and faster scales integration with PLCs, HMI operator panels or industrial robots. Profinet is featured in the IM01.EX-5 communication module and MW-01-A5 weighing module, and as an option at an extra charge in PUE HX7 and PUE HY10 terminals, and in HRP platforms (and is not included in HRP.EX platforms).

Profibus – a real-time industrial network standard. It is based on the physical layer of the s (more)erial interface known as RS485. Communication takes place on a master/ slave basis and in this correlation the scale acts as a slave device. The use of the Profibus interface allows RADWAG scales to integrate with older generation automation systems using the Profibus network, which is still widely used in industry. Profibus is featured in the IM01.EX-4 communication module as well as in MW-01-A4 and MW-04-3 weighing modules, and as an option at an extra charge in PUE HX7 and PUE HY10 terminals.

IN/OUT module – semiconductor digital inputs/outputs which can take two binary states: “ (more)0” (inactive) or “1” (active). The input ativation performs the assigned function of the scale, for example, zeroing, tare or process start. The output activation informs about the execution of the assigned function, for example, a certain weight threshold exceeding, scale stability or the process continuation. The IN/OUT module comes for an extra charge in PUE H315 (4 IN/ 4 OUT).

IN/OUT module – semiconductor digital inputs/outputs which can take two binary states: “ (more)0” (inactive) or “1” (active). The input ativation performs the assigned function of the scale, for example, zeroing, tare or process start. The output activation informs about the execution of the assigned function, for example, a certain weight threshold exceeding, scale stability or the process continuation. The IN/OUT module comes for an extra charge in PUE HX7 and PUE HY10 (12 IN/ 12 OUT) terminals.

EtherNet/IP - (Ethernet Industrial Protocol), an industrial communication protocol using Ethernet. E (more)therNet/IP is based on CIP (Common Industrial Protocol) and is widely used in industrial automation. The use of the EtherNet/IP interface ensures compatibility of Radwag weighing systems with other manufacturers' industrial automation components. This approach results in easier and faster integration of scales with PLCs, HMI operator panels or industrial robots.

The analog output module converts the scale output signal (mass) into an analog signal. The mass val (more)ue is most often represented in the form of a 4-20 mA current signal. Due to the low resolution of the module (several thousand), such a signal is used in automation for processes that do not require high precision. Analog output module is available in: IM01.EX-2 communication module and MW01-A7 weighing module, and for an extra charge in PUE H315 terminals.

The analog output module converts the scale output signal (mass) into an analog signal. The mass val (more)ue is most often represented in the form of a 4-20 mA current signal. Due to the low resolution of the module (several thousand), such a signal is used in automation for processes that do not require high precision. Analog output module is available in: IM01.EX-2 communication module and MW01-A7 weighing module, and for an extra charge in PUE HX7 and PUE HY10 terminals.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

ZD421t (ZD4A042-30EM00EZ) - printer suitable for printing thermal and thermal transfer self-adhesive (more) labels. The maximum width of the media is 108 mm, with the maximum print on the width of 104 mm. As standard, it has a built-in movable label sensor. Printing takes place at speeds up to 152 mm / s, printing resolution 203 dpi. The printer is equipped with a USB port. The basic version of the printer does not include a dispenser and a cutter.

This is the first receipt printer of RADWAG production. We offer two models which differ in terms of (more) communication interfaces: RTP-RU80 – RS 232* and USB, RTP-UEW80 – USB, Ethernet and Wi-Fi. The printers communicate with all RADWAG laboratory balances and industry scales. Their connection and configuration is intuitively easy and takes barely few moments (Plug and Play). Communication via Wi-Fi enables remote printing. The printers are equipped with a paper cutter ensuring operation ergonomics. The set includes: RTP-RU80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; RS232 cable, female/ male; 80 mm thermal paper, 1 roll; RTP-UEW80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; 80 mm thermal paper, 1 roll. *RS 232 port comes in a female version

This is the first receipt printer of RADWAG production. We offer two models which differ in terms of (more) communication interfaces: RTP-RU80 – RS 232* and USB, RTP-UEW80 – USB, Ethernet and Wi-Fi. The printers communicate with all RADWAG laboratory balances and industry scales. Their connection and configuration is intuitively easy and takes barely few moments (Plug and Play). Communication via Wi-Fi enables remote printing. The printers are equipped with a paper cutter ensuring operation ergonomics. The set includes: RTP-RU80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; RS232 cable, female/ male; 80 mm thermal paper, 1 roll; RTP-UEW80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; 80 mm thermal paper, 1 roll. *RS 232 port comes in a female version

RFID is a proximity (contactless) tag with a microprocessor (chip) and an antenna. It does not emit  (more)a signal by iitself - it uses radio waves of a specific frequency for identification (passive tag). Application The RFID tag* allows access to defined capabilities by radio-frequency identification of a: • Specific person - Simply close the RFID tag to the terminal to access the data. This way don't have to enter your name and password every time you want to log in. This means data security and time saving; • Spiecific access code - You can use the RFID tag to mark specific goods or recipe ingredients in the database. This solution guarantees error-free formulation and reduces the procedure time. *RFID ISO/IEC 14443 Type A, 13,56 MHz How to Use RFID Tag with ELLIPSIS Balances? 1. Click the Parameters field and then the Operators field. 2. Add an operator and fill in your data. 3. Click the Card no. field and close the tag to the terminal. 4. Click to confirm the settings. Benefits In short, RFID technology ensures data security through 100% user identification and eliminates errors due to the "human factor". In addition, it optimizes work time and improves effciency, and above all, it offers endless possibilities.

PT0455 Cable is used to connect the 5Y series balance or the PUE CY10 terminal to a RADWAG RTP print (more)er. Its standard length is 1,8m.

PT0454 Cable is used to connect the 5Y and CY10 series balance to a communication module Media Box  (more)IM02.1. Its standard length is 0,6 m.

PT0443 Cable is used to connect the 5Y series balance or the PUE CY10 terminal to a computer. Its st (more)andard length is 1,8 m. Optionally, the cable is used to connect the 5Y series balance or the PUE CY10 terminal to: AS X2 and AS R series balances PS X2 i PS R series balances PM C32 series balances WLC and WTC series balances, and C315 series scales MAS and MPS series weighing modules

RS 232 cable for connecting a balance/scale (PUE C/31 terminal) to an Epson printer. Standard cable  (more)length: 1,7m. Compatible with: - Scales operated by means of PUE C31 terminal - Scales operated by means of PUE 7.1 terminal - PUE C31 terminal - PUE 7.1 terminal

RS 232 cable: Balance - computer. Standard cable length: 1.7 m. Compatible with: - Scales with PUE C (more)315 terminal - PUE C315 terminal

RS 232 cable: Balance - computer. Cable length: 5 m Compatible with: - Scales with PUE C315 terminal (more) - PUE C315 terminal

The IM02.1 (MediaBox) communication module enables the expansion of the available range of interface (more)s of the PUE CY10 weighing terminal and 5Y series balances. It is equipped with RS 232, Virtual Com (USB type B) and 4 opto-isolated inputs and 4 semiconductor outputs, which enables interfacing PUE CY10 terminals and 5Y series balances with accessories such as: printers, control buttons (e.g. print-tar), light columns, buzzers, PLC controllers and other control and signalling devices. Assignment of input and output functions is possible from the menu of the PUE CY10 weighing terminal and 5Y series balances.

The screen of the 5Y and CY10 terminal is made of glass – a material prone to scratches and cr (more)acks. It can easily be dropped or damaged by transport, so it is worth ensuring that it is properly protected. Safety in Every Inch Hybrid glass protects the touch panel of the ELLIPSIS and CY10 series devices terminal from scratches and cracks. It combines the advantages of glass and film: resistance and flexibility. It is perfectly matched to the balances’s display, so it provides the highest level of security to every inch of the screen. Antistatic Properties The Hybrid Protective Glass is not only scratch and impact resistant, but also antistatic. Thanks to its antistatic properties, the Hybrid Protective Glass prevents dust particles drawn by static electricity from sticking to the surface of the screen. Instant Responsiveness The hybrid protective glass allows instant response to touch. It does not affect the user experience of the terminal – it does not limit the sensitivity of the screen, does not reduce viewing angles and does not distort colors. Hybrid Protective Glass at a Glance: very thin – ~0.3 mm perfectly smooth durable – strengthens the screen by up to 250% scratch-resistant – glass hardness of 7H The Set Includes: hybrid protective glass leave that removes pollen from under the already applied glass positioning sticker to help fit the glass to the screen cardboard to eliminate air bubbles cleaning kit (moistened cloth and non-dusting cloth) You can buy and install the hybrid protective glass at any time. Installation is very easy and takes a while.

An accessory for the ELLIPSIS laboratory balances, designed to read fingerprints in order to log int (more)o the balance. Simply touch the reader to log in. The fingerprint reader is connected to the ELLIPSIS balance via the USB port.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

The 21 CFR Part 11 Compliance Module is a solution especially useful for those users who are obliged (more) to conform to provisions of 21 CFR Part 11 and EU GMP Part 4, Annex 11 regulations. These two documents determine the rules for using electronic records and signatures. Data protection is guaranteed by: advanced password settings, control of logging correctness, various permission levels, data management access, backup, electronic signature, time-defined automatic logout, modification record to Audit Trail file. The module includes "Audit Trail". Audit Trail is a kind of a log where all modifications of balance settings, changes in database records and user activity are recorded. Audit Trail, for example, keeps record of previous and new modifications in databases and informs by whom and when they were introduced. This log allows the administrator to track and find out who logged in, when, who signed a document or who used invalid password. The Audit Trail Reader freeware allows users, upon connection with a balance, to display Audit Trail log and manage it by generating reports of various formats: pdf, xls, csv, html.

Large-size additional display is an accessory of load-cell scales. stainless steel housing 6 digits  (more)of 4,5 inches in height (11,2cm) white diode backlight Features Robust and Resistant Stainless Steel Housing The WWG-2 LCD display is housed in a stainless steel housing, which enables its operation in harsh industry conditions. The display can be installed on the table top or mounted on the wall. The WWG-2 LCD features white diode backlight and clear display indicating digits of 4.5" (11.2cm) height. Communication Communication with indicators (weighing instruments) is carried out via RS22 or RS485 connectors. Depending on the installation option, the display is powered by 230VAC or 7-24VAC.
