A mounting bracket for the PUE C315 indicator connected to the scale via cable. It enables fitting t (more)he indicator to a table or mounting it on a wall. The mounting bracket is manufactured in mild steel powder coated technology.

A stand for supporting scale's indicator installed on a cable 5Y / PUE CY10. Mild steel version (more) available.

A stand, based on a tripod for supporting scale's indicator installed on a cable PUE HY10 / PUE  (more)HX7 / HX5.EX. Stainless steel version available. Stand for measuring indicator PUE HX5.EX can only be purchased together with the HX5.EX indicator/ scale.

A stand, based on a tripod for supporting scale's terminal installed on a cable PUE H315. Stainl (more)ess steel version available.

A stand, based on a tripod for supporting scale's indicator installed on a cable PUE C32 / PUE 7 (more).1. Mild steel version available.

A stand, based on a tripod for supporting scale's indicator installed on a cable PUE C315. Mild  (more)steel version available.

Wall-mounting kit has been designed to facilitate installation of PUE 7.1 and PUE C32 terminals on a (more) vertical surface. The kit can be mounted in two positions. Intended use: Easy installation of PUE 7.1 terminal on a vertical surface; Easy installation of PUE C32 terminal on a vertical surface; Mounting the PUE 7.1 terminal to a wall at the angle of 80°; Mounting the PUE C32 terminal to a wall at the angle of 80°; Mounting the PUE 7.1 terminal to a wall at the angle of 55°; Mounting the PUE C32 terminal to a wall at the angle of 55°. Design: The PUE-7-32 wall-mounting kit is manufactured of 1 mm steel, which provides sufficient rigidity. The kit is offered in powder coated mild steel version in colour corresponding to the colour of PUE 7.1 / PUE C32 housing. Multiple technological holes, make it possible to mount the kit in 8 points (4 mounting points for the PUE 7.1 / PUE C32 terminal and 4 mounting points for fixing to a vertical surface).

Wall-mounting kit has been designed to facilitate installation of 5Y / PUE CY10 terminals on a verti (more)cal surface. The kit enables adjustment of the terminal tilt.

PUE-7-36 wall-mounting kit has been designed to facilitate installation of PUE 7.1 and PUE C32 termi (more)nals on a vertical surface. The kit enables adjustment of the terminal tilt. Intended use: Easy installation of PUE 7.1 terminal on a vertical and horizontal surface, adjustable tilt angle, Easy installation of PUE C32 terminal on a vertical and horizontal surface, adjustable tilt angle.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Character communication protocol is designed for communication between RADWAG balance and external d (more)evice via RS232, Ethernet or Wi-Fi* interfaces. The protocol consists of commands sent from the external device to the balance and responses sent from the balance to the device. Responses are sent from the balance each time a command is received as a response to the command. The commands that make up the communication protocol allow you to obtain information about the status of the balance and ways to influence its operation, for example, they allow you to receive weighing results from the balance, control the display, etc.

Profinet – an open communication system based on the industrial Ethernet standard. It is a cer (more)tain combination of features of PROFIBUS DB standard and industrial Ethernet. The Profinet interface application ensures compatibility of RADWAG weighing systems with industrial automation elements of other manufacturers. This approach results in easier and faster scales integration with PLCs, HMI operator panels or industrial robots. Profinet is featured in the IM01.EX-5 communication module and MW-01-A5 weighing module, and as an option at an extra charge in PUE HX7 and PUE HY10 terminals, and in HRP platforms (and is not included in HRP.EX platforms).

Profibus – a real-time industrial network standard. It is based on the physical layer of the s (more)erial interface known as RS485. Communication takes place on a master/ slave basis and in this correlation the scale acts as a slave device. The use of the Profibus interface allows RADWAG scales to integrate with older generation automation systems using the Profibus network, which is still widely used in industry. Profibus is featured in the IM01.EX-4 communication module as well as in MW-01-A4 and MW-04-3 weighing modules, and as an option at an extra charge in PUE HX7 and PUE HY10 terminals.

IN/OUT module – semiconductor digital inputs/outputs which can take two binary states: “ (more)0” (inactive) or “1” (active). The input ativation performs the assigned function of the scale, for example, zeroing, tare or process start. The output activation informs about the execution of the assigned function, for example, a certain weight threshold exceeding, scale stability or the process continuation. The IN/OUT module comes for an extra charge in PUE H315 (4 IN/ 4 OUT).

IN/OUT module – semiconductor digital inputs/outputs which can take two binary states: “ (more)0” (inactive) or “1” (active). The input ativation performs the assigned function of the scale, for example, zeroing, tare or process start. The output activation informs about the execution of the assigned function, for example, a certain weight threshold exceeding, scale stability or the process continuation. The IN/OUT module comes for an extra charge in PUE HX7 and PUE HY10 (12 IN/ 12 OUT) terminals.

EtherNet/IP - (Ethernet Industrial Protocol), an industrial communication protocol using Ethernet. E (more)therNet/IP is based on CIP (Common Industrial Protocol) and is widely used in industrial automation. The use of the EtherNet/IP interface ensures compatibility of Radwag weighing systems with other manufacturers' industrial automation components. This approach results in easier and faster integration of scales with PLCs, HMI operator panels or industrial robots.

The analog output module converts the scale output signal (mass) into an analog signal. The mass val (more)ue is most often represented in the form of a 4-20 mA current signal. Due to the low resolution of the module (several thousand), such a signal is used in automation for processes that do not require high precision. Analog output module is available in: IM01.EX-2 communication module and MW01-A7 weighing module, and for an extra charge in PUE H315 terminals.

The analog output module converts the scale output signal (mass) into an analog signal. The mass val (more)ue is most often represented in the form of a 4-20 mA current signal. Due to the low resolution of the module (several thousand), such a signal is used in automation for processes that do not require high precision. Analog output module is available in: IM01.EX-2 communication module and MW01-A7 weighing module, and for an extra charge in PUE HX7 and PUE HY10 terminals.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

Powerbank ZR-04 is used for rechargeable power supply for balances and scale accessories. It uses fa (more)st charging technology. It allows long operating time without recharging and, thanks to the “Low Power” function, powering devices with low power consumption. The ZR-04 powerbank is made of high-quality components that ensure reliable operation. A display indicating the state of charge enhances ergonomics. Powerbank ZR-04 meets airline standards, which means that it can be carried on board an airplane as hand luggage. The device can simultaneously power the balance/ scale and charge the internal battery. The average power time of the balance/ scale is, depending on the product series, from 8 to as much as 24 hours.

ZD421t (ZD4A042-30EM00EZ) - printer suitable for printing thermal and thermal transfer self-adhesive (more) labels. The maximum width of the media is 108 mm, with the maximum print on the width of 104 mm. As standard, it has a built-in movable label sensor. Printing takes place at speeds up to 152 mm / s, printing resolution 203 dpi. The printer is equipped with a USB port. The basic version of the printer does not include a dispenser and a cutter.

This is the first receipt printer of RADWAG production. We offer two models which differ in terms of (more) communication interfaces: RTP-RU80 – RS 232* and USB, RTP-UEW80 – USB, Ethernet and Wi-Fi. The printers communicate with all RADWAG laboratory balances and industry scales. Their connection and configuration is intuitively easy and takes barely few moments (Plug and Play). Communication via Wi-Fi enables remote printing. The printers are equipped with a paper cutter ensuring operation ergonomics. The set includes: RTP-RU80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; RS232 cable, female/ male; 80 mm thermal paper, 1 roll; RTP-UEW80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; 80 mm thermal paper, 1 roll. *RS 232 port comes in a female version

This is the first receipt printer of RADWAG production. We offer two models which differ in terms of (more) communication interfaces: RTP-RU80 – RS 232* and USB, RTP-UEW80 – USB, Ethernet and Wi-Fi. The printers communicate with all RADWAG laboratory balances and industry scales. Their connection and configuration is intuitively easy and takes barely few moments (Plug and Play). Communication via Wi-Fi enables remote printing. The printers are equipped with a paper cutter ensuring operation ergonomics. The set includes: RTP-RU80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; RS232 cable, female/ male; 80 mm thermal paper, 1 roll; RTP-UEW80: printer; power supply; cable with a plug of European standard, type C or E/F; USB cable; 80 mm thermal paper, 1 roll. *RS 232 port comes in a female version

RFID is a proximity (contactless) tag with a microprocessor (chip) and an antenna. It does not emit  (more)a signal by iitself - it uses radio waves of a specific frequency for identification (passive tag). Application The RFID tag* allows access to defined capabilities by radio-frequency identification of a: • Specific person - Simply close the RFID tag to the terminal to access the data. This way don't have to enter your name and password every time you want to log in. This means data security and time saving; • Spiecific access code - You can use the RFID tag to mark specific goods or recipe ingredients in the database. This solution guarantees error-free formulation and reduces the procedure time. *RFID ISO/IEC 14443 Type A, 13,56 MHz How to Use RFID Tag with ELLIPSIS Balances? 1. Click the Parameters field and then the Operators field. 2. Add an operator and fill in your data. 3. Click the Card no. field and close the tag to the terminal. 4. Click to confirm the settings. Benefits In short, RFID technology ensures data security through 100% user identification and eliminates errors due to the "human factor". In addition, it optimizes work time and improves effciency, and above all, it offers endless possibilities.

PT0455 Cable is used to connect the 5Y series balance or the PUE CY10 terminal to a RADWAG RTP print (more)er. Its standard length is 1,8m.

PT0454 Cable is used to connect the 5Y and CY10 series balance to a communication module Media Box  (more)IM02.1. Its standard length is 0,6 m.

PT0443 Cable is used to connect the 5Y series balance or the PUE CY10 terminal to a computer. Its st (more)andard length is 1,8 m. Optionally, the cable is used to connect the 5Y series balance or the PUE CY10 terminal to: AS X2 and AS R series balances PS X2 i PS R series balances PM C32 series balances WLC and WTC series balances, and C315 series scales MAS and MPS series weighing modules

RS 232 cable for connecting a balance/scale (PUE C/31 terminal) to an Epson printer. Standard cable  (more)length: 1,7m. Compatible with: - Scales operated by means of PUE C31 terminal - Scales operated by means of PUE 7.1 terminal - PUE C31 terminal - PUE 7.1 terminal
