Emulsifiers

Dispersion rod S 25 KV - 25G for IKA T25 digital ULTRA-TURRAX New material in original packaging For (more) homogenizer IKA T25 digital ULTRA-TURRAX Model: S 25 KV - 25 G (S25KV-25G) Processed capacity (H2O): 0.05 - 2 l Stator diameter: 25 mm Rotor diameter: 17 mm Stator-rotor gap: 0.5 mm Max. permissible speed : 25000 rpm Peripheral speed : 22.2 m/s Immersion depth : 40 - 225 mm Total length : 270 mm Material in contact with the product : FFPM / SIC, AISI 316L, AISI 302 pH 2 - 13 Solvent resistant : yes Max. working temperature : 220 °C Sterilization methods : all methods Vacuum : 1 mbar Max. pressure : 6 bar Final fineness, suspension : 15 - 50 µm Final fineness, emulsions : 1 - 10 µm Weight : 0.6 kg

Samples and applications - Homogenization of foods (smoothies, homogenized foods, drinks) and prepar (more)ation of stuffings for food (e.g., meat, vegetables) - Homogenization/crushing of tablets - Homogenization of tobacco leaves - Preparation of ceramics and ceramic paste - Processing of textile fibers TECHNICAL DATA - Rotor diameter: 18 mm - Stator diameter: 25 mm - Stator/rotor gap: 0.5 mm - Volume (H2O): 100 - 2,500 ml - Immersion depth: 40-175 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 23.6 m/s - Ultimate fineness, emulsions: 1-10 µm - Ultimate fineness, suspensions: 15-50 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed

Samples and applications - Preparation of spreadable creams and soluble powders (tea, coffee, milk)  (more)- Preparation of pharmaceutical ointments and creams - Suspensions/emulsions for infusion/injection - Preparation of soap, shampoo, and conditioner; preparation of cosmetic lotions - Water analysis - Preparation of pigments, inks, and paints - Preparation of liquid crystals for displays - Preparation of biodiesel TECHNICAL DATA - Rotor diameter: 15 mm - Stator diameter: 20 mm - Stator/rotor gap: 0.5 mm - Volume (H2O): 50 - 2,000 ml - Immersion depth: 40-175 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 19.6 m/s - Ultimate fineness, emulsions: 1-7 µm - Ultimate fineness, suspensions: 5-40 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed

Samples and applications - Food homogenization and preparation of spreadable creams and stuffing for (more) foods (e.g. meat, vegetables) - Preparation of samples for DNA analysis, organic tissue samples and dispersions of organic tissues - Homogenisation of tobacco leaves - Processing of textile fibres - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed TECHNICAL DATA - Rotor diameter: 15 mm - Stator diameter: 20 mm - Stator/rotor gap: 0.5 mm - Volume (H2O): 50 - 2,000 ml - Immersion depth: 40-175 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 19.6 m/s - Ultimate fineness, emulsions: 1-7 µm - Ultimate fineness, suspensions: 5-40 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes

Samples and applications - Sample preparation for DNA and organic tissue analysis - Organic tissue d (more)ispersions TECHNICAL DATA - Rotor diameter: 3.2 mm - Stator diameter: 5 mm - Stator/rotor gap: 0,4 mm - Volume (H2O): 0,2 - 50 ml - Immersion depth: 10-50 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 4,2 m/s - Ultimate fineness, emulsions: 1 -10 µm - Ultimate fineness, suspensions: 10 -50 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed

Samples and applications - Preparation of foamy mixtures (ice cream, butter, margarine, icing) and s (more)preadable creams    - Preparation of tablet coatings - Preparation of ointments and pharmaceutical creams - Preparation of cosmetics (lip balm, soap, shampoo, conditioner, creams, lipstick, mascara) - Preparation of pigments, inks and paints - Preparation of biodiesel - Dispersion of petroleum derivatives (e.g. asphalt) TECHNICAL DATA - Rotor diameter: 18 mm - Stator diameter: 25 mm - Stator/rotor gap: 0.5 mm - Volume (H2O): 100 - 2,500 ml - Immersion depth: 40-175 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 23.6 m/s - Ultimate fineness, emulsions: 1-5 µm - Ultimate fineness, suspensions: 5-25 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed

Samples and applications - Preparation of foamy mixtures (ice cream, butter, margarine, icing) and s (more)preadable creams - Preparation of tablets coatings - Preparation of pharmaceutical ointments and creams - Preparation of cosmetic products (lip balm, soap, shampoo, conditioner, creams, lipstick, mascara) - Preparation of pigments, inks, paints - Preparation of biodiesel and dispersion of petroleum derivatives (e.g., asphalt) TECHNICAL DATA - Rotor diameter: 15 mm - Stator diameter: 20 mm - Stator/rotor gap: 0.5 mm - Volume (H2O): 50 - 2,000 ml - Immersion depth: 40-175 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 19.6 m/s - Ultimate fineness, emulsions: 1-7 µm - Ultimate fineness, suspensions: 5-40 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed

Samples and applications - Food homogenization and preparation of spreadable creams and stuffing for (more) foods (e.g. meat, vegetables) - Preparation of cosmetics (lip balms, creams, lipsticks, ...) - Preparation of tablet coatings and homogenisation/crushing of tablets - Preparation of samples for DNA analysis, organic tissue samples and dispersions of organic tissues - Homogenisation of tobacco leaves - Preparation of pigments, inks, paints and ceramic paste - Processing of textile fibres - Dispersion of petroleum derivatives (e.g. asphalt) - Sterilization and cleaning methods: it is possible to sterilize all the components of the dispersing tool in different ways according to the construction materials and the sample processed TECHNICAL DATA - Rotor diameter: 15 mm - Stator diameter: 20 mm - Stator/rotor gap: 0.5 mm - Volume (H2O): 50 - 2,000 ml - Immersion depth: 40-175 mm - Max. speed: 25,000 rpm - Max. circumferential speed: 19.6 m/s - Ultimate fineness, emulsions: 1-10 µm - Ultimate fineness, suspensions: 10-50 µm - Max. allowable working temperature: 180 °C - Materials in contact with the medium: AISI 316L, PTFE - Suitable for solvents: Yes
