Checkweighers

The offered instrument / system is fully functional tested and ready to use. FURTHER DETAILS TO FOLL (more)OW

Mettler Toledo IND690/PUA579 Checkweigher Lab Platform Scales PUA579-CS300 These were removed from a (more) working lab where they were surplus to requirements. The system powers up and is in good working order. it is in good cosmetic condition with marks from use. It comes supplied with 19 rolls of thermal receipt paper. ControlType - IND690 DeskSN - 3107324/2009 Type - PUA579-CS300SN - 3107323Dimensions - 120 x 105cm Printer type - GA46SN - 3107325

Overhead track scale H315 series is designed for weighing half carcass and porkhalf which are transp (more)orted on scale’s track. The weighing process starts when a roller with measured load enters a measuring section of the track. The load cells are installed lengthwise to the weighing track which is fixed with spherical mandrels. Such design eliminates tensions in the construction. Scales can cooperate with carcass grading equipment. The H315 series is manufactured either in galvanized or in stainless steel version, as dual range weighing instruments. They are equipped with a stainless steel backlit LCD indicator PUE H315 installed on a cable.

Overhead track scale H315 series is designed for weighing half carcass and porkhalf which are transp (more)orted on scale’s track. The weighing process starts when a roller with measured load enters a measuring section of the track. The load cells are installed lengthwise to the weighing track which is fixed with spherical mandrels. Such design eliminates tensions in the construction. Scales can cooperate with carcass grading equipment. The H315 series is manufactured either in galvanized or in stainless steel version, as dual range weighing instruments. They are equipped with a stainless steel backlit LCD indicator PUE H315 installed on a cable.

Are you overwhelmed by the number of production processes? What about having them all under control? (more) To be able to analyse and correct them in real time? After all, it is the key to increasing the efficiency of the production line! Our clients, the factory owners, were the ones who told us about their problems and needs. Our answer is simple: the E2R System. This software is designed to make your work easier. The E2R System consists of six independent modules: 1. E2R Weighing, 2. E2R Weighing Records, 3. E2R Formulations, 4. E2R PGC, 5. E2R Checkweigher, 6. E2R Moisture Analyzer. Choose the best module for your company. Need more information? With the E2R Checkweigher module, you can: collect the weighings recorded by the checkweighers; add, delete and edit elements of the “Products” and “Operators” databases; monitor, from the computer, the weighings carried out on the checkweighers; sort the collected weighings using the preset filters; summarise filtered data in different forms (e.g. weighing sum or measurement mean); handle large amounts of data in real time; define the permission levels for specific operators; export weighings to external files in XLS and CSV formats; export reports to files: PDF, HTML, MHT, RTF, XLS, CSV and TXT; generate both general and detailed reports on the weighings collected; generate graphs of the weighings carried out at the selected time; generate reports: “PGC”, “Standard” and “Miscellaneous” sent from the checkweigher; monitor the status of the checkweigher connected to the E2R System via the E2R Manager application; generate weighing graphs for a given scale in real time, taking into account thresholds and Qn values for the controlled product; enable or disable the collection of individual weighings and their reporting depending on the hardware configuration of the computer on which the E2R Checkweigher module is installed.

The roller scale is designed for weighing heavy, large-size packages such as pallets or crates. It a (more)llows for final product mass control before it enters the warehouse or is transported to the customer. Depending on the application, the scale can be made in a powder-coated version, dedicated for use in warehouses, or in a stainless-steel version, intended for use in wet environments. Operation Ergonomics The scale has a large 10-inch touch screen, which is comfortable and intuitive to use. Operation of the roller scales does not require additional training, as the software of all RADWAG checkweighers is unified. Select an Interface That Your Production Line Supports RADWAG roller scales offer the option of using one of four industrial interfaces, depending on your requirements. All our interfaces allow you to: start and stop the dynamic weighing procedure remotely (Start and Stop function), enter the batch number (Batch Number Readout function), select a product (Select Product During Standstill function). Do You Want Your Scale to Work With a Barcode Scanner? Our roller scales are compatible with barcode scanners: 1D and 2D, manual and automatic. Data contained in one-dimensional (bar) barcodes can be read using 1D scanners. 2D scanners, on the other hand, can read 2D codes, which are large amounts of data encoded in images composed of black and white squares. You can use our scales if you have a manual or automatic scanner mounted above your production line. Roller Scale and Printer – The Perfect Combination Do you use a RADWAG roller scale but not a printer? You have no idea what you are losing. You can easily print a ready report (e.g. statistical or PGC) at any time thanks to the direct connection between the scale and a printer. Do you require product parameters or information on a specific operator? Just select, press “print”, and you’re done. The automatic printout function allows you to receive an automatic frame, i.e. information sent to your computer or printer, immediately after weighing. What does this mean for you? Possibility of recording weighings in real time. You can customise the automatic frame based on your preferences. What do you need? Mass? Product code? Date? You got it. Weigh the Product and Print the Label Do you print labels to identify products in your company? If so, you understand how time-consuming and tedious your work would be without a label printer. We have some exciting news for you: RADWAG roller scales are compatible with label printers. Our product range includes a label printer that can print thermal and thermal-transfer (paper, foil) self-adhesive labels. The printer communicates with the roller scale via Ethernet or RS 232. Capability to Record Measurements The local SQL database system and integration with the multifunctional server software E2R Checkweigher allow measurements to be recorded and processed. Does Your Line Require Special Control Algorithms? The RADWAG roller scales software allows you to adjust the scale operation to the specific requirements of your line. Approval The scale is MID approved. Custom Designs The scale can also operate in feeder mode by controlling the feeding valves.

Automatic checkweigher DWT/RC series is a device designed to control heavy loads or cumulative produ (more)cts. It provides full control of goods transported on a processing line. The device is manufactired in a stanless steel version. Automatic scale DWT/RC series is equipped with a terminal HY series ensuring stability and reliability of operation. The HY controller despite simple construction provides extended possibilities of cooperation with peripheral devices and supplies a set of informative-controlling signals which simplify integration with a processing line. The terminal HY series features full alphanumeric keyboard, and touch screen display which enables very simple and intuitive checkweigher operation. Application: Automatic checkweigher DWT/RC/HY series is designed to control single goods according to customers regulations or according to current regulation on Control of Packaged Goods. The checkweigher can operate in dynamic or static mode. DWT/RC series is attested by NIH. Main applications: · agri-food industry, · chemical industry · meat industry · tobacco industry · distilling industry, · engineering industry, · brewing industry, · transport, shipping. Functions Control of goods in accordance with regulation on Control of Packaged Goods, Control of goods in accordance with customer regulations, Acquiring data on controlled goods, Database of products, Database of operators, Definable access levels for scale users, Statistics conducted in real time, Reports generated automatically in accordance with the weighing mode Cooperation with peripheral devices in a processing line, Remote control, Cooperation with computer software, Static weighing mode. Cooperation with peripheral devices Automatic checkweigher DWT/RC series is prepared to cooperate with peripheral devices, and devices form a processing line. I/O set provides broad configuration possibilities and full integration of the scale with an existing processing line. Printout on thermal printers, Remote control, Records on weighments stored on an external computer, Control over additional conveyors, Cooperation with dosing device with feedback. Implementation options: Feeding conveyor with function of separating packages, Discrimination of defective goods by weight, Separate discriminating set for "too light" and "too heavy" goods, Sounder and/or Warning tower lights, Cooperation with dosing device with feedback, Cooperation with printer, Software for keeping records from weighing processes.

Automatic checkweigher DWT/RC series is a device designed to control heavy loads or cumulative produ (more)cts. It provides full control of goods transported on a processing line. The device is manufactired in a stanless steel version. Automatic scale DWT/RC series is equipped with a terminal HY series ensuring stability and reliability of operation. The HY controller despite simple construction provides extended possibilities of cooperation with peripheral devices and supplies a set of informative-controlling signals which simplify integration with a processing line. The terminal HY series features full alphanumeric keyboard, and touch screen display which enables very simple and intuitive checkweigher operation. Application: Automatic checkweigher DWT/RC/HY series is designed to control single goods according to customers regulations or according to current regulation on Control of Packaged Goods. The checkweigher can operate in dynamic or static mode. DWT/RC series is attested by NIH. Main applications: · agri-food industry, · chemical industry · meat industry · tobacco industry · distilling industry, · engineering industry, · brewing industry, · transport, shipping. Functions Control of goods in accordance with regulation on Control of Packaged Goods, Control of goods in accordance with customer regulations, Acquiring data on controlled goods, Database of products, Database of operators, Definable access levels for scale users, Statistics conducted in real time, Reports generated automatically in accordance with the weighing mode Cooperation with peripheral devices in a processing line, Remote control, Cooperation with computer software, Static weighing mode. Cooperation with peripheral devices Automatic checkweigher DWT/RC series is prepared to cooperate with peripheral devices, and devices form a processing line. I/O set provides broad configuration possibilities and full integration of the scale with an existing processing line. Printout on thermal printers, Remote control, Records on weighments stored on an external computer, Control over additional conveyors, Cooperation with dosing device with feedback. Implementation options: Feeding conveyor with function of separating packages, Discrimination of defective goods by weight, Separate discriminating set for "too light" and "too heavy" goods, Sounder and/or Warning tower lights, Cooperation with dosing device with feedback, Cooperation with printer, Software for keeping records from weighing processes.

Automatic checkweigher DWT/RC/HYF series is dedicated to work on technological lines of food industr (more)y, where high humidity and frequent high pressure cleaning are the major issues. The construction has been designed to enable fast and easy cleaning. Special emphasis has been put on elimination of gaps, spaces and flat surfaces susceptible to condensates and waterstains. The structure of the conveyor belt allows washing it inside and outside without dissembling. The electronics has been placed high above the weighing platform for minimizing the possibility of inundation of the control panel. The checkweigher DWT/RC/HYF series is created in accordance with vertical space division. “Clean zone” ranges from the floor to the level of the conveyor belt (the area where food and production waste accumulates). “Technological zone” is placed above the production line. The control mechanism is based on a terminal HY series, facilitating easy communication between the operator and the machine and providing additional features. Standard functions: - Database of operators and products - RS 232/485 and Ethernet interfaces - I/O control - Current weighing statistics - Automatic printouts - Reports - Cooperation with computer software Additional functions: - Faulty goods discriminator - Barcode scanner - The checkweigher can be equipped with standard ink printers and labelling printers allowing to print the tags of the weighed products - Sounder and/or Warning tower lights - Cooperation with feeders, mounted to the front side, in a feedback system.

Automatic checkweigher DWT/RC/HYF series is dedicated to work on technological lines of food industr (more)y, where high humidity and frequent high pressure cleaning are the major issues. The construction has been designed to enable fast and easy cleaning. Special emphasis has been put on elimination of gaps, spaces and flat surfaces susceptible to condensates and waterstains. The structure of the conveyor belt allows washing it inside and outside without dissembling. The electronics has been placed high above the weighing platform for minimizing the possibility of inundation of the control panel. The checkweigher DWT/RC/HYF series is created in accordance with vertical space division. “Clean zone” ranges from the floor to the level of the conveyor belt (the area where food and production waste accumulates). “Technological zone” is placed above the production line. The control mechanism is based on a terminal HY series, facilitating easy communication between the operator and the machine and providing additional features. Standard functions: - Database of operators and products - RS 232/485 and Ethernet interfaces - I/O control - Current weighing statistics - Automatic printouts - Reports - Cooperation with computer software Additional functions: - Faulty goods discriminator - Barcode scanner - The checkweigher can be equipped with standard ink printers and labelling printers allowing to print the tags of the weighed products - Sounder and/or Warning tower lights - Cooperation with feeders, mounted to the front side, in a feedback system.

Automatic checkweigher DWT/RC/HYF series is dedicated to work on technological lines of food industr (more)y, where high humidity and frequent high pressure cleaning are the major issues. The construction has been designed to enable fast and easy cleaning. Special emphasis has been put on elimination of gaps, spaces and flat surfaces susceptible to condensates and waterstains. The structure of the conveyor belt allows washing it inside and outside without dissembling. The electronics has been placed high above the weighing platform for minimizing the possibility of inundation of the control panel. The checkweigher DWT/RC/HYF series is created in accordance with vertical space division. “Clean zone” ranges from the floor to the level of the conveyor belt (the area where food and production waste accumulates). “Technological zone” is placed above the production line. The control mechanism is based on a terminal HY series, facilitating easy communication between the operator and the machine and providing additional features. Standard functions: - Database of operators and products - RS 232/485 and Ethernet interfaces - I/O control - Current weighing statistics - Automatic printouts - Reports - Cooperation with computer software Additional functions: - Faulty goods discriminator - Barcode scanner - The checkweigher can be equipped with standard ink printers and labelling printers allowing to print the tags of the weighed products - Sounder and/or Warning tower lights - Cooperation with feeders, mounted to the front side, in a feedback system.

Automatic checkweigher DWT/RC/HYF series is dedicated to work on technological lines of food industr (more)y, where high humidity and frequent high pressure cleaning are the major issues. The construction has been designed to enable fast and easy cleaning. Special emphasis has been put on elimination of gaps, spaces and flat surfaces susceptible to condensates and waterstains. The structure of the conveyor belt allows washing it inside and outside without dissembling. The electronics has been placed high above the weighing platform for minimizing the possibility of inundation of the control panel. The checkweigher DWT/RC/HYF series is created in accordance with vertical space division. “Clean zone” ranges from the floor to the level of the conveyor belt (the area where food and production waste accumulates). “Technological zone” is placed above the production line. The control mechanism is based on a terminal HY series, facilitating easy communication between the operator and the machine and providing additional features. Standard functions: - Database of operators and products - RS 232/485 and Ethernet interfaces - I/O control - Current weighing statistics - Automatic printouts - Reports - Cooperation with computer software Additional functions: - Faulty goods discriminator - Barcode scanner - The checkweigher can be equipped with standard ink printers and labelling printers allowing to print the tags of the weighed products - Sounder and/or Warning tower lights - Cooperation with feeders, mounted to the front side, in a feedback system.

Automatic checkweigher DWT/RC/HYF series is dedicated to work on technological lines of food industr (more)y, where high humidity and frequent high pressure cleaning are the major issues. The construction has been designed to enable fast and easy cleaning. Special emphasis has been put on elimination of gaps, spaces and flat surfaces susceptible to condensates and waterstains. The structure of the conveyor belt allows washing it inside and outside without dissembling. The electronics has been placed high above the weighing platform for minimizing the possibility of inundation of the control panel. The checkweigher DWT/RC/HYF series is created in accordance with vertical space division. “Clean zone” ranges from the floor to the level of the conveyor belt (the area where food and production waste accumulates). “Technological zone” is placed above the production line. The control mechanism is based on a terminal HY series, facilitating easy communication between the operator and the machine and providing additional features. Standard functions: - Database of operators and products - RS 232/485 and Ethernet interfaces - I/O control - Current weighing statistics - Automatic printouts - Reports - Cooperation with computer software Additional functions: - Faulty goods discriminator - Barcode scanner - The checkweigher can be equipped with standard ink printers and labelling printers allowing to print the tags of the weighed products - Sounder and/or Warning tower lights - Cooperation with feeders, mounted to the front side, in a feedback system.

Automatic checkweigher DWT/RC/HYF series is dedicated to work on technological lines of food industr (more)y, where high humidity and frequent high pressure cleaning are the major issues. The construction has been designed to enable fast and easy cleaning. Special emphasis has been put on elimination of gaps, spaces and flat surfaces susceptible to condensates and waterstains. The structure of the conveyor belt allows washing it inside and outside without dissembling. The electronics has been placed high above the weighing platform for minimizing the possibility of inundation of the control panel. The checkweigher DWT/RC/HYF series is created in accordance with vertical space division. “Clean zone” ranges from the floor to the level of the conveyor belt (the area where food and production waste accumulates). “Technological zone” is placed above the production line. The control mechanism is based on a terminal HY series, facilitating easy communication between the operator and the machine and providing additional features. Standard functions: - Database of operators and products - RS 232/485 and Ethernet interfaces - I/O control - Current weighing statistics - Automatic printouts - Reports - Cooperation with computer software Additional functions: - Faulty goods discriminator - Barcode scanner - The checkweigher can be equipped with standard ink printers and labelling printers allowing to print the tags of the weighed products - Sounder and/or Warning tower lights - Cooperation with feeders, mounted to the front side, in a feedback system.

Automatic rotational scales is designed for operation in technological lines of cylindrical packaged (more) goods, like aerosols, sprays, glass and plastic bottles, etc. Control unit is based on Windows Embedded software and SQL database server. Industrial computer is designed to operate in hard industrial conditions. Its cooperation with specially prepared Windows platform makes the system stable and allows for holding set parameters. Graphic and touch screen communication panel makes operation very easy and intuitive which has already been appreciated by users. Rotational device is not equipped with its own conveyor belt, it is mounted over an existing one, which significantly shortens and simplifies its installation. The scale is pneumatically powered. This provides high durability and reliability. The DWR H2 checkweigher features two independent weighing systems in-built into one construction, thanks to which the throughput is 160 pcs/min. Application: Rotational scales is intended to control cylindrically shaped single packages, like aerosol, with diameter 35- 66mm*. System operates in accordance with regulation on Control of Prepacked Goods. Main application: · Chemical industry, · Pharmaceutical industry, · Distilling industry, · Food processing industry. * it is possible to weigh containters with other diameter Functions Rotational scales provide 100 % control of goods transported on the processing line. Goods that do not meet set thresholds are discriminated from the line. Control of goods in accordance with regulation on Control of Packaged Goods, Acquiring data on controlled goods, Definable access levels for scale users, Discrimination of defective goods by weight, Extended statistics conducted in real time, Built-in line performance meter, Reports generated automatically in accordance with the weighing mode, Export of reports to PDF files, Cooperation with other devices in a processing line, Remote start and stop function, Detection of line congestion, Detection of empty line, Cooperation with computer software. Basic technical data Industrial Windows Embedded system, Industrial computer designed for operation in hard conditions, Graphic touch screen, Databases applying SQL servers, Interfaces and ports: RS232, USB and Profibus, Ethernet, Controlling - informative outputs control, IP55 or IP65 Cooperation with peripheral devices Rotational scale is prepared to cooperate with peripheral devices, and devices form a processing line. I/O set provides broad configuration possibilities and full integration of the scale with an existing processing line. Cooperation with dosing device with feedback, Cooperation with barcode scanner, Printouts on receipt printers, Remote control , Keeping records from weighing on a computer. Implementation options: Separate discriminating set for "too light" and "too heavy" goods, Sounder and/or Warning tower lights, Cooperation with printers and label printers, Two USB ports, Profibus and Modbus interface support, Weighing record application.

Automatic rotational scales is designed for operation in technological lines of cylindrical packaged (more) goods, like aerosols, sprays, glass and plastic bottles, etc. Control unit is based on Windows Embedded software and SQL database server. Industrial computer is designed to operate in hard industrial conditions. Its cooperation with specially prepared Windows platform makes the system stable and allows for holding set parameters. Graphic and touch screen communication panel makes operation very easy and intuitive which has already been appreciated by users. Rotational device is not equipped with its own conveyor belt, it is mounted over an existing one, which significantly shortens and simplifies its installation. The scale is pneumatically powered. This provides high durability and reliability. Application: Rotational scales is intended to control cylindrically shaped single packages, like aerosol, with diameter 35- 66mm*. System operates in accordance with regulation on Control of Prepacked Goods. Main application: · Chemical industry, · Pharmaceutical industry, · Distilling industry, · Food processing industry. * it is possible to weigh containters with other diameter Functions Rotational scales provide 100 % control of goods transported on the processing line. Goods that do not meet set thresholds are discriminated from the line. Control of goods in accordance with regulation on Control of Packaged Goods, Acquiring data on controlled goods, Definable access levels for scale users, Discrimination of defective goods by weight, Extended statistics conducted in real time, Built-in line performance meter, Reports generated automatically in accordance with the weighing mode, Export of reports to PDF files, Cooperation with other devices in a processing line, Remote start and stop function, Detection of line congestion, Detection of empty line, Cooperation with computer software. Basic technical data Industrial Windows Embedded system, Industrial computer designed for operation in hard conditions, Graphic touch screen, Databases applying SQL servers, Interfaces and ports: RS232, USB and Profibus, Ethernet, Controlling - informative outputs control, IP55 or IP65 Cooperation with peripheral devices Rotational scale is prepared to cooperate with peripheral devices, and devices form a processing line. I/O set provides broad configuration possibilities and full integration of the scale with an existing processing line. Cooperation with dosing device with feedback, Cooperation with barcode scanner, Printouts on receipt printers, Remote control , Keeping records from weighing on a computer. Implementation options: Separate discriminating set for "too light" and "too heavy" goods, Sounder and/or Warning tower lights, Cooperation with printers and label printers, Two USB ports, Profibus and Modbus interface support, Weighing record application.

Mechanical Design Compliant with HACCP DWM HPX checkweigher is designed in accordance with ‚hy (more)gienic design’ requirements. Adoped solutions minimize potential spots where contamination can accumulate, and facilitate maintenance. Among these solutions there are: round-profile construction, no places accumulating contamination, fast disassembly of conveyors and belts requiring no tools, less flat horizontal surfaces on which contamination may accumulate, stainless steel mechanical design (AISI 304 or 316). Specially-designed gaskets, seal wires and shields guarantee IP69K ingress protection. Intended Use This series of checkweighers is intended for food industry, it is especially useful on fish and meat processing production halls. The applied solutions and materials are compliant with strict hygiene standards required for food production. Reinforced, hermetic construction allows to clean the device with pressure washer. Measurement Speed and Precision Mass measurement using DWM HPX checkweigher is carried out with up to 0.5 g readability, on an electromagnetic weighing module housed in a hermetic housing of IP69K ingress protection. Clear Information Layout The 12” display with a touch panel enables easy access to the main functions and clear presentation of the most important information during operation, e.g. current mass value, current statistics, production line throughput and function buttons. Databases The DWM checkweigher features an SQL database. The database stores lists of products, operators and measurement reports. Connectivity with Central Database System E2R software enables synchronization of local databases of particular weighing instruments with a central database. With this, it is possible to preview and manage data from the weighing system administrator’s computer. Compliance with Global Standards DWM HPX checkweighers have type approval certification compliant with the MID directive, and have passed tests carried out in accordance with OIML R51. The checkweigher software enables creation of different permission levels for operators, and registers operations carried out on the scale along with possible operator errors. Compliance with 21 CFR Part 11. The following functions are available to ensure compliance with the regulation: 10 permission levels for operators to be defined by the administrator, requirements for each operator's passwords (determined by the administrator: minimum length, upper-case letters and digits quantity, special signs quantity), the requirement to enter new password at first logging (the first password is entered by the administrator creating the account), determination of password validity period in days automatic logout after a specified time of inactivity operator lockout after 3 incorrect login operations; lockout time specified, unlimited account lockout after 6 incorrect login operations; the account can be unlocked by the administrator saving changes to Audit Trail file; detailed reports on all modifications carried out on the checkweigher (information on parameters modifications including previous and new values), adding information about modification reason. This applies to all operational parameters of the checkweigher, e.g. conveyors speed, enabling/disabling ejector, ejector settings modification, checkweigher start/stop, logging and data contained in all products, operators, weighings and reports databases. All login, start, stop operations and report generating are recorded.

Sorting checkweigher for single loads, intended to be used on a sorting line. The DWM HPS checkweigh (more)er has been designed to comply with strict requirements for hygiene and for resistance to ambient conditions that are present on manufacturing lines in plants processing fish and poultry. Universal mechanic design guarantees that the DWM HPS can be adopted to needs of other branches of industry. Sorting checkweigher of RADWAG production is a hi-tech weighing device equipped with specialized automatics system providing precise and fast product separation. With electromagnetic weighing module, the DWM checkweigher guarantees high speed and precision of the weighing process. The automatic sorting checkweigher has been designed to provide self-acting product sorting process, wherein the products are separated into several groups varying by weight. Owing to the system functionality, the weighed products can be separated into 12 different weight groups. The system enables rejection of defective or faulty products. Depending on the used algorithm, the products can be grouped within specified weight or quantity range (the containers can be filled up to determined weigh value or product quantity). The DWM HPS is a solution carrying out simple operation of sorting and grouping of wide range of products in small and medium-sized companies. It may comprise additional buffering, storing and signaling systems. The device has been equipped with colour 12’’ touch screen easy to read for any working environment. An in-built self-diagnostic system monitors the DWM HPS operation and reports any detected problems in real time. Not only standard DWM HPS series is offered, this sorting checkweigher can be manufactured in a customized version suiting any customer needs. Owing to customization unlimited possibilities are provided when it comes to device dimensions and performance. Used modern industrial dual-core computer guarantees fast data analysis, high weighing throughput, and simultaneously performed connection of scale to a master computer system. The DWM HPS checkweigher features dedicated E2R computer system which facilitates real-time preview of scale state, remote databases update, preview of weighings carried out on the scale and remote reports downloading. The system allows analysis of recorded data, and generating statistics in accordance with self-adopted criteria. To learn more about DWM HPS sorting checkweigher call: +48 48 38 66 234 or write an e-mail: [email protected]

DWM HPE is a combination of a checkweigher system and a labelling system, designed for weighing and  (more)marking of products of variable weight. These parameters speak for themselves: Maximum capacity: 7,5 kg Readability [d]: 1 g Throughput: up to 60 pcs./min You See Everything Even From a Distance The device has been equipped with 12-inch, colour screen and a touch pannel. It can be programmed either using a terminal or remotely, with the Label Editor and E2R Checkweigher software run. Go for the solution which you find more convenient. And you design the labels from the Label Editor. Apply the Labels the Way You Like You can adjust the label application system to particular requirements of the production process of yours (application from the top, application from the side). To meet the most demanding requirements, we can apply tamp or blow label applicators mounted on the actuator or the rotary arm. Should you need to use metal detection and rejection systems, we can equip the device with them – its modular design allows that. You Want to Know What For You Need It? Well, the answer is this: mainly for industry. The DWM labelling checkweighers are intended for industry since it requires pre-packaged products of variable weight to be marked with labels including price. Our devices’ functions are as follows: Constant-weight product labelling, Variable-weight product labelling, Single/ bulk/ pallet label printing, Product sorting, Contamination check-ups, Weighed product record, Freely configurable report module. Plus, They Conform to Worldwide Standards The DWM labelling checkweighers have type approval accordant with MID directive and are tested in accordance with OIML R51 reccomendations. The software enables creation and printout of any labels, also those that include product price. Software Tools Label Editor R02 E2R Checkweigher

Remarkable Throughput, Versatility of Applications Food industry? Pharmaceutical industry? Cosmetic  (more)industry? Three questions and one answer only: DWM checkweighers. These multifunctional devices have MID certificate, proving conformity with regulations on measures and weighing instruments used in all the aforementioned branches of industry. A Walking Ideal Checkweighers are based on an electromagnetic mass converter which is a guarantee for speed and accuracy of the measurement. High resistance to overload means failure free operation, and your peaceful mind. Do Not Set the Expectation Bar Low – This Device Will Adapt to Your Requirements Checkweighers, due to their modular design, meet the requirements of any production line. A complete set of shields, rejecters, sensors, signalling and monitoring modules will come up to expectations of every single customer, and a vast range of transport solutions will allow one to adapt the device to the requirements of a particular product. Convenience of Operation Touch screen terminal, HIM, with multi-language menu, is more than just fast and easy access to all control and static functions of the device. It is also pure pleasure. Take up the Challenges of the Future ICommunication interfaces like Ethernet, Ethernet IP, Profinet, Profibus and access to the database system are the response to the requirements of Industry 4.0 concept. We have equipped our scales with a special package of dedicated functions, like an extended access control module, and complete archiving of all scale states in the Audit Trail module. Thanks to this, all pharmaceutical processes you carry out are safe and accordant with GMP, and FDA 21 Part 11 requirements. Complete Validation: IO, OQ and PQ In order to be able to install any measuring device in the pharmaceutical industry you need validation. A special equipment qualification package will guarantee a complete, documented validation for your checkweigher: Installation Qualification (IQ), Operational Qualification (OQ), Performance Qualification (PQ) – we provide all these. Proved Effectiveness With the special OEE module in E2R software, you can control the utilization rate of your machines and equipment.

DWM H2 checkweigher assures the highest quality and accuracy of weighing. It is intended for integra (more)tion with multi-track packaging machines transporting products to the line using several parallel tracks. It is possible to integrate the DWM H2 checkweigher in systems which due to the required throughput demand use of multiple checkweighers. The scale is equipped with multiple tracks integrated into one construction, the tracks are operated via one operation panel. Each of the weighing tracks is an independent measuring system equipped with a weighing module and rejecters. The weighing tracks are placed next to each other. With this, products can be picked up directly from the packaging machine. Multi-track scale throughput: tracks quantity x single track throughput of 500 pcs Integrated electronics speed up determination of settings, facilitate operation and enable generating single report for a production batch. The device features user-friendly and intuitive interface, integrated functions facilitating operation and statistics record. The scale enables precise control of pre-packaged goods in accordance with the PGC Regulation. The complex communication modules ensure full integration of the scale with production line allowing for unattended operation of the device. Connecting the scale to an IT system enables online preview of the production process, record of weighings, and generating reports providing information on weighing statistics, quantity statistics, shutdown and line malfunction. DWM H2 scale is intended for control of a single load of mass up to 7500 g (depending on the model). Scale's software enables products control to be carried out either in accordance with user requirements or the Pre-Packaged Goods Control Regulation. A 'flexible limits' module is especially intended for pharmaceutical plants. The devices feature PZH food approval certificate. Area of use: Pre-packaged goods control accordant with the regulation; Comprehensive automatic control of the production process; Supervision over dosing equipment; Verification of product packaging correctness; Weighing drugs, blisters, syrups, etc. Features: Static weighing; Checkweighing; Database of operators with various permissions; Products database; Weighings database; Reports database; +/- control; Pre-packaged goods control mode according to the regulation; Pre-packaged goods control mode according to user requirements; Autodiagnostics; Automatic correction of packaging mass; Verification of rejecter operation; Pressure control of the power supply installation; Bin overload sensor; Integration with feeders; Compatibility with PLCs; Reports; Reports export to PDF files; Control of products transport; Product dimensions control; Smooth regulation of conveyors speed;. Software The scale is equipped with industry computer and Windows Embedded operating system. With such a solution, interaction of the operator and the device is intuitive and uncomplicated. The database module is based on Microsoft SQL Server, which guarantees stable and secure record of data generated by the scale and easy connection of the database with customer's IT system. Protection of data and weighing records is carried out by means of simultaneous record on two separate storage media. All driver elements of the scale, such as drives, rejecters, emergency buttons, signalling devices are supervised by the real-time computing (RTC) guaranteeing fault-free operation and immediate reaction to incoming control system signals. Checkweigher enables data exchange via Ethernet network. Implemented communication protocol facilitates automatic sending of weighing records, databases update, determining weighing settings and visualization of the checkweigher online operation. Models: Separate rejecters for 'too light' and 'too heavy' products, Rejecter in a form of a swing conveyor, Optical and acoustic signalling device, Feeder operation in the feedback system, Printers and labeller operation, Two USB ports, Profibus operation, Program for weighings archiving. For more information, please contact us: phone +48 48 38 66 234 or e-mail: [email protected]
