Nitto Kohki VP0625 Vacuum Pump

Technical features Flow rate 0.2-1.3 l / min Suction (max.) 3 mWg Operating pressure (max.) 4 bar (r (more)el.) Permitted fluid temperature 5-80°C Maximum permissible viscosity 150 cSt FFKM valve material Membrane material PTFE coating Pump head material PTFE, PP, PVDF Applications Transfer of liquids Qualitative characteristics Small footprint Simple and intuitive use Manual control Self-priming, it can run dry Splash-proof with IP65 protection rating Available with different material configurations for chemical resistance Maintenance free Pump head materials: PP, PVDF, PTFE Membrane material: PTFE coating Valve material: FFKM Simriz® VERSIONS S (standard): the flow rate can only be set manually, using the knob on the upper side, as shown in the photo. RC (remote control): the range can be controlled remotely, such as from a PC, including a fault alarm; a connection cable will be supplied. Supplied with fittings for 8 mm internal diameter tube. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

The EM range of oil‑sealed rotary pumps – renowned for their high ultimate vacuum, rapid pumping spe (more)ed, quiet operation and ability to handle vapour – have become the industry standard for laboratory and light industrial applications. Displacement (50Hz): 20.5 m3/h Displacement (60Hz): 25.0 m3/h Speed (50 Hz): 17.0 m3/h Speed (60Hz): 20.4 m3/h Nominal rotation speed (50Hz): 1440 rpm Nominal rotation speed (60Hz): 1720 rpm Ultimate vacuum (total pressure) without gas purge: 1 x 10-3 mbar Ultimate vacuum (total pressure) with gas purge: 1.5 x 10-2 mbar Max permitted pressure at outlet: 0.5 bar Max inlet pressure for water vapour: 20 mbar Max water vapour pumping rate: 0.3 kg/h Oil capacity: 0.75 – 1.05 l

Leybold OERLIKON TURBOVAC WIDE RANGE Turbo Pump Type TW 690MS 800052V0001 This was removed from a un (more)iversity lab where it was surplus to requirements. It is in good cosmetic condition, we are unable to test it further at our facility. The fan blades move smoothly manually.

KNF IP65 UFEM 1.10 KT.18S2 Liquid Pump KNF SIMDOS diaphragm pumps offer a variety of options to sui (more)t most laboratory liquid metering and dosing needs. The UFEM 1.10 KT.18S2 version has a liquid transfer flow rate of 1 – 100 mL/min and discreet dosing volumes of 1– 999 mL. It is constructed with the following chemically-resistant flow path materials: PP head, PTFE covered diaphragm, and FFKM valves. The easy-to-read display combined with a touch control knob makes programming and access of all functions very intuitive. All SIMDOS pumps are simple and intuitive to operate, compact, and quiet, making them a welcome addition to any business or academic lab. They are effective against pressures of up to 85 psig and transfer viscous media up to 500 centistokes (reduced flow rate above 150 cSt). The integrated software permits the transfer parameters to be modified for a range of different viscosities at the touch of a button. With a durable and IP65 splash-proof design, these pumps are maintenance free, and provide trouble-free ±2% accuracy and ±1% repeatability performance. SIMDOS 10 pumps are self-priming up to 9.8 feet of water, and can run dry indefinitely without damage. Also, unlike peristaltic pumps, there are no troublesome tubing to break or fatigue. INCLUDED: The KNF IP65 UFEM 1.10 KT.18S2 Liquid Pump includes: - Power Cord - Operator's Guide - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

IKA VACSTAR Digital Vacuum Pump Maximum Flow Rate 22 L/min (1.32 m^3/h) Final Pressure 2 mbar Sucti (more)on Levels 4 Features - High suction capacity of the four-chamber membrane vacuum pump - Requires low space due to compact design - High serviceability features for ease of maintenance - Parameters are adjustable via a rotary-push button - Digital display indicates current rpm (rotations per minute) - Automated processes managed by the optional vacuum controller VC 10 - Includes analogue cable for pump-controller connection - VSE 1 vacuum safety emission recommended for additional security: Prevents solvent release into the environment - Ideal for dry and oil-free applications in laboratory settings - Membranes feature high chemical resistance The four-chamber membrane vacuum pump convinces with its high suction capacity, low space requirement and high serviceability. The setting of the parameters is carried out through a rotary-push button over a digital display showing current rpm. Automated processes are controlled with the vacuum controller VC 10, which is available as an accessory. An analogue cable which is required for connecting pump and controller is included in the delivery of the pump. Additionally it is recommended to use the VSE 1 vacuum safety emmission. It prevents that solvents are released into ambient air. The Vacstar digital is used for dry and oil-free applications in the laboratory. The membranes of the pump are particularly chemical resistant. INCLUDED: The IKA VACSTAR Digital Vacuum Pump includes: - Vacuum hose (1 m) - Silencer - USB A-B Cable - Connecting Cable - Power Cord - Operator's Guide - Manufacturer's Documentation - 2 Year Manufacturer Warranty ( + Additional Free 1 Year Warranty Extension with IKA Registration) IKA VACSTAR Digital Vacuum Pump Specifications Pump rate max. (50/60Hz)1.32 m³/hPump rate max. (50/60Hz)22 l/minFinal pressure without gas ballast2 mbarSuction levels4Cylinder4Connection diameter suction side8 mmConnection diameter pressure side8 mmInput pressure2 - 1030 mbarTwo-point controlyesAnalog speed vacuum controlyesSpeed controlTurning knob Speed range285 - 1200 rpm DisplayLED Noise at low. pressure54 dB(A)Material in contact with mediumAl2O3; PTFE; FFPM; PPS; NBRHousing materialalu-cast coating / thermoplastic polymerMode automaticyesMode manualyesMode pump %yesMode programyesDimensions (W x H x D)150 x 375 x 370 mmWeight11.5 kgPermissible ambient temperature5 - 40 °CPermissible ambient conditions80% (up to 31°C), decreasing linearly to max. 50 (@40°C)Protection class according to DIN EN 60529IP 20RS 232 interfaceyesUSB interfaceyesVoltage100 - 240 VFrequency50/60 HzPower input130 WPower input standby3 W

Edwards E2M28 Vacuum Pump Ultimate Vacuum 1 x 10-3 mbar / 7.5 x 10-4 Torr Inlet Connection NW25 Fl (more)ange Displacement 38.9 m3h-1 / 22.3 ft 3min-1 Features - Quiet operation ensures a more comfortable working environment, ideal for spaces where noise reduction is crucial. - Features a compact, freestanding design for flexible use across various settings without requiring additional support. - Proven reliable performance in a wide range of laboratory and industrial applications, showcasing its versatility and dependability. - Incorporates a gas ballast valve, essential for effectively pumping vapor without condensation inside the vacuum pump. - Built-in motor protection systems include cooling by an external fan and thermal overload protection that automatically resets. - Maintenance is simplified with an O-ring sealed sight glass for easy monitoring of oil levels and conditions at a glance. - Designed for effortless oil changes, featuring an oil drain port at the end of the oil box for convenient oil removal. - Facilitates easy oil top-ups through a large filling port and a recessed top, minimizing spills and maintenance time. The EM range of oil‑sealed rotary pumps – renowned for their high ultimate vacuum, rapid pumping speed, quiet operation and ability to handle vapour – have become the industry standard for laboratory and light industrial applications. The pump is a freestanding unit with the drive provided through a flexible coupling by either a single‑phase or three‑phase (four pole) motor.Click Here to View Product Video INCLUDED: The Edwards E2M28 Rotary Vane Vacuum Pump includes: - Edwards Ultragrade 19 Oil - Power Cord - Operator's Manual - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Block: Gold anodized 96 well block Max Heating Rate: 3.5°C/sec Max Cooling Rate: 2.5°C/sec Avg Heati (more)ng Rate: 3.0°C/sec Avg Cooling Rate: 2.0°C/sec Temperature Uniformity 55°C: ± 0.20°C within 15 sec Temperature Uniformity 70°C: ± 0.30°C within 15 sec Temperature Uniformity 95°C: ± 0.60°C within 15 sec Block Temperature Range: 3°C to 99°C Gradient Temperature Range 20 to 99 °C Control Accuracy +/- 0.1 °C Block Format: 96 well (70µl) Memory: 350 typical programs in up to 30 user directories (password protected) Auto restart after power failure: Yes Lid Temperature Range: 30 to 99°C Dimensions (WxDxH): 280 x 380 x 240 mm Weight: 13.0 kg

CO₂ Control: 0,2 – 20 % Control accuracy in space: ±0,2 % Recovery rate: <=0,8 %/min Required CO₂ pr (more)essure: 0,3 – 0,7 bar Operation temperature: 60°C Temperature deviations in space (at 37°C): ≤0,25°C Temperature deviations in time (at 37°C): ≤0,1°C Relative humidity humidity dish volume: 1,5 L Humidity level (at 37°C, 5°C CO₂): 95% RH Volume: 190 L Internal dimensions (WxDxH): 632 x 440 x 686 mm Dimensions (WxDxH): 765 x 734 x 862 mm Weight: 94.5 kg Equipped with segmented internal door

Particle Plus Handheld 8303 This item was removed from a university lab where it was surplus to requ (more)irements. The unit powers up and is in good cosmetic condition, we are unable to test it further at our facility. Item includes the following: Certificate of calibrationPower Supply 15V ~2amp 100-240VACCarry caseTripod and plateUSB Cable 6'&nbsp;

This item has just arrived in our stock. Please enquire for further details.

HX7 scale&rsquo;s multi functions Many functions, many interfaces and great robustness (IP66/ IP68)  (more)mean many possibilities for you to use this advanced scale. Tomorrow you can apply it to a different process than today &ndash; that&rsquo;s the multifunctionality. That&rsquo;s the saving! Use the potential Barcode scanners, receipt printers, label printers, external displays, control buttons, light signalling towers and other controlling/ signalling devices &ndash; thanks to multipurpose software, HX7 scale can work with all of them. You can easily connect them thanks to the fact that the balance is equipped with interfaces: RS232, RS485, USB, Ethernet, 4 IN/ 4 OUT. Optionally, the balance can be equipped with 12 IN/ 12 OUT and analog output module. You can find all accessories in our regular offer. And if you have questions about compatibility, our experts will help you. Easy and pleasant Simple and convenient operation with a 7-inch color display. Perfectly visible messages additionally supported by bargraph. The top part of the operation panel features a bar graph consisting of 9 red and green diode fields. The bar graph is a graphic visualisation informing the user on a current net weight of a product presented with reference to the scale range or declared min and max thresholds. The bracket allows the terminal to be placed on any flat horizontal surface or screwed to the wall with adjustable angle. The power of steel The use of stainless steel guarantees you a long life for the scale. It is not afraid of contact with moist objects or accidental splashes. The construction of the scale is made of powder-coated steel with a stainless steel weighing pan. This guarantees you work for many years, and what&rsquo;s more, powder-coated steel is more environmentally friendly than traditional painting methods. Not just weighing But also parts counting, dosing, percent weighing and formulations. The power of HX7&rsquo;s working mods. Do you need ALIBI? There you have it. ALIBI memory is like a black box of a scale. It records all measurements taken on the device. The ALIBI memory cannot be modified or erased. Referring to stored weighings you can generate weighing reports, formulation reports and reports on performed control processes. Single weighing is stored in the ALIBI memory as long as it is specified by a Weighing Storage Period (days) parameter.
