Vacuum gauges

Varian CC2C Module Model-Sentorr This item was removed from a university lab where it was surplus to (more) requirements. It is in good cosmetic condition and powers on, we are unable to conduct further testing at our facility. Specifications:- Model: Sentorr - Serial No.: LID30427

Edwards D39590000 ADC Active Digital Vacuum Gauge Controller, Standard Version, 1 Gauge Active Gauge (more) Compatibility APG Series (including 200, legacy APG, and APGX-H) & WRG Series (including 200 and legacy WRG) Display High brightness green LED display 12mm (0.47 in. high) Choice of Units mbar, Torr, Pa, Volts Features - Simply plug in the mains supply, connect the gauge, and the ADC displays the measured pressure - Supports Edwards gauges with a total measuring range of 2000 to 1 x 10⁻⁹ mbar (1500 to 7.5 x 10⁻¹⁰ Torr) - The ADC and Edwards gauges address a broad spectrum of laboratory and industrial applications - Bright LED display gives clear long distance readability - Displays in mbar, Torr, Pascal or Volts - Compact with small 1/8 DIN enclosure, may be panel or bench mounted - Push-button control makes operation highly intuitive The Edwards D39590000 ADC Active Digital Vacuum Gauge Controller is a streamlined and efficient tool for vacuum measurement, suitable for a range of laboratory and industrial applications. This compact controller features a bright LED display, providing clear readability from a distance, and simple push-button controls for ease of use. It is designed to automatically recognize and integrate with compatible Edwards gauges such as the APG200, WRG200, AIM200, and ASG2 ranges, loading the appropriate look-up table and displaying the pressure in commonly used units like mbar, Torr, Pascal, or Volts. The standard version of the ADC can display the pressure measured by a single active gauge. Its compact size allows for flexibility in installation, fitting easily into a small 1/8 DIN enclosure that can be mounted on a panel or positioned on a bench. To operate, simply connect the mains supply and attach the gauge to immediately begin pressure monitoring, making it a cost-effective choice for managing process vacuum. INCLUDED: The Edwards D39590000 ADC Active Digital Vacuum Gauge Controller, Standard Version, 1 Gauge includes: - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

VACUUBRAND VACUU-VIEW Vacuum Gauge Upper Measuring Limit 1100 mbar/hPa (825 torr) Lower Measuring L (more)imit 0.1 mbar/hPa (0.075 torr) Vacuum Sensors Integrated Features - Highest precision in the range from atmosphere down to 0.1 mbar, perfect gauge for all rough vacuum applications - Compact design with integrated sensor for useful setup in laboratory and process - Chemically resistant ceramic diaphragm sensor, highly reliable at harsh laboratory conditions even in case of aggressive chemicals - Illuminated display, easy to read - Display with menu driven handling easy to use e.g. for unit setting For the monitoring of your vacuum processes in the rough vacuum range, the new vacuum gauges VACUU·VIEW are perfect! Chemically resistant ceramic diaphragm sensor for measurement in the rough vacuum range. VACUU·VIEW provides gas-independent pressure indication with precise capacitive readout.INCLUDED: The VACUUBRAND VACUU-VIEW Vacuum Gauge includes: - Kit Hose Nozzle DN 6/10 mm - Power Supply - Operator's Manual - Manufacturer's Documentation - 2 Year Manufacturer's Warranty

VACUUBRAND VACUU-VIEW Extended Vacuum Gauge Upper Measuring Limit 1100 mbar/hPa (825 torr) Lower Me (more)asuring Limit 1 x 10-3 mbar/hPa (1 x 10-3 torr) Vacuum Sensors Integrated Features - Precision and chemical resistance in an exceptionally wide range from atmosphere down to 10-3 mbar, one gauge only for both rough and fine vacuum - Compact design with integrated sensors for useful setup in laboratory and process - The chemical resistant combination of ceramic diaphragm sensor and ceramic jacketed Pirani sensor ensures a long product life even with aggressive chemicals - Illuminated display, easy to read - Display with menu driven handling, easy to use e.g. for unit settings For the monitoring of your vacuum processes in the rough and fine vacuum range, the new vacuum gauges VACUU·VIEW extended are perfect! The heavy duty combination of ceramic diaphragm sensor and ceramic jacketed Pirani sensor ensures reliable readings in the wide range from atmosphere down to 10-3 mbar.INCLUDED: The VACUUBRAND VACUU-VIEW Extended Vacuum Gauge includes: - Kit Hose Nozzle DN 6/10 mm - Power Supply - Operator's Manual - Manufacturer's Documentation - 2 Year Manufacturer's Warranty

VACUUBRAND DVR 2pro Vacuum Gauge Upper Measuring Limit 1060 mbar/hPa (795 torr) Lower Measuring Lim (more)it 1 mbar/hPa (1 torr) Vacuum Sensors Integrated Features - Improved functionality within the navigation menu helps to save energy and to increase the life cycle of the battery - Large, graphical analog display with digital measuring values alows to detect tendencies and makes it easier to readout precisely - Pressure unit user-selectable in mbar, hPa or Torr prevents unnecessary conversions - Different vacuum connections and the additional support rod allow the use in almost every laboratory application - Chemical resistant materials for wetted parts together with the capacitive ceramic diaphragm pressure sensor provide excellent long-term stability and accuracy The DVR 2pro is a fully electronic, versatile vacuum gauge for the measuring range from atmospheric pressure to 1 mbar. All wetted parts are made from enhanced chemical resistant material which allows the use under very rough laboratory conditions. The high accuracy and the large graphical display from the DVR 2 have also been carried forward for the “pro” version. One of the main enhancements is the power supply with a normal 9 V Alkaline battery. The new battery slot at the back of the gauge allows for easy replacement of the battery. A wider range of connection parts provide a great range of connection flexibility for laboratory use.INCLUDED: The VACUUBRAND DVR 2pro Vacuum Gauge includes: - 9V Alkali-Manganese Battery - Support Rod and Connecting Parts - Operator's Manual - Manufacturer's Documentation - 2 Year Manufacturer's Warranty

VACUUBRAND DCP 3000 Vacuum Gauge with VSP 3000 Head Upper Measuring Limit 100 mbar/hPa (750 Torr) L (more)ower Measuring Limit 1 x 10-3 mbar/hPa (1 x 10-3 torr) Interface RS232C Features - Vacuum measuring device for connecting external vacuum sensors for measurements directly on the system - Flexible and expandable with up to eight sensors, four of the types VSK 3000 / VACUU·VIEW (Atm. to 0.1 mbar) and VSP 3000 / VACUU·VIEW extended (Atm. up to 10-3 mbar) - Relative pressure measurement with reference sensors (VSK 3000) and data logger function with up to 32000 measuring points (RS 232C) - Robust plastic / ceramic vacuum sensor VSP 3000 with high chemical resistance - VSP 3000 with a wide measuring range from atmospheric pressure to fine vacuum (10-3 mbar) thanks to the thermal conductivity measuring principle The fully electronic vacuum measuring device DCP 3000 is both versatile and decisive with its mechanical robustness, measuring accuracy and reliability. The large, illuminated display provides the measured value display of all connected sensors via an easy-to-use rotary control. Up to eight vacuum sensors (four of each type VSK 3000 / VACUU·VIEW and VSP 3000 / VACUU·VIEW extended) can be connected to the DCP 3000. The measurement can be carried out directly on the application. The DCP 3000 enables a relative pressure measurement (reference sensor VSK 3000) as well as working with pressure-dependent switching points by specifying switch-on and switch-off points on an external valve. The vacuum measuring device can also be used as a data logger with up to 32,000 measuring points. The data is read out via the serial interface (RS 232C). The vacuum sensor VSP 3000 is based on the gas thermal conductivity (Pirani) principle for the wide measuring range from atmospheric pressure to 10-3 mbar. Thanks to its structure made of chemically resistant plastics (PBT, PUR) and ceramics, it offers significantly higher chemical resistance and robustness compared to conventional Pirani sensors with fine wire metal filaments. Please also note our alternative product VACUU·VIEW extended.INCLUDED: The VACUUBRAND DCP 3000 Vacuum Gauge with VSP 3000 Head includes: - Power Supply - Operator's Manual - Manufacturer's Documentation - 2 Year Manufacturer's Warranty

VACUUBRAND DCP 3000 Vacuum Gauge with VSK 3000 Head Upper Measuring Limit 1080 mbar/hPa (810 Torr)  (more)Lower Measuring Limit 0.1 mbar/hPa (0.1 torr) Interface RS232C Features - Vacuum measuring device for connecting external vacuum sensors for measurements directly on the system - Flexible and expandable with up to eight sensors, four of the types VSK 3000 / VACUU·VIEW (Atm. to 0.1 mbar) and VSP 3000 / VACUU·VIEW extended (Atm. up to 10-3 mbar) - Relative pressure measurement with reference sensors (VSK 3000) and data logger function with up to 32000 measuring points (RS 232C) - Capacitive ceramic diaphragm vacuum sensor VSK 3000 made of aluminum oxide with high chemical resistance, gas type independent absolute pressure Measurement - Excellent measurement accuracy, temperature and long-term stability The fully electronic vacuum measuring device DCP 3000 is both versatile and decisive with its mechanical robustness, measuring accuracy and reliability. The large, illuminated display provides the measured value display of all connected sensors via an easy-to-use rotary control. Up to eight vacuum sensors (four of each type VSK 3000 / VACUU·VIEW and VSP 3000 / VACUU·VIEW extended) can be connected to the DCP 3000. The measurement can be carried out directly on the application. The DCP 3000 enables a relative pressure measurement (reference sensor VSK 3000) as well as working with pressure-dependent switching points by specifying switch-on and switch-off points on an external valve. The vacuum measuring device can also be used as a data logger with up to 32,000 measuring points. The data is read out via the serial interface (RS 232C). The ceramic membrane vacuum sensor VSK 3000 is suitable for the measuring range from atmospheric pressure to 0.1 mbar. It measures regardless of the gas type and is highly chemically resistant, which means that the measurement can be carried out directly at the process, with excellent measurement accuracy and high long-term and temperature stability. Please also note our alternative product VACUU·VIEW.INCLUDED: The VACUUBRAND DCP 3000 Vacuum Gauge with VSK 3000 Head includes: - Kit Hose Nozzle DN 6/10 mm - Power Supply - Operator's Manual - Manufacturer's Documentation - 2 Year Manufacturer's Warranty
