Thermo Scientific Lab Vision PT Module incl. Pump Kit

Technical features Flow rate 0.2-1.3 l / min Suction (max.) 3 mWg Operating pressure (max.) 4 bar (r (more)el.) Permitted fluid temperature 5-80°C Maximum permissible viscosity 150 cSt FFKM valve material Membrane material PTFE coating Pump head material PTFE, PP, PVDF Applications Transfer of liquids Qualitative characteristics Small footprint Simple and intuitive use Manual control Self-priming, it can run dry Splash-proof with IP65 protection rating Available with different material configurations for chemical resistance Maintenance free Pump head materials: PP, PVDF, PTFE Membrane material: PTFE coating Valve material: FFKM Simriz® VERSIONS S (standard): the flow rate can only be set manually, using the knob on the upper side, as shown in the photo. RC (remote control): the range can be controlled remotely, such as from a PC, including a fault alarm; a connection cable will be supplied. Supplied with fittings for 8 mm internal diameter tube. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Diaphragm vacuum pump KNF N022AN.18 Final pressure/ultimate vacuum (abs.) (mbar): 181 mbar (see phot (more)o) Model: N022AN18 Technical specifications: Voltage: 230 V, 50 Hz Current: 0.7 A Power: 100 W Max. pressure: 4 Bar Pump flow rate: 15 l / min External dimensions (W) x (D) x (H): 28 x 20 x 23 cm Equipment tested Year of manufacture: 2007

Pfeiffer HiCube 300 Neo, 100 CFF, MVP 030-3 Turbo Pumping Station Final Pressure 1x10-8 hPa / 7.5x (more)10-9 Torr / 1 x 10-8 mbar Backing Pump Speed 1.8 m³/h / 1.06 cfm / 30 l/min Pumping Speed for N2 260 l/s Features - Compact series of pumping stations for all high vacuum applications - Simple operation with 7in. touch display - Remote control via web server available - Compatible with a wide variety of applications - Reliable and robust The Pfeiffer HiCube 300 Neo, 100 CFF, MVP 030-3 Turbo Pumping Station is a compact, high-performance solution designed for all high vacuum applications. Featuring a user-friendly 7-inch touch display, it offers simple operation and remote control capabilities via a web server, allowing for versatile use across various demanding environments. With a final pressure of 1 x 10⁻⁸ mbar and a pumping speed of 260 l/s for nitrogen, this turbo pumping station ensures efficient and reliable vacuum generation. Equipped with the HiPace 300 turbopump and an MVP 030-3 backing pump, this unit provides robust performance with a quiet emission sound level of ≤50 dB(A). The air-cooled forced convection system maintains optimal operating conditions, and the unit is globally compatible with an input voltage range of 100-240 V AC. Weighing 22.5 kg, it is both sturdy and adaptable, making it suitable for a variety of applications in lab and industrial settings. INCLUDED: The Pfeiffer HiCube 300 Neo, 100 CFF, MVP 030-3 Turbo Pumping Station includes: - Backing Pump - Pfeiffer MVP 030-3 Diaphragm Pump - Protective Cap for High Vacuum Flange - Power Cord - Operator's Manual - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

KNF IP65 UFEM 1.10 ST.18RCP2 Liquid PumpKNF SIMDOS diaphragm pumps offer a variety of options to sui (more)t most laboratory liquid metering and dosing needs. The UFEM 1.10 ST.18RCP2 version has a liquid transfer flow rate of 1 – 100 mL/min and discreet dosing volumes of 1 – 999 mL. It is constructed with the following chemically-resistant flow path materials: stainless steel head, PTFE covered diaphragm, and FFKM valves. The easy-to-read display combined with a touch control knob makes programming and access of all functions very intuitive. Besides onboard manual control, this pump offers analog control, start/stop and reset/prime TTL logic control, output signal fault alarm, and RS 232 PC control. A RC control interface cable and RS 232 cable with D-Sub 9 connector are included. A foot switch for start and stop impulses is available. All SIMDOS pumps are simple and intuitive to operate, compact, and quiet, making them a welcome addition to any business or academic lab. They are effective against pressures of up to 85 psig and transfer viscous media up to 500 centistokes (reduced flow rate above 150 cSt). The integrated software permits the transfer parameters to be modified for a range of different viscosities at the touch of a button. With a durable and IP65 splash-proof design, these pumps are maintenance free, and provide trouble-free ±2% accuracy and ±1% repeatability performance. SIMDOS 10 pumps are self-priming up to 9.8 feet of water, and can run dry indefinitely without damage. Also, unlike peristaltic pumps, there are no troublesome tubing to break or fatigue. INCLUDED: The KNF IP65 UFEM 1.10 ST.18RCP2 Liquid Pump includes: - Power Cord - Operator's Guide - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Pumpdrive model 7544-20 (speed 20 rpm) Housing material: Polysulfone Rotor material: Cold-rolled ste (more)el Rollers: Three; cold-rolled steel Occlusion: Average, fixed mL/rev: Depends on tubing selected Accepted tubing: L/S 13, L/S 14, L/S 16, L/S 25, L/S 17, L/S 18 Min flow rate: 0.06 mL/min (at 1 rpm with L/S 13 tubing) Max flow rate: 2300 mL/min (at 600 rpm with L/S 18 tubing)

Displacement (50Hz): 504 l/min Speed (50 Hz): 25 m3/h Nominal rotation speed (50Hz): 1500 rpm Ultima (more)te vacuum (partial): 10-4 mbar Ultimate vacuum (total pressure) without gas ballast: 2 x 10-3 mbar Ultimate vacuum (total pressure) with gas ballast: 1 x 10-2 mbar Max permitted pressure at outlet: 0.5 bar Max inlet pressure for water vapour: 30 mbar Max water vapour pumping rate: 0.55 kg/h Oil capacity: 0.5 – 1.0 l

Arctiko SUF 500 -86°C Ultra Low Chest Freezer Temperature Setting -40°C / -86°C Volume 13.0 cu. ft.  (more)(368L) Cooling System Single System / Static Features - Single compressor technology that ensures easy maintenance, lower heat dissipation, and low energy consumption - Newly developed noise reduction technology reduces noise level drastically for a more pleasant work environment - Filter less construction prevents dust from blocking the airflow which reduces the unit’s ability to dissipate heat effectively, minimizing maintenance procedure - Capable of reaching -80°C in only 190 minutes - The user friendly XR30CX controller is standard and includes different alarms such as visual, acoustic, power failure, and more - An insulated inner door is featured for providing better recovery time after door openings and optimal temperature stability - Features a premade access port, making it easier to monitor or inspect the unit with external probes - 100% HCFC & CFC free The Arctiko SUF 500 -86°C Ultra Low Chest Freezer is a high capacity, ultra low temperature chest freezer designed to work in high traffic labs. The single compressor technology ensures a quick pulldown, fast recovery time, and high temperature uniformity throughout the compartment, even with multiple door openings. The SUF 500 is capable of reaching -80°C in only 190 minutes and the single compressor technology is specially designed to reduce the number of mechanical components that generate unnecessary heat and noise. The SUF 500 has optimized internal storage for the best overlook. With the included stackable basket and the optional stainless steel front rack storage system, samples will be easily accessible at any time. This freezer also features a premade access port, making it easier to monitor or inspect the unit with external probes. This freezer also features filter less construction, which makes cleaning unnecessary. The evaporator coils are spaced so far apart that dust will not be trapped and obstruct the airflow. With this unique construction, the dust intake is minimal, which eliminates the need for filters entirely saving on maintenance time and cost. INCLUDED: The Arctiko SUF 500 -86°C Ultra Low Chest Freezer includes: - Key for Door Lock - Stackable Basket - Power Cord - Operator's Manual - 2 Year Manufacturer's Warranty

Biorad MINI-SUB CELL GT electrophoresis cuvette. Includes cover and power cables, 1 gel tray, 1 limi (more)ter for the formation of gels and 2 combs of 8 and 15 wells, respectively. User manual. Biorad MINI-SUB CELL GT is a compact and versatile gel electrophoresis system that allows efficient analysis of DNA and protein samples. With its ergonomic design and small size, this equipment is ideal for laboratories with limited space. MINI-SUB CELL GT features a transparent acrylic gel chamber that allows easy visualization of samples during the electrophoresis process. Furthermore, its hermetic sealing system ensures accurate and reproducible migration of samples. Accommodating up to 2 standard size gels, this system offers flexibility in the number of samples that can be analyzed simultaneously. Biorad MINI-SUB CELL GT is a reliable and efficient tool for the separation and analysis of nucleic acids and proteins in the laboratory.

Memmert UN30 Natural Convection Oven 32L, 115V Temperature Range Ambient +5°C to 300°C Convection T (more)ype Natural Convection Chamber Volume 32L Features - 32L chamber volume accommodates various sample sizes, enhancing lab versatility - Precise temperature control from +5°C above ambient to 300°C for sensitive applications - Ergonomic PID controller with high-definition TFT display for intuitive adjustments - Durable stainless steel interior and exterior, corrosion-resistant for rigorous use - Natural convection ensures uniform heat distribution for delicate samples - Pre-heated fresh air admixture with adjustable air flap for temperature uniformity - Adaptive settings include programmable temperature, timer, and setpoint wait for workflow optimization - AtmoCONTROL software for data logging and remote monitoring via Ethernet - Easy-to-clean stainless steel interior with reinforced ribbing, ideal for frequent use The Memmert UN30 Natural Convection Oven 32L, 115V delivers precise temperature control from Ambient +5°C to 300°C, making it ideal for a variety of sensitive applications. Featuring an ergonomic digital PID controller with a high-definition TFT display, this oven offers intuitive settings and rapid access to temperature adjustments. Built for rigorous lab environments, its durable stainless steel construction resists corrosion, while the natural convection system ensures even, consistent heating distribution across all samples. Fully adjustable safety controls, including a built-in overtemperature monitor, provide added protection and peace of mind. With an easy-to-clean interior and robust stainless-steel shelving, the UN55 maximizes efficiency in daily operations, delivering reliable performance for years to come. INCLUDED: The Memmert UN30 Natural Convection Oven 32L, 115V includes: - 1 x Stainless Steel Grid - Tilt Protection Wall Bracket - Calibration Certificate - Power Cord - Operator's Manual - Manufacturer's Documentation - 3 Year Manufacturer's Warranty

IKA RT 5 Multiposition Magnetic Hotplate Stirrer Stirring Positions 5 Positions Speed Range 0 to 1, (more)000 RPM Heating Temp. Range Room Temp. to 120°C Features - Combines RCT basic magnetic stirrer with ETS-D5 contact thermometer. - Safety circuit limits max. temp. independently of set point. - Heating function switches off if temp. limit exceeded. - Set safety temp. of heating plate remains available. - Hotplate temp. displayed on RCT. - Contact thermometer display can be placed at eye level. The IKA RT 5 Multiposition Magnetic Hotplate Stirrer is a 5-position digital stirrer designed for synchronous heating and stirring. It combines the RCT basic magnetic stirrer with the ETS-D5 contact thermometer, featuring a safety circuit to limit maximum temperature independently of the set point. The heating function switches off if the temperature limit is exceeded, ensuring safety. With magnetic coil technology, it provides noiseless and consistent stirring up to 1000 rpm, and its surface temperature is adjustable up to 120 °C. It supports a maximum stirring quantity of 0.4 liters per position (H2O). The stirrer has a durable aluminum alloy set-up plate measuring 110 x 495 mm, and the unit measures 120 x 60 x 610 mm, weighing 4 kg. Suitable for continuous operation, it includes an adjustable safety circuit (50 - 150 °C), operates within 5 - 40 °C, and has an IP 40 protection class.

Waters Lambda-Max Model 481 LC Spectrophotometer
