Edwards D39590000 ADC Active Digital Vacuum Gauge Controller, Standard Version, 1 Gauge
Edwards D39590000 ADC Active Digital Vacuum Gauge Controller, Standard Version, 1 Gauge Active Gauge (more) Compatibility APG Series (including 200, legacy APG, and APGX-H) & WRG Series (including 200 and legacy WRG) Display High brightness green LED display 12mm (0.47 in. high) Choice of Units mbar, Torr, Pa, Volts Features - Simply plug in the mains supply, connect the gauge, and the ADC displays the measured pressure - Supports Edwards gauges with a total measuring range of 2000 to 1 x 10⁻⁹ mbar (1500 to 7.5 x 10⁻¹⁰ Torr) - The ADC and Edwards gauges address a broad spectrum of laboratory and industrial applications - Bright LED display gives clear long distance readability - Displays in mbar, Torr, Pascal or Volts - Compact with small 1/8 DIN enclosure, may be panel or bench mounted - Push-button control makes operation highly intuitive The Edwards D39590000 ADC Active Digital Vacuum Gauge Controller is a streamlined and efficient tool for vacuum measurement, suitable for a range of laboratory and industrial applications. This compact controller features a bright LED display, providing clear readability from a distance, and simple push-button controls for ease of use. It is designed to automatically recognize and integrate with compatible Edwards gauges such as the APG200, WRG200, AIM200, and ASG2 ranges, loading the appropriate look-up table and displaying the pressure in commonly used units like mbar, Torr, Pascal, or Volts. The standard version of the ADC can display the pressure measured by a single active gauge. Its compact size allows for flexibility in installation, fitting easily into a small 1/8 DIN enclosure that can be mounted on a panel or positioned on a bench. To operate, simply connect the mains supply and attach the gauge to immediately begin pressure monitoring, making it a cost-effective choice for managing process vacuum. INCLUDED: The Edwards D39590000 ADC Active Digital Vacuum Gauge Controller, Standard Version, 1 Gauge includes: - Manufacturer's Documentation - 1 Year Manufacturer's Warranty
$943.00 ex VAT
