Edwards T-Station 300 Dry Turbo Station ISO100 mXDS3s, 115V
Edwards T-Station 300 Dry Turbo Station ISO100 mXDS3s, 115V
Ultimate Pressure
6.000 × 10⁻⁸
Pumping Speed for H2
280 ls-1
Inlet Connection
DN 63 ISO-K
Features
- Compact, powerful and reliable performance… wherever you need it
- NOW also with the latest mXDS3s scroll pumps providing the best efficiency and best performance of the turbomolecular pump.
- Push button vacuum stations ready to go - Designed to be used straight from the box our T-Station's do not require systemisation or complex configuration.
- User servicable - The nEXT85 and nEXT300 turbomolecular pumps, mXDS3 dry scroll pump, XDD1 dry diaphragm pump and E2M1.5 backing pump are all user serviceable
- Inlet flange options - Available with either an NW40, ISO63 or CF63 for T-Station 85 and ISO100 and CF100 for T-Station 300 inlet flange to suit your application
The Edwards Turbomolecular Pumping Stations are meticulously designed to provide a comprehensive and user-friendly vacuum solution, incorporating the latest technological advances for seamless installation and operation. These pumping stations are versatile, catering to a wide range of applications. Choose from a range of turbomolecular pumping stations, including the entry-level T-Station 85 and the higher capacity T-Station 300.Experience top-tier vacuum solutions with High Vacuum Pump Systems. Edwards offers cutting-edge technology and versatility to enhance your operations. Upgrade your vacuum system today and enjoy seamless performance in a variety of applications.The T-Station 300 builds on the existing popular T-Station 85 platform, by replacing the nEXT85H with the nEXT300 turbomolecular pump providing a solution for customers and applications that require a higher pumping speed up to 300 ls-1.
Click Here to View Product Video
INCLUDED:
The Edwards T-Station 300 Dry Turbo Station ISO100 mXDS3s, 115V includes:
- T-Station Pumping Station Base
- Edwards mXDS3s Dry Scroll Pump
- nEXT300 Turbomolecular Pump with ISO100 Inlet
- All Necessary Tubing and Cables for Turn-key Operation
- Operator's Manual
- Manufacturer's Documentation
- 1 Year Manufacturer's Warranty
| Ultimate Vacuum | <6×10⁻⁸ mbar mbar |
| Pumping Speed | 300 l/s |
| Compression ratio for N 2 | >1x10 11 mbar |
| Backing pump speed 50Hz | 3 m3h |
| Inlet Flange | DN 63 ISO-K |
| Exhaust flange | 1/8 BSP for 6x8mm |
| Noise level db(A) | <56 ± 3dB(A) Declared dual number noise emission values in |
| Leak tightness | <1x10 6(mbar l/s) |
| Operating temperature range | 12 to 40°C |
| Electrical Requirements | 1Ph 100-120V 50/60Hz |
