Centrifugation

Embossed foil keypad for simple operation Short-spin function with pre-selected rotational speed rpm (more) or rcf settings as required (from 500 rpm in steps of 100 rpm) Timer up to 99 min or continuous run Soft key for gentle acceleration and deceleration Automatic imbalance detection Equipped with a Eppendorf F-45-30-11 fixed angle rotor. Rotor has a 30x 3,75 g capacity and a max rpm of 14000. Max. rotational speed: 14,000 rpm Max. load: 30 x 2.0 ml Safe-Lock Microcentrifuge Tubes Max. density of material to be centrifuged: 1.2 g/ml Max. kinetic energy: 6,100 Nm Dimensions (HxWxD): 228 x 310 x 430 mm Weight: 17 kg

Max speed: 6000 rpm Max RCF: 2000 x g Max capacity: 6 x 1.5/2ml Dimensions: (WxHxD): 130 x 120 x 150 (more) mm Weight: 500g

Excluding rotor.

Max RCF: 20913 x g Max RCF with fixed angle rotor: 20913 x g Max RCF with swing-bucket rotor: 4500 x (more) g Max RCF with plate rotor: 3486 x g Speed: 200 – 14000 rpm Temperature range: -9 °C to 40 °C Max capacity: 4x 750 mL/4x 4 MTP Acceleration/braking ramps: 9/9 Dimensions (WxDxH): 700 x 608 x 345 mm Weight: 99 kg Equipped with: 1x Eppendorf A-4-62 Swing-out rotor (max 4000 rpm) 4x Eppendorf microplate carrier 2x Eppendorf bucket 2x Eppendorf insert (3x 50 mL falcon tube capacity)

The Concentrator plus has three main operation modes: Concentrate, centrifuge and desiccator – to co (more)ver all your application needs. Processing times are reduced by up to 20% thanks to the ability to choose between three application modes that correspond to sample solvent (aqueous, alcohol or high vapor pressure). The choice of four heating levels (ambient, 30°C, 45°C, 60°C) enables safe and efficient concentration of various samples. When working with delicate samples you also have the option to turn off the brake function. equipped with: 1x Eppendorf F45-8-17 rotor for 8 x 15 mL falcon tubes. 1x Eppendorf F45-48-11 rotor 48 x 1.5/2 mL microtubes. Vacuum: 20 mbar Fixed speed: 1400 rpm Dimensions (WxDxH): 330 x 370 x 230 mm Weight: 16,5 kg

Embossed foil keypad for simple operation Short-spin function with pre-selected rotational speed rpm (more) or rcf settings as required (from 500 rpm in steps of 100 rpm) Timer up to 99 min or continuous run Soft key for gentle acceleration and deceleration Automatic imbalance detection Equipped with a Eppendorf F-45-30-11 fixed angle rotor. Rotor has a 30x 3,75 g capacity and a max rpm of 14000. Max. rotational speed: 14,000 rpm Max. load: 30 x 2.0 ml Safe-Lock Microcentrifuge Tubes Max. density of material to be centrifuged: 1.2 g/ml Max. kinetic energy: 6,100 Nm Dimensions (HxWxD): 228 x 310 x 430 mm Weight: 17 kg

Speed settings: up to 15000 rpm (100 rpm increments) Speed display: actual rotor speed in 100 rpm in (more)crements or in RCF Time settings: up to 9 hours 59 minutes or continuous Time display: timed run (indicates time remaining) or continuous (indicates elapsed time) Temperature settings: -20°C to 40°C (1°C increments) Temperature display: chamber temperature in 1°C increments Acceleration: 10 profiles Deceleration: 10 profiles Dimensions (WxDxH): 650 x 685 x 405 mm Weight: 124 kg Equipped with:  1x Beckman Coulter TS-5-500 swing out rotor (max 5100 rpm) 4x Beckman Coulter TS-5.1-500 bucket (capacity 500 mL) 4x Beckman Coulter 368327 insert (4x 50 mL) 4x Beckman Coulter 368331 insert (12x 15 mL) 4x Beckman Coulter microplate carrier (max 4100 rpm) 1x Beckman Coulter S5700 swing out rotor (max 5700 rpm) 2x Beckman Coulter S5700 bucket (capacity 10x wellplate/1x deep well plate)

Max. speed: 30.000 rpm Speed Control: ± 50 rpm of set speed Max Capacity Volume Range: 510 mL Operat (more)ing Temperature: –20 to 40°C in 1°C increments Electrical: 208V, 60Hz, 12A Dimensions (WxDxH): 61x66x38 cm Weight: 86 kg, without rotor

See attachment for more info: 4320gramslidestainer

Speed: 500 – 12000 rpm Speed steps: 500 rpm Max. RCF = centrifugal force: 9660 G Running time: 1 to  (more)99 min Rotor equipment options: HKT rotor, angle rotor, strip rotor, adapter set Dimensions: 264 x 229 x 120 mm Mains voltage: 85-264 Volt/ 50/60 Hz/ 45 Watt Weight: 2 kg Compact micro hematocrit centrifuge with interchangeable rotors for micro vessels. The SERVOspin Smart HKT is a high speed table centrifuge for the determination of the hematocrit value. Up to now the determination of the hematocrit value (percentage by volume of cells in blood) by centrifugation as gold standard (DIN 58933-1). Equipped with a low-noise motor, the SERVOspin Smart HKT accelerates the rotor to a speed of 12.000 rpm which corresponds to a maximum RCF of 9660 G. The clear design allows intuitive handling by the user. The locking of the lid is monitored electronically and is coupled with an automatic emergency brake function. This offers maximum comfort and safety for the user. A 12-times hematocrit rotor with HKT evaluation card, a dispenser tube with 100 capillaries, a plate with sealing wax, two exchangeable rotors for mini centrifuge tubes, as well as a detailed operating manual are included in the scope of delivery. All functions at a glance • Maximum speed 12.000 min-1 (RCF 9660 G) • Simple and intuitive operation • Running time and speed adjustable • Low noise engine • Electronically monitored lid locking system

Maximum speed: 6000 rpm Maximum capacity: 6 x 1.5/2.0 mL Deceleration time: <5 seconds Dimensions: 1 (more)50 x 150 x 117 mm

Maximum speed: 4500 rpm Maximum acceleration: 4200 g Maximum capacity: 4 x 250 mL Acceleration: 9 pr (more)ogrammable ramps Braking: 9 programmable ramps Temperature range: -10°C to 40°C Program storage: 10 programs in memory Dimensions (HxWxD): 425 x 750 x 635 mm Weight: 105 kg Equipped with: CENSW12000024 Swing out rotor CENSW12000027 250 mL Bucket (4x) CENSW12000006 Insert for 9 x 15 mL conical bottom tubes (4x) Insert for 5 x 50 mL conical bottom tubes (4x)

Equipped with: 1x MSE Mistral swing out rotor

rotor 4294 with buckets 4 inserts with 26 positions each 220-240 V 50-60Hz 7,500 rpm

Maximum speed: 30000 rpm Maximum RCF: 65395 xg Maximum capacity: 6 x 250 ml Speed range: 200 – 30000 (more) rpm Temperature range: -20°C to 40°C Running time: 59 min 50 s / 10 s increments, 99 h 59 min / 1 min increments Dimensions (WxHxD): 715 x 420 x 510 mm Weight: 91 kg Equipped with: 1x Hermle 221.21 fixed angle rotor 6x Hermle 12/001 1x 50 ml falcon tube adapter 6x Hermle 13/001 4x 15 ml falcon tube adapter

Capacity: 2x Tube strip 8x 0.2 mL Speed: 6000 rpm g-force: 2000 xg Dimensions (WxHxD): 153 x 102 x 1 (more)53 mm Weight: 0,9 kg

Max capacity: 4x 400 mL Max density: 1.2 kg/dm³ Max speed: 11000 RPM Max force: 13800 RCF Max kineti (more)c energy: 35000 Nm Dimensions (WxDxH): 580 x 690 x 410 mm Weight: 55 kg Equipped with: 1x Hettich 4394 Swing out rotor (max 4000 RPM) 4x Hettich 5051 bucket 4x Hettich 5268 insert (Capacity: 5 mL, Dimensions (ØxL): 12 x 81 mm)

Maximum capacity: 4 x 100 ml Maximum density: 1.2 kg/dm3 Maximum speed: 6000 RPM Maximum force: 4186 (more) RCF Maximum kinetic energy: 3000 Nm Noise level (dependent on rotor): ≤ 65 dB(A) Dimensions (WxDxH): 368 x 437 x 261 mm Weight: 15.6 kg No rotor included

Max. Capacity: 24 x 1.5/2.2 ml Max. Speed: 14,800 rpm (min. speed: 200 rpm) Max. g-Force: 16,163 x g (more) Timer: 10 sec. up to 99 min. 59 sec, short and continuous run possible Shortest acceleration time: 13 sec Shortest deceleration time: 11 sec Noise level at max. speed: < 60 dB Dimensions (WxDxH): 212 x 266 x 176 mm Weight: 6.2 kg

Speed range: 0 to 15500 rpm in 100 rpm increments Timer: up to 9 hr 59 min or continuous Temperature (more) setting: -20°C to 40°C in 1°C increments Temperature operating range: 2°C to 40°C Acceleration: 10 profiles Deceleration: 10 profiles Dimensions (WxDxH): 460 x 707 x 370 mm Weight: 78 kg Equipped with: 1x S2096 Microtiter rotor (max 3000 rpm) 2x S2096 Carrier 1x SX4250 Swing out rotor (max 4500 rpm) 4x SX4250 Bucket 4x 392264 Lid 4x 392255 Insert (1x 250 mL capacity)| 4x 368338 Insert (4x 50 mL capacity) 4x 368331 Insert (12x 15 mL capacity)

No rotor included.

Maximum capacity: 12 L Maximum speed: 10500 rpm Mininum speed: 100 rpm Maximum kinetic energy: 279 K (more) Nm Temperature setting range:  -20°C to 40°C Minimal rotor temperature at 23°C ambient temperature: < 4°C Dimensions (HxWxD): 980 x 810 x 910 mm Weight: 420 kg Rotor is not included in scope of delivery. Please order separately! See for additional ionfo: https://www.sigma-centrifuges.co.uk/files/2011/09/Sigma-8KB-11-2010_E.pdf
