Knauer Azura P2.1L Preparative HPLC Pump
AZURA preparative HPLC pump P 2.1L covers wide flow rate range and pressure capabilities. It has bee (more)n designed for purification of mg and gram samples. The Mobile Control allows intuitive control in stand-alone operation. The integrated automatic recognition of the pump head with RFID technology allows fast adaptions of the pump for various applications. Preparative pump offers wide range of flow rates (0.1-1000 ml/min) Choice of different LC software platforms Improved electronic drive compensation Integrated compressibility compensation Integrated leak management Constant pressure operation mode Solvent delivery Pump type: Preparative HPLC pump Delivery system: double piston pump with Al²O³ pistons Pump head: 250 ml/min Pump head materials: titanium Pressure sensor materials: PEEK (Polyether ether ketone) Maximum delivery pressure: 22.5 MPa (225 bar, 3260 psi) up to 100 ml/min, 20 MPa (200 bar, 2900 psi) at 250 ml/min Flow rate range: 0.1-250 ml/min, 0.5-200 ml/min (recommended) Flow rate increment: 0.01 ml/min Flow rate accuracy: ± 2 %, measured at 5 – 50 % of flow range using ethanol/water 10:90 Flow rate precision: < 0.2 % RSD Gradient support: isocratic, upgradeable to a binary HPG system with additionalpump P 2.1L or to a binary orternary LPG system HPG: gradient accuracy: ± 2 % (5 – 95 %, measured at 5 – 50 % of flow range, water/caffeine tracer) HPG: gradient precision: 1 % RSD, based on retention time at constant room temperature LPG: gradient accuracy: ± 3 % (5 – 95 %, measured at 5 – 50 % of the flow range, water/caffeine tracer) LPG: gradient precision: 2 % RSD, based on retention time at constant room System protection: soft start, Pmin and Pmax are programmable Wetted materials: titanium,stainless steel, graphite fiber reinforced PTFE, FKM, PEEK, sapphire, aluminum oxide (Al²O³) Ambient conditions: temperature range: 10–40 °C; 50–104 °F, air humidity: below 90 % humidity (non condensing) Leak sensor: Yes Communication Control: LAN; RS-232; analog and event controlled Analog inputs: 0-10 V Analog control input: flow rate Level/event outputs: 8 event outputs (TTL, OC, relays) Programming: 19 programs + 9 links (to programs) + 1 wake up program Special features: system pump head is detected automatically using radio frequency identification (RFID) General Power supply: voltage range: 100 – 240 V, 50 – 60 Hz Dimensions: 361 x 208.2 x 523 mm (W x H x D) Weight: 19 kg
€6,750.00 ex VAT
Netherlands
