Perkin Elmer Envision 2103 Multilabel Reader
The 2103 EnVision Multilabel Plate Reader is a fast, sensitive and versatile benchtop reader that de (more)livers optimized performance in every application and for every label. The unique design features modular label-specific optical mirror modules, high energy flash lamps, and high speed detectors. Light Source: Xenon flash lamp Plate Formats: 1 to 3456 wells Temperature range: from 2°C above ambient up to 45°C (0.5 °C increments) Uniformity: ± 1°C Heating time: < 10 minutes (from ambient up to 37°C) Shaking: linear, orbital, dual orbital Dispense volume: 2-475 µL (1 µL increments) Pump speed: 100-500 µL/s Dead volume: 750 µL. With pump-back function < 50 µL using stardard tubing length and factory settings. Typical Throughput: Fi/Abs (On the fly): 96 wells – 22 s, 384 wells – 27 s, 1536 wells – 36 s Fi/Abs (10 flash): 96 wells – 32 s, 384 wells – 1 min 03 s, 1536 wells – 2 min 56 s Fluorescence polarization (30 flash): 96 wells – 37 s, 384 wells – 1 min 22 s, 1536 wells – 4 min 15 s TRF LANCE (30 flash): 96 wells – 37 s, 384 wells – 1 min 22 s, 1536 wells – 4 min 15 s TRF DELFIA (100 flash): 96 wells – 55 s, 384 wells – 2 min 32 s, 1536 wells – 8 min 52 s AlphaScreen STD: 96 wells – 1 min 32 s, 384 wells – 4 min 54 s, 1536 wells – 19 min 28 s AlphaScreen HTS: 96 wells – 51 s, 384 wells – 1 min 52 s, 1536 wells – 9 min 23 s Detection Limit: Fluorometry (Fluorescein): 96 wells (200 µL) – < 4 pM/ < 0.8 fmol/well, 384 wells (50 µL) – < 4 pM/ < 0.2 fmol/well, 1536 wells (7.5 µL) – < 20 pM/ < 0.15 fmol/well Fluorescence polarization (Fluorescein 1 nM, SD): 96 wells- < 3 mP, 384 wells – < 2 mP, 1536 wells – < 7 mP TR-Fluorometry (Europium): 96 wells (200 µL) – < 55 fM/ < 11 amol/well, 384 wells (50 µL) – < 55 fM/ < 3 amol/well, 1536 wells (6.6 µL) – < 150 fM/ < 1 amol/well Standard Luminometry (ATP): 96 wells (200 µL) – < 75 pM Enhanced Luminometry (ATP): 384 wells (50 µL) – < 10 pM Photometry Measuring range: 96 wells – 0 to 4 OD, 384 wells – 0 to 4 OD, 1536 wells – 0 to 3 OD Accuracy (at 2 OD): < 2 % Precision (at 2 OD): < 0.1% AlphaScreen (STD and HTS): 384 wells (25 µL, phosphorylated bio-peptide, kinase assay): < 100 amol Dimensions (HxDxW): 580 x 550 x 420 mm Weight: 50 kg
€13,500.00 ex VAT
Netherlands
microplate readers
