Pfeiffer HiCube 300 Neo, 100 CFF, MVP 030-3 Turbo Pumping Station
Description from the supplier
Pfeiffer HiCube 300 Neo, 100 CFF, MVP 030-3 Turbo Pumping Station
Final Pressure
1x10-8 hPa / 7.5x10-9 Torr / 1 x 10-8 mbar
Backing Pump Speed
1.8 m³/h / 1.06 cfm / 30 l/min
Pumping Speed for N2
260 l/s
- Compact series of pumping stations for all high vacuum applications
- Simple operation with 7in. touch display
- Remote control via web server available
- Compatible with a wide variety of applications
- Reliable and robust
The Pfeiffer HiCube 300 Neo, 100 CFF, MVP 030-3 Turbo Pumping Station is a compact, high-performance solution designed for all high vacuum applications. Featuring a user-friendly 7-inch touch display, it offers simple operation and remote control capabilities via a web server, allowing for versatile use across various demanding environments. With a final pressure of 1 x 10⁻⁸ mbar and a pumping speed of 260 l/s for nitrogen, this turbo pumping station ensures efficient and reliable vacuum generation.
Equipped with the HiPace 300 turbopump and an MVP 030-3 backing pump, this unit provides robust performance with a quiet emission sound level of ≤50 dB(A). The air-cooled forced convection system maintains optimal operating conditions, and the unit is globally compatible with an input voltage range of 100-240 V AC. Weighing 22.5 kg, it is both sturdy and adaptable, making it suitable for a variety of applications in lab and industrial settings.
- Backing Pump - Pfeiffer MVP 030-3 Diaphragm Pump
- Protective Cap for High Vacuum Flange
- Power Cord
- Operator's Manual
- Manufacturer's Documentation
- 1 Year Manufacturer's Warranty
Product details
| Final Pressure | 1x10 -8 hPa / 7.5x10-9 Torr / 1 x 10-8 mbar |
| Pumping Speed for N 2 | 260 l/s |
| Pumping Speed for Backing Pump 50 Hz | 1.8 m³/h / 1.06 cfm / 30 l/min |
| Cooling method | Air (Forced convection) |
| Motor for region | Worldwide |
| Type | Turbo pumping station |
| Turbopump | HiPace 300 |
| Ambient temperature | 5 – 40 °C |
| Rated power at max. rotation speed | 235 W |
| Emission sound pressure level (EN ISO 2151) | ≤50 dB(A) |
| Weight | 22.5 kg / 49.6 lb |
| Backing pump | MVP 030-3 |
| Fore-vacuum safety valve | No |
| Connection flange (in) | DN 100 CF-F |
| Connection flange (out) | Silencer, 1/8" thread |
| Input Voltage(s) | 100 – 120 / 200 – 240 V AC (±10 %), 50/60 Hz |
