Edwards mXDS3s Dry Scroll Pump

$3,897.00 (ex VAT)
item image

Description from the supplier

Edwards mXDS3s Dry Scroll Pump


Ultimate Pressure
0.1 mbar (0.075 Torr)
Pumping Speed
2.06 CFM (3.5 m^3/h^-1)
Inlet Connection
DN 16 ISO-KF (NW16)

  • Weighs in at just 17.2 lb. (7.8 kg) and comes with a purpose-made carry handle making it highly portable
  • Can typically be mounted horizontally or vertically and for convenient connection
  • Inlet can be orientated vertically or horizontally with a push-fit alternative available as an accessory
  • Delivers 2.06 CFM (3.5 m^3/h^-1) peak speed at 60Hz and 0.1 mbar ultimate pressure
  • Gas ballast facility incorporated in the design as standard for water vapour handling and an exhaust valve
  • Oil-free pump with no oil to top up, replace or dispose of
  • Optimized fan cooling is beneficial in reducing noise for quieter operation and a pleasant working environment
  • Low maintenance, with tip seal changes required over typically 2 years


The Edwards Vacuum range of small dry scroll pumps is expanding with the introduction of the compact mXDS3 and mXDS3s Dry Scroll Pumps. The new mXDS3 dry scroll pump delivers 1.77 CFM (3 m^3/h^-1) pumping speed at 50Hz or 2.06 CFM (3.5 m^3/h^-1) together with an ultimate pressure of 0.1 mbar making it well suited for backing turbomolecular pumps. The mXDS3 is the standard option supplied with no inlet valve fitted, while the mXDS3s comes factory fitted with an inlet valve featuring delay opening. The mXDS3s is also supplied with an exhaust silencer. Both offer the same vacuum performance and feature an IEC connector for main supply and an on/off switch for easy control. This compact dry pump offers flexibility to the system designer and end user alike with a wide range of accessories available to choose from to meet your configuration requirements. This standard variant of the mXDS3 comes with a single phase 115V, 50/60Hz motor.
Click Here to View Product Video

  • Inlet Isolation Valve
  • Exhaust Silencer
  • Power Cord
  • Operator's Manual
  • Manufacturer's Documentation
  • 1 Year Manufacturer's Warranty

Product details

Ultimate Pressure (Closed Gas Ballast)0.1 mbar (0.075 Torr)
Ultimate Pressure (Gas Ballast with 1 Turn)0.15 mbar (0.113 Torr)
Maximum Pumping Speed (50Hz)1.77 CFM (3 m^3/h^-1)
Maximum Pumping Speed (60Hz)2.06 CFM (3.5 m^3/h^-1)
Maximum Permitted Inlet Pressure1000 mbar
Typical Initial Pressure Rise on Power Loss5 mbar l
Inlet ConnectionDN 16 ISO-KF (NW16)
Outlet Connection1/8" BSP for 6x8mm hose
Power Consumption at Ultimate Pressure180W
Mains ConnectorIEC EN60320 C13
Noise Level54.0 dB(A) ± 2.5
Leak Tightness1 x 10^-4 mbar/ls^-1
Nominal Rotational Speed3,000 RPM at 50Hz or 3,600 RPM at 60Hz
Dimensions (L x W x H)8.8 x 6.2 x 9.1 in. (22.4 x 15.8 x 23.1 cm)
Weight17.2 lb. (7.8 kg.)
Electrical Requirements115V, 50/60Hz, 1Ph
