Pierre Guerin Technologies EVO 10-20L Fermenter

This listing is for 1 of 4 Pierre Guerin Technologies EVO 10-20L Fermenters. The unit is in full working condition and is ready for immediate release.Please see spreadsheet attached at the bottom of listing for all parts included with this unit.The Pierre Guerin EVO Series fermenters and bioreactors are designed for precision in bioprocess research and development. These mobile, SIP (Sterilize-In-Place) and CIP (Clean-In-Place) units are ideal for applications ranging from educational settings and R&D to pilot-scale productions within GLP or GMP environments. They are versatile and suitable for various culture types, including yeast, bacteria, fungi, or cell cultures, operating in batch, fed-batch, continuous, or perfusion modes (with appropriate accessories).Key FeaturesVessel Design:Capacity & Configuration: Working volume of 10-20L with a total volume of 23L.Material & Surface Finish: High-grade 316L stainless steel, with an internal surface finish of Ra ≤ 0.8 µm and pipework Ra ≤ 1.6 µm, ensuring sterility and cleanability.Sterilization & Temperature Control: Double jacket for automatic media sterilization and precise culture temperature regulation.Operating Pressure: Maximum vessel pressure of 2 barg, jacket pressure up to 2.5 barg.Headplate Design: Removable flat headplate for easy access and maintenance.Agitation System:Drive Type: Available in mechanical coupling with a single seal or magnetic coupling with a synchronous drive for reduced contamination risk.Impeller Configuration: Standard setup includes one HTPG4 impeller, one Rushton impeller, and one baffle, providing optimal mixing for various culture types.Speed Range: 30 to 1200 RPM with precision control.Torque Monitoring: Integrated system for monitoring agitation performance.Instrumentation & Control:Measurement & Control:Temperature: PID-controlled temperature regulation.Agitation Speed: Precise real-time adjustment.pH: Online monitoring and automated control.pO₂ (Dissolved Oxygen): Optical probe-based real-time monitoring and control.Foam Level: Automatic detection and antifoam control.Weight Measurement: Integrated load cell system.Total or Viable Cell Density Measurement: Optional high-accuracy sensors available.Neptune Control System:Graphical Interface: Intuitive touchscreen display.GMP Compliance: 21 CFR PART 11 & GAMP 5 validation-ready.Advanced Process Control: Includes profile management, real-time calculations, and automation strategies.Remote Monitoring & Data Logging: Supports Ethernet™ network integration for remote supervision and maintenance.Gas & Fluid Management:Gas Control: Automatic control of air, oxygen, nitrogen, and CO₂ sparging.Peristaltic & Precision Dosing Pumps: Integrated system for nutrient and pH adjustments.Media Addition & Sampling: Dedicated ports for sterile sampling and automated feed control.Cleaning & Sterilization:SIP (Sterilize-In-Place): Automated sterilization cycle.CIP (Clean-In-Place): Fully integrated system for effortless cleaning between batches.Specifications:Nominal Working Volume: 10-20 litersMinimum Working Volume: 7 litersTotal Volume: 23 litersAgitation Speed Range: 30-1200 RPMMaterial: 316L stainless steel with Ra ≤ 0.8 µm finishPressure Ratings: Vessel 2 barg, Jacket 2.5 bargSterilization: SIP & CIP capabilityControl System: Neptune SCADA-based, remote monitoring readyGas Control: Automated sparging system for O₂, N₂, CO₂, and airPumps: Integrated peristaltic dosing & feed pumpsProcess Modes: Batch, Fed-Batch, Continuous, PerfusionParts List:https://docs.google.com/spreadsheets/d/e/2PACX-1vTvtN5S8ejYzw7v3-x4ipgu7tn2Z2Rrt5NQrImDPxw-xJhxRUodjlVoFlDj1F9qxKnciCbDLgtEzEa2/pubhtml*only 1 out of the 4 units is supplied with a Nuova General Instruments 2883/D10/C-FMP Safety Pressure ValveBrochure:https://www.pierreguerin.com/sites/g/files/tkmtob276/files/2023-10/Evo_Data%20Sheet_UK.pdf
