Invitrogen XCell SureLock Electrophoresis Cell

High voltage power supply with constant voltage, constant current or constant power regulation mode.

Voltage range: 0 – 500 V Amperage range: 0 – 500 mA Power range: 0 – 150 W Timer: 1 – 999 min/0.1 –  (more)99.9 h Outputs dual in parallel, floating Leakage detection: > 500 μA No load detection: < 0.1 W Dimensions: 300 x 120 x 180 mm Weight: 5 kg

Bio-Rad offers a range of mini horizontal electrophoresis chambers to resolve DNA fragments on eithe (more)r handcast agarose gels or ReadyAgarose precast gels. These cells include a buffer tank, safety lid with cables, and leveling bubble. Fast and flexible, the Mini-Sub cell GT cell is our most popular classroom gel box. The Mini-Sub cell GT cell holds either a 7 x 7 cm or a 7 x 10 cm gel tray. A 10 cm agarose gel poured with two 8-well combs easily accommodates two student teams at a time. At 100 V, this cell resolves DNA fragments from 20–20,000 base pairs in just under 30 min. Cell size (WxLxH): 120 x 260 x 65 mm Gel tray sizes (OD) (WxL): 70 x 70 mm ReadyAgarose gels accommodated: Yes, mini format Sample throughput: 8–30 Base buffer volume: ~270 ml Buffer recirculation: No Bromophenol blue migration: 4.5 cm/hr (at 75 V)

This system is used to analyze the size of DNA/RNA samples, with convenientanalytical operability. I (more)t achieves analysis costs on par with agarose gel electrophoresis, and can perform fully automatic analyses of up to 108 samples. Using optimized reagent kits (four types for DNA analysis and one type for RNA analysis), the system achieves a high resolution and high sensitivity. It can significantly improve the workflow for mutation checks in genome editing, and genotype determination. Sample rack: Compatible with 96-well PCR plate and 12/8-strip PCR tube (Shimadzu recommended product) Microchip: Quartz, 23 mm separation channel length, on-chip electrodes (insert up to four microchips) Pretreatment: Automatic sample injection, automatic separation buffer replenishing, automatic chip cleaning Electrophoresis Voltage: Max. rated voltage: 1.5 kV, max. current: 250 μA Analysis Cycle time: Approx. 80 s (using four chips) DNA standard analysis (DNA-1000/premixed). This does not include time required for carrying out the first and final wash and initial analysis. Detection Method: LED-excited fluorescence detector (470 nm excitation wavelength) Separation Size Range: 25 to 500 bp (DNA-500 Kit), 100 to 1000 bp (DNA-1000 Kit), 100 to 2500 bp (DNA-2500 Kit), 100 to 12000 bp (DNA-12000 Kit), Up to 28S rRNA (5.0 knt) (RNA Kit) Resolution: 5 bp (25 to100 bp), 5% (100 to 500 bp), 10% (500 to 1000 bp), 20% (1000 to 12000 bp) Sizing Accuracy: ±5 bp (25 to 100 bp), ±5% (100 to 500 bp), ±15% (DNA-1000, DNA-2500, DNA-12000) Required Sample Volume: DNA analysis: Premix mode: 2 to 10 μL (after mixing with marker solution: 6 to 30 μL), On-Chip Mixing mode: 5 to 30 μL, RNA analysis: Premix mode: 3 to 15 μL (after mixing with marker solution: 6 to 30 μL), In the Premix mode, the marker solution is mixed with the sample before loading in the instrument, In the On-Chip Mixing mode, the sample and marker solution are loaded separately and mixed on the microchip under program control. Maximum Salt Concentration: DNA analysis: 10mM Tris-HCI containing 125 mM KCl or NaCl max, RNA analysis: 10mM Tris-HCI, containing 1 mM EDTA max. Min. Detection Limit: DNA analysis: 0.2 ng/μL (at 10mM Tris-HCI buffer, containing 50 mM KCl and 1.5 mM MgCl2), RNA analysis: 5 ng/μL (total RNA), 25 ng/μL (mRNA) (at 10 mM Tris-HCI buffer, containing 1mM EDTA) Quantitation Range: DNA analysis: 0.5 to 50 ng/μL (at 10mM Tris-HCI, containing 50 mM KCl and 1.5 mM MgCl2), RNA analysis: 25 to 500 ng/μL (total RNA), 25 to 250 ng/μL (mRNA) (10 mM Tris-HCI buffer, containing 1 mM EDTA) Quantitation Accuracy: DNA analysis: ±30% (at 10 mM Tris-HCI buffer, containing 50 mM KCL) (DNA-500, DNA-1000, and DNA-2500 Kits), ±40 % (DNA-12000 kit. Quantitative accuracy is based on verification from 200 bp to 12000 bp.) Quantitation Repeatability: RNA analysis: CV 10% or less (CV 20% or less for eukaryotic-origin total RNA at concentrations of 150 ng/μL or more) Dimensions (WxDxH): 415 x 545 x 508 mm Weight: 43 kg

Scilogex MicroPette Plus Autoclavable Pipettor, 0.1-2.5ul Volume Range 0.1-2.5uL Adjustable or Fixed (more) Volume Adjustable Volume Accuracy (±%) 2.50/3.00/12.00 Features - Fully autoclavable at 121°C - Ergonomic design provides excellent operating experience - Easy-to-read volume display - The pipettes cover the volume range from 0.1μL to 10mL - Integral tip ejector for access into narrow tubes - Easy to calibrate and maintain with tool supplied - Used with 'universal' pipette tips - Each MicroPette Plus supplied with an individual calibration certificate according to ISO8655. The MicroPette Plus pipettes are fully autoclavable, enable easy cleaning and reduce the risk of contamination. Steam autoclaving can be performed at 121°C, 1 bar for 20 minutes. After autoclaving, the pipette must be cooled down and left to dry for 12 hours before use. It is recommended to check the performance of the pipette after each autoclaving. Greasing and sealing of the pipette piston after every 10th autoclaving will secure an enhanced function. All SCILOGEX pipettes have been quality tested according to ISO8655-2:2002 and are supplied with individual calibration certificates. The quality control includes gravimetric testing of each pipette with distilled water at 22°C. Volume adjustment is selected by turning the thumb plunger mechanism. MicroPette's are calibrated in accordance ISO/DIS 8655. Each pipettor passes a quality control/calibration test and is supplied with a certificate. INCLUDED: The Scilogex MicroPette Plus Autoclavable Pipettor, 0.1-2.5ul includes: - Operator's Manual - Manufacturer's Documentation - 1 Year Manufacturer's Warranty
