Lumenera LW135M Camera

The offered instrument / system is fully functional tested and ready to use. FURTHER DETAILS TO FOLL (more)OW

Motic Panthera E2 Trinocular + BTI10 Camera Bundle Panthera E2 microscopes combine high quality mate (more)rials and precise engineering to a persistent and resilient construction. Smooth operation of the mechanics is self-evident for fast and reliable results, responsible for shifting your daily work in classroom and lab to a higher level of quality. User-friendly design, robust for tough environments and unique features grants the best performance. The Moticam BTI10 combines a space-saving camera hardware with new Wi-Fi technology. The 4MP Wi-Fi camera comes together with an 10” Android tablet to deliver fast live images (up to 30 fps) on any microscope with a vertical photo tube.INCLUDED: The Motic Panthera E2 Trinocular + BTI10 Camera Bundle includes: - 4X/0.10 (WD 30.5mm ) Objective - 10X/0.25 (WD 17.4mm ) Objective - 40X/0.65/S (WD 0.6mm ) Objective - 100X/1.25/S-Oil (WD 0.16mm ) Objective - Dust Cover - Power Cord - Allen Key - UC-WF eyepieces 10X/20mm - Moticam BTI10 - 0.35X C-Mount camera adapter - Manufacturer’s Documentation - 5 Year Manufacturer’s Warranty Motic Panthera E2 Trinocular + BTI10 Camera Bundle SpecificationsPanthera E32 Trinocular SpecificationsOptical systemColor Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf type, 360° swivelingInclination25° inclined, 360° rotating (storage saving), 360° swivellingTrinocular light splitFixed 50:50Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield UC-WF10X/20mm with diopter adjustmentNosepieceReversed quadrupleObjective classificationCCIS® UC Plan Achromatic (Pb free)Objectives4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUprightStageMechanical stage with built-in low position rackless coaxial stage control and sample holderStage size140x135mmTravel range X&Y75x40mmCondenserFocusable and centerable Abbe condenser N.A. 0.90/1.25 with slot for contrast slidersDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminatorTransmitted illuminationFixed Koehler LED 1W with intensity controlIllumination featuresNosepiece LED light intensity indicatorTransformerInternalPower supply110-240V (CE), USB 2.0 for battery packOther featuresUSB 2.0 for external camera powerDimensions LxWxH282x210x396mmNet weight7.5kg BTI10 Camera SpecificationsSensor TypeCMOSSensor Size1/3"Imaging Area5.44x3.07mmCapture Resolution Info4MP (2592x1520 pixels)Live display mode through Wi-Fi1280x720, 1920x1080 pixels (Full HD)Live display mode through Ethernet1280x720, 1920x1080 pixels (Full HD)Pixel size2.0x2.0μmScan modeProgressiveData transferWi-Fi (2.4 & 5 GHz), EthernetMax. frames per second (fps)1920x1080 @ 30 fps, 1280x960 @ 30 fps (depending on Wi-Fi strength)Exposure time0.03 msec to 0.03 secOperating temperatureFrom 0 to +60 Degrees Celsius non condensingMax. signal to noise ratio38.3dBDynamic range64.6dBSensitivity1.9V/Lux-sec (550nm)ButtonsOn/OffSupport deviceUniversal Web browser (HTML5)Supported OSWindows XP/Vista/7/8/10, MAC OSX, Android 4,0 or higher, iOS7 or higherMinimum computer requirements2GHz dualcore - RAM memory 2GB - Video memory min. 512 MBLens mountC-MountScreen10" IPS TabletSoftwareMotiConnect App for iOS and Android (pre-installed)FunctionsStill image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system.Power supply12V (External Power supply)Tablet bracket holderFor tablets from 7” to 10”Package includesUSB cable, Motic 4-dot calibration slide, universal power supply 100V-240V (CE)Tablet SpecificationsSize (mm)218x136x10mmSystemAndroid 10Pre-installed AppMotiConnectLanguageMulti-LanguageCPU2.0GHz 8-coreRAM6GB DDR3NAND Flash128GBDisplay10" (IPS) 16:10 RatioDisplay resolutions1920x1200Touch PanelCapacitive Multi-Touch ScreenGPUMALI-G720 MP3PortsMicroSD/MMC/TF Card (Support up 64 GB), 3.5mm Audio, USB-C (USB OTG and Charging)Speaker8Ω/0.7Wx2MicMIC (Internal)Wi-Fi802.11b/g/nBluetooth4.0CameraFront (5M Pixels) + Rear (8M Pixels)Support display formatMPEG-1/2 (DAT, MPG, VOB, TS), MPEG-4, H.263 (3GP, MOV, MP4), H.264 (AVI, MKV, MP4, MOV, 3GP), RM, RMVB, FLV, WEBMSupport audio formatMP3, WMA, MP2, OGG, AAC, M4A, OGA, FLAC, APE, MP1, WAVPicture formatJPG, JPEG, GIF, BMP, PNGBattery3.7V/3500mAh Rechargeable BatteryPower supply tabletInput：AC100-240V. 50-60HZ - Output: DC5V 2A (Support USB port charging）CertificationsFCC CEColorWhiteComparison of ModelsSpecificationPanthera E2 BinocularPanthera E2 Binocular (w/o 100x)Panthera E2 Trinocular + BMH4000 Camera BundlePanthera E2 Trinocular + BTI10 Camera BundlePanthera E2 TrinocularPanthera E2 Trinocular (w/o 100x)Optical SystemColor Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Observation TubeBinocular head, Siedentopf type, 360° swivelingBinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular Light SplitN/AN/AFixed 50:50Fixed 50:50Fixed 50:50Fixed 50:50EyepiecesWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentObjectives4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)Stage Size140x135mm140x135mm140x135mm140x135mm140x135mm140x135mmIlluminationLEDLEDLEDLEDLEDLED.comparison-table tr td:nth-child(5) { background-color: #fffacd; }

Motic Moticam X5 Plus Microscope Camera Highest Live Display Mode 1920x1080 Pixels Capture Resolutio (more)n 4MP Maximum Frames per Second (FPS) 30 FPS Features - 4MP (2560x1440 pixels) capture resolution - 1280x720, 1920x1080 pixels (Full HD) live display - Data transfer: Wi-Fi (2.4 & 5 GHz), Ethernet (RJ-45) - 30 Frames per second (depending on Wi-Fi strength) - CMOS sensor type (1/3-inch); C-mount lens mount The Motic Moticam X5 Plus is a 4 MP digital microscope camera with Wi-Fi and ethernet data transfer. The Moticam X5 Plus turns your microscope into a Wi-Fi station, allowing you to share your images with up to six devices at the same time by logging into MotiConnect from your tablet or smartphone. The Moticam X5 Plus follows our All-In-One-Box methodology. This means that with the included focusable lenses, eyepiece adapters, and glass calibration slide, you can convert almost any conventional microscope into a digital microscope. View, edit, capture and store your images in the blink of an eye, view live images on multiple wireless devices, and share your work with anyone in just a few clicks. The MotiConnect App makes data sharing possible in a collaborative environment, encouraging teamwork and collective learning experiences. Connect your Moticam to your computer if you wish to work with our well-known software Motic Images Plus 3.1, which comes included in the package as a download Click Here to View Product Video INCLUDED: The Motic Moticam X5 Plus Microscope Camera includes: - CS ring adapter - 12mm Focusable lens - Eyepiece adapters - Motic 4-dot calibration slide - Motic Images Plus for Windows/OSX/Linux (download) - MotiConnect (free app download) - Power Cord - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Moticam BTI8 Microscope Camera Highest Live Display Mode 1920x1080 Pixels Capture Resolution 4 (more)MP Maximum Frames per Second (FPS) 30 FPS Features - Fast live images up to 30 fps on any microscope with a vertical photo tube - 8-inch detachable android tablet - Wi-Fi and Ethernet data transfer - Pre-installed MotiConnect app allows you to capture, save, edit and share - Sensor type: CMOS - Lens mount: C-mount - Image capture resolution: 4 MP - Video resolution: 720P (HD) - Built-in micro-SD port - Functions: image and video capture, image measurement, adjustments, white balance, exposure, and individual objective calibration system The Motic Moticam BTI8 is a digital microscope camera with an 8-inch Android tablet. The BTI8 will deliver fast live images up to 30 frames per second on any trinocular microscope with the right C-mount adapter. The Moticam BTI8 provides the convenience of a detachable tablet and Wi-Fi data transfer, making it easier than ever to capture your images and bring them anywhere. With the pre-installed MotiConnect app, you can view live camera streams, capture, edit, measure, annotate, save, and share your microscope image by simply touching the icons on the tablet. The MotiConnect app makes data sharing possible in a collaborative environment, encouraging teamwork and collective learning experiences. Please note, that the photo is for illustrative purposes; the Included tablet is an Android tablet. INCLUDED: The Motic Moticam BTI8 Microscope Camera includes: - USB cable - Motic 4-dot calibration slide - Power Cord - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Moticam 4000X Microscope Camera Capture Resolution 8MP Pixel Size 1.45 x 1.45μm Maximum Frames (more) per Second (FPS) 30 FPS Features - Designed for ease of use with fast live image output at 4K (3840x2160) resolution - Connects to a computer via USB or through HDMI - On-board software for standalone operation with 11.6" integrated LCD screen - USB port for mouse connection - Integrated SD card slot for flexible, portable data saving without a computer - Delivers 1080p Full HD live image with maximum color fidelity on integrated LCD screen - No computer required for standard operation - Includes Motic Images Plus 3.1 software for Windows and Mac OS
