CLIMATE CHAMBERS
KK SMART PRO BY POL-EKO
KK - TRUSTWORTHY AND EXTREMELY ADAPTABLE
Constructed without compromise, the KK Smart Pro climate chambers are an essential asset in medical, biotechnological, chemical, and industrial laboratories. They are also crucial for pharmaceutical stability testing in accordance with ICH Q1A (R2) - (CPMP/ICH/2736/99).
These climate chambers regulate a consistent temperature between 0°C and 60°C, while an ultrasonic humidifier allows for humidity control ranging from 30% to 90%.
The KK series is outfitted with the advanced POL-EKO Smart PRO touch control panel. More than just a 7' display, this panel features WiFi for communication and data transmission, programming functions, alarm systems, internal memory for data logging, and much more, including standard PC management software.
Further observation will allow you to uncover the numerous beneficial features of these climate chambers!
SUPREME CONTROL
The Smart PRO control panel is one of the most comprehensive on the market. Its large icons and temperature values facilitate clear readability and ease-of-use. The touchscreen can even respond to inputs through latex gloves.
The use of the Smart PRO system reveals unique possibilities. Leveraging cutting-edge functions for data transfer and remote usage, the system achieves this excellence with the aid of LabDesk software.
Should you be interested, a dedicated post is available with extensive insights on the Smart and Smart PRO panels.
ADVANTAGES OF THE SMART PRO PANEL
- Crisp 7' color touch screen
- LAN, USB, and WiFi ports for communication and data transmission
- Rapid, multi-segment, time, and temperature programming
- Adjustable ramps
- Recording of the minimum, average, and maximum temperature value for each segment
- Visual and audible alarms with a color bar display
- Internal memory for programming and data storage
- Fan speed control 0...100% or 10%...100% (dependent on chamber capacity)
- User manuals accessible directly from the controller
- Loop function for up to 255 times or infinite loops
- Temperature sensor failure alarm
- Event log with user notifications
- Ability to create user accounts for rights and password assignment
- Capacity for 40 user programs
- Data log – 10,000 data records per user, viewable on screen in tabular or graphical form
- USB port for direct data download
- Event log
QUALITY FIRST
Resilient. Long-lasting.
POL-EKO climate chambers are designed and built for elite performance, making them a wise investment towards the future of your laboratory. These products ensure precise results over a long timespan, ensuring consistency and ease of use.
The KK Smart Series utilizes quality materials and includes significant accessories, delivering a comprehensive and ready-to-use standard product.
- Insulated door with a lock
- Internal glass door
- DIN 1.4301 acid-resistant stainless steel interior
- Stainless steel grill shelf (Inox)
- Overtemperature protection of class 3.3 in accordance with DIN 12880
- Castor wheels
- Quality control protocol (at +25°C and 60%rH)
- Automatic defrost function
- USB, LAN (with cable), and WiFi connectivity
- LabDesk software
- External probe insertion point, with a diameter of 30mm
- Deionized water tank
- Door open alarm
- FIT certification: day and night simulation with intensity control.
Note: the usable temperature range with FIT active is +10°C... +50°C.
KK SMART PRO SERIES - EXPAND YOUR POSSIBILITIES
POL-EKO offers nine climate chamber models, with capacities ranging from 109 to 1485 liters.
Refer to the included graph to understand the superior working range (humidity/temperature) that POL-EKO climate chambers, specifically the KK series, can offer.
ULTRASONIC HUMIDIFIER
Climate chambers with an ultrasonic humidifier are refined, reliable instruments that ensure stable and precise conditions, enabling their use across a wide range of applications like seed germination, mushroom and plant cultivation, food testing, and the stability testing of pharmaceutical, cosmetic, packaging, and electronic products.
NOTE: Deionized water (1 μS/cm) is required for the KK series.
Water source: deionized water tank; deionizer; or internal deionized water network.
DETAILS AND ACCESSORIES
Every aspect of your POL-EKO model is designed for effortless routine work and comfortable usability. Below are some of the incredible features of your future ovens for drying, analysis, or testing:
Front View
1 - Rating Plate
2 - Fan
3 - Internal Glass Door
4 - ø30mm Probe Hole
5 - Shelf
6 - Condenser Position
7 - Lockable Wheels
8 - Solid External Door (option for window)
9 - Touch Screen Control Panel
10 - USB Port
11 - Door Open Sensor
Rear View
1 - Deionized Water Container
2 - Power Cable
3 - Connectors
4 - Connectors (to a tank with demineralized water or deionizer)
5 - Service Connector
6 - Drain Connection
7 - Main Switch
8 - LAN Port
9 - Fuse
For larger models (KK 500 / 700 / 1200 / 1450):
a - Power Cable
b - Deionized Water Container
c - Condensate Collection Tray with Pump
d - Main Switch
e - LAN Port
f - Fuse
The delivery of the climatic chamber also includes:
OPTIONAL FEATURES
POL-EKO offers the possibility to enhance your climatic chamber with superior quality accessories to better accommodate specific applications or to enhance instrumentation with safety features and advanced connectivity.
Inside Image: Climatic Chamber with LED Series Fitotrone System
- Panoramic Window Door
- Perforated Shelf
- Reinforced Shelf
- Stainless Steel Basins
- Phitotron FIT System
- Internal Socket
- Water Level Sensor
- Calibration and qualification of IQ OQ PQ
- Backup Battery for Display Power Failures
- Clean Contact
- Non-standard 20/60/100 mm Access Doors
- Additional 30mm Access Door
POL-EKO CUSTOMERS
The SPEKTROCHEM Research and Development Center for Paints, Adhesives, and Polymers has remained an unwavering POL-EKO customer for many years, utilizing our climatic chambers for testing water-based laboratory prepared raw materials.
Temperature °C | 0... +60 |
External dimensions mm L x P x A | 660 x 1080 x 1990 |
Internal dimensions mm L x P x A | See the technical data sheet for precise information |
Control panel | Color display touchscreen |
Shelves and drawers | 3 shelves (11 max.) |
Timer | Multifunction timer |
Safety class | 3.3 |
Internal volume lt | 470 |
Power W | 1850 W |
Warranty | 12 month ex works. 24 months for spare parts. |
Type of refrigerant | R290 |
Series | KK |
Readability | 0,1 °C |
Cooling tecnology | Compressor |
Various | Double door: internal glass; full exterior |
Weight kg | 130 |
Supply | 230 V / 50-60 Hz |
Temperature variation (in space) | +/- 2.0 @ 25°C, 60%rH |
Air convection | Forced |
Port for external sensor | Ø 30 mm |
GWP | 3 |
Humidity adjustable from...to % | 30... 90 |
Humidity resolution | 1,0 % |
Humidity variation (in space) | +/- 5.0 @ 25°C, 60%rH |
Defrosting | Automatic |
Castors | Standard |
