Yamato DT-411 Forced Convection Clean Oven, 91L
Product Description
The Yamato DT-411 is a Class 100 forced convection cleanroom oven designed for precise temperature testing, drying, and sterilization in a dust-free environment.
- Circulation Method: Forced convection
- Operating Temperature Range: Room temperature +30 to 360°C
- Temperature Control Accuracy: ±0.3°C at 360°C
- Temperature Fluctuation: ±0.5°C at 360°C
- Temperature Distribution Accuracy: ±4.0°C at 360°C
- Temperature Gradient: ±20.0°C at 360°C
- Max Temperature Reach Time: Approximately 80 minutes
- Clean Level: Class 100 at stable temperature
- Materials: Interior - Stainless steel; Exterior - Cold rolled steel plate with melamine resin bake finish
- Insulation: Glass wool
- Door: Single side, left swing
- Heater: Stainless steel pipe heater
- Fan Type: Sirocco fan with 400W condenser motor
- Filter: Heat-resistant HEPA filter with >99.97% efficiency for 0.3µm particles
- Cable Port / Exhaust Port: Inner diameter 33mm (right side) / Outer diameter 61mm
- Mobility: Free swivel caster wheels without stopper; level adjusters (two front)
- Temperature Control & Display: PID V controller with digital ▲/▼ key setting; dual LED display (green 4-digit and orange 5-digit)
- Operation Functions: Constant temp, programmed operation (up to 99 steps × 99 patterns), auto start/stop, quick auto stop, repeat functions
- Additional Functions: Variable fan speed, accumulated operation time (up to 65,535 hours), calibration offset, power consumption and CO2 emission monitoring, heater output monitoring, power recovery, data save and restore
- Sensor: Dual K-type thermocouples for control and overheat prevention
- Heater Control: Triac zero-cross control
- Safety Features: Self-diagnostic functions, earth leakage breaker (15A, 30mA sensitivity), key lock, independent overheating prevention, phase reversal relay, door switch disabling fan and heater when open
- Dimensions (WxDxH): Internal 450×450×450 mm; External 700×1025×1570 mm
- Capacity: 91 liters (3.21 cu. ft.)
- Weight: Approximately 200 kg (441 lbs.)
- Shelves: 2 plates with 4 brackets; 12 height steps with 30mm pitch
- Shelf Load Capacity: ~30 kg per shelf
- Power Supply: 220V 3-phase, 10A, 50/60Hz ±10%
- Additional Features: Anti-fouling casters, enhanced filter replacement indicator, phase reversal relay for installation safety, larger cable port diameter, compact height compared to previous models.
Item Stats
Product details
| Circulation Method | Forced convection |
| Operating Temp. Range | Room temperature +30 to 360°C |
| Temp. Control Accuracy | ±0.3°C at 360°C |
| Temp. Fluctuation | ±0.5°C at 360°C |
| Temp. Distribution Accuracy | ±4.0°C at 360°C |
| Temp. Gradient | ±20.0°C at 360°C |
| Max. Temp. Reaching Time | ~80 mins. |
| Clean Level | Class100 (when temperature is stable) |
| Interior/Exterior Material | Stainless steel / Cold rolled steel plate with melamine resin baking finish |
| Heat Insulating Material | Glass wool |
| Door | Single side left swing |
| Heater | Stainless steel pipe heater |
| Fan Type | Sirocco fan, Condenser motor 400W |
| Differential Pressure Meter | Analog type (0 ~ 300Pa) |
| Cable Port/ Exhaust Port | Inner diameter: 33mm×1 (right side) / Outer diameter 61mm |
| Filter | Heat resistant HEPA filter (dust-collection efficiency >99.97% up to 0.3μm particle filtering) |
| Caster Wheels / Adjuster | Free swivel caster wheels without stopper / level adjuster (2 at front) |
| Temp. Control/Setting Method | PID V control / Digital setting with ▲/▼ keys |
| Temp. Display System | Top screen: green 4-digit digital LED (resolution 1°C), Bottom screen: orange 5-digit digital LED (resolution 1°C) |
| Other Indications | LED indicates temperature patterns for heating/stabilizing/cooling |
| Operation Functions | Constant temperature operation, Programmed operation (Maximum 99 steps, up to 99 patterns, repeat operation function),Duration/time select operation function (auto start/auto stop/quick auto stop, program operation) |
| Additional Functions | Variable fan speed, Accumulated on time, operation time function (up to 65,535 hours); calibration offset; accumulated powerconsumption monitoring, total CO2 emission monitoring, heater output monitoring; power recovery; setting data save and restore |
| Sensor | K type Thermocouple dual sensor (temperature control and independent overheat prevention device sensors) |
| Heater Control | Triac with zero-cross control |
| Safety Device | Self-diagnostic functions (Detection for Temp. Sensor Failure, Triac Short Circuit, Automatic overheating prevention, Fan motorfailure detection, Heater Line Disconnect, Main Relay Contact Damage), Earth leakage breaker, Key Lock Function, Independentoverheating prevention device, Phase reversal relay, Door switch |
| Earth Leakage Breaker | 15A, Current leak /short circuit/surge protection, rated sensitivity 30mA |
| Door Switch | Door open: fan motor and heater circuit off, Door close: fan motor and heater circuit on |
| Internal Dimensions WxDxH | 450×450×450 mm |
| External Dimensions WxDxH | 700×1025×1570 mm |
| Internal Capacity | 91L / 3.21 cu. ft. |
| Weight | ~200 kg / ~441 lbs. |
| Shelf Rest / Pitch | 12 steps / 30mm |
| Withstand Load Of Shelf | ~30 kg / shelf |
| Power Supply 50/60Hz (V±10%) | 220V 3 phase 10A |
| Shelf Plate / Bracket | 2 pcs. / 4 pcs. |
