Yamato DF-832 Fine Oven 512L, 220V 3 Phase
Product Description
Yamato DF-832 Fine Oven, 512L, 220V 3 Phase, 16.5A, 50/60Hz
Large capacity, high-performance fine oven designed for high throughput with accurate temperature control and exhaust damper.
Operation and Functions:
- Precision temperature maintenance for large parts
- Quick exhaust and cooling using manual exhaust damper
- Digital key entry with green LED display
- Monitors power consumption and CO₂ emissions
- Safety with self-diagnostic functions
Specifications:
- System: Forced air circulation and ventilation
- Operating Temperature Range: Room temp. +15°C to 200°C
- Temperature Fluctuation: ±0.5°C at 200°C
- Temperature Slope: 15°C at 200°C
- Temperature Controller: PID Z control
- Temperature Setting: Digital with ▲▼ keys
- Timer: 0 min to 99 hrs 59 min; resolution of 1 min or 1 hr
- Operation Modes: Fixed temp, programmable (up to 99 steps and 99 patterns), auto start/stop functions
- Additional Functions:
- Accumulated power and operation time (max 65,535 hours)
- 24-hour calendar time
- Calibration offset
- Displays power consumption, CO₂ emissions, heater output
- Power recovery mode
- User settings save/restore
- Fan speed adjustment
- Sensor: Double K-thermocouple
- Heater: Stainless steel pipe heater with fan
- Fan Motor: Stainless steel axial flow fan, 20W capacitor motor (two motors for Model 1032)
- Cable Port: ID φ30 mm (rear)
- Heat Insulation: Glass wool
- Additional Structures: Manual exhaust damper
- Safety Devices:
- Self-diagnostics (sensor error, heater disconnection, SSR short-circuit, overheat prevention)
- Door switch
- Fan failure detection
- Key lock
- Independent overheat protection
- Electric leakage breaker with overcurrent protection
- Power Supply: 3-phase AC 220V, 13.5A (no plug, round terminal)
- Internal Dimensions (WxDxH): 800 x 800 x 800 mm
- External Dimensions (WxDxH): 1500 x 1015 x 1330 mm
- Internal Capacity: 512 liters
- Weight: Approx. 350 kg
- Shelves/Brackets: 3 shelves, 6 brackets
Item Stats
Product details
| System | Forced air circulation and ventilation |
| Operating Temp. Range | Room temp. +15°C~200°C |
| Temperature Fluctuation | ±0.5°C (at 200°C) |
| Temperature Slope | 15°C (at 200°C) |
| Temperature Controller | PID Z control |
| Temp Setting Method | Digital setting with ▲▼ keys |
| Timer | 0 min~99 hrs 59 min (Resolution: 1 minute or 1 hour) |
| Operation Function | Fixed temperature operation, Program operation (maximum 99 steps, up to 99 patterns, repeat operation function) Duration/time select timer operation function (fixed temperature operation, auto start/auto stop/quick auto stop, program operation auto start) |
| Additional Functions | Accumulated Power on and Operation Time (up to 65,535 hours); Calendar Time (24 hours); Calibration Offset; Monitor Display of Accumulated Power Consumption, Total CO₂ Emission, and Heater operating Output; Power Recovery Mode; User Settings Save and Restore Function; Fan Speed Setting Function |
| Sensor | K-thermocouple (double sensor) |
| Heater | Stainless steel pipe heater with a fan |
| Fan Motor | Stainless steel axial flow fan (capacitor motor: 20W), Two motors used for Model 1032 |
| Cable Port | I.D. φ30mm (rear) |
| Heat Insulator | Glass wool |
| Other Additional Structure | Exhaust damper (manual operation) |
| Safety Device | Self-diagnostic functions (temp. sensor error, heater disconnection, SSR short-circuit, automatic overheat prevention), door switch, fan failure detection, key lock, independent overheat protection, electric leakage breaker with over current protection |
| Power Supply 50/60 Hz | 3 phase AC220V 13.5A (no plug, round terminal) |
| Internal Dimensions WxDxH | 800 x 800 x 800 mm |
| External Dimensions WxDxH | 1500 x 1015 x 1330 mm |
| Internal Capacity | 512L |
| Weight | ~350kg |
| Shelf / Bracket | 3 pcs. / 6 pcs. |
