Refurbished Photic Stimulator. 6 months warranty*
Scope of delivery:
- Photic Stimulator
- Photic Arm
- Roll Stand
- Table clamp
- User Manual
Features:
- Consistent Flash Characteristics: Accurate stimulus parameters
- Wide Intensity Range: Extended appplications
- Wide Flash Rates: Provides variable stimulus rates
- Synchromous inputs/Outputs: Active High/Low TTL inputs/outputs simplify interfacing
Technical data:
- Flash Mode: Single or repetitive flashes
- Flash Intensity: 5 steps with ratios of 1,2,4,8,16. 22 lumen sec/ft2 at intensity 16 maximum energy (1.44 joules).
- Flash Rate: 1 to 60 per second, ‡5% accuracy
- Flash Duration: 10 uS
- Flash Tube: Xenon
- Monitors Front panel monitor light, flashes only when flash lamp lights. Two output pulses suitable for low frequency display devices.
- Synchronous Inputs: External control of flash rate via TTL level sync pulse. External control of intensity via TTL logic levels.
- Synchronous Output: TTL level, 20 us pulse for high frequency devices, signal averager, oscilloscope, etc.
- Power: 115 or 230 VAC, 50/60 Hz, 150 VA maximum
Physical Size:
- 9.75" W x 5.375" H x 8.1875" D (24.8cm x 13.7cm x 20.8cm)
- Weight: 12 lbs. (5.4kg)
- Flash Lamp: 5.375" diameter (13.7cm), 5" depth (12.7cm)
- Handle: 4" long (10.2cm), 1.25" diameter (3.2cm)
- Cable Length: 12-foot (3.6m)
Environmental Specifications:
- Operations: 0 to 40°C, 10 to 90% RH
- Non-condensing
- Storage: -20 to 60°C
- Pressure: 800 to 1,040 hPa
Regulatory:
- 115VAC: Certified to CAN/CSA C22.2
- No. 1010.1. Conforms to UL3101-1.
- 230VAC: CE Mark to IEC-1010-1.G
* No warranty on the light bulb.
