Lumenera INFINITY 8-20C 20MP USB 3.1 Microscope Camera with 1" Color CMOS Sensor
Product Description
The Lumenera INFINITY 8-20C is a high-resolution digital microscope camera optimized for biological and industrial material imaging.
- Sensor: SONY IMX183 CMOS, 1” diagonal, color sensor with 5472×3648 effective pixels (2.4μm square pixels)
- Frame Rate: Up to 19.6 fps at full 20MP resolution (8-bit mode), 10 fps in 12-bit mode
- Interface: USB 3.1 (A-male to Micro-B male locking) for fast image transfer and power over USB (5V, ~3.6W)
- Controls and Features: Programmable integration time (14μs to 76 min), rolling shutter with global reset, automatic/manual exposure and white balance, in-sensor gain up to 45 dB, selectable 8 or 12-bit output
- Physical: Compact camera head weighing 108g, dimensions 41.5 mm (L) x 45 mm (W) x 45 mm (H), C-mount lens adapter
- Operating Conditions: Temperature 0°C to 50°C, humidity 10%-70% non-condensing
- Optical: Large field of view suited for low magnification, recommended 1X coupler to optimize cost-efficiency
- Software: Includes INFINITY ANALYZE microscopy software (version 7.0.3 or higher), compatible with Windows and Mac and supports plugins for MetaMorph and MicroManager
- Package Contents: INFINITY8-20C camera, 3 m USB 3 cable (locking), software DVD with TWAIN driver and documentation
This instrument delivers ultra-high resolution imaging with excellent color fidelity and performance suited for detailed sample analysis in microscopy.
Item Stats
Product details
| Image Sensor | SONY IMX183; CMOS format, color, 1” diagonal |
| Effective Pixels | 5472×3648, 2.4μm square pixels |
| Frame Rate | 20 fps maximum at full resolution in 8-bit; 10 fps in 12-bit |
| Signal/Noise | 41.7 dB |
| Digital Output | 8 or 12-bit |
| Read Noise | 3.4 e- |
| Mass | 108g |
| Power Requirement | 5V via Power Over USB3 Cable. |
| Power Consumption | ~3.6 Watts |
| Operating Temperature | 0° C to 50° C |
| Operating Humidity | 10%-70%, Non-condensing |
| Integration Time | Programmable in increments of 1μs; minimum (in μs) is 14 μs maximum is 76 minutes; Pulse controlled via Trigger pulse width. |
| Shutter | Rolling Shutter with Global row reset function |
| ROI | Full Frame |
| Exposure Mode | Automatic / Manual |
| White Balance | Automatic / Manual |
| Gain | In-sensor Gain; 45 dB |
| Interface Connector | USB 3.1 connector, A-male to computer |
| Dimensions (L x W x H) | 41.5 mm (max) x 45 mm x 45 mm |
| Lens Mount | C-Mount lens adapter |
| Binning Options | 2 x 2 |
