Heidolph Hei-VAP Expert HL/G3 Non Coated Hand Lift w/ G3 Vertical Glassware

Marshall Scientific$9,984.00 (ex VAT)
item image

Description by the supplier

Heidolph Hei-VAP Expert HL/G3 Non Coated Hand Lift w/ G3 Vertical GlasswareFeatures

- Rotation speed range of 10 to 280 RPM

- Heating bath temperature range of 20°C to 210°C

- Conveniently adjust the angle of inclination between 20° and 80° with a maximum height of 160mm

- Multilingual menu and text display for error messages

- Integrated solvent library to facilitate adjustment of the required vacuum on an external vacuum controller

- Smart functions include timer and maximum temperature limitation

- Optional display of vapor temperature

- Highly resistant PTFE vacuum seals achieve maximum tightness and reduce expensive spare parts

- Available in hand lift or motor lift models

- USB and Micro SD interfaces featured




5" touch screen display with clear display of all values, featuring basic and advanced views, along with additional smart functions


Separate knobs for rotation and heating with locking function to prevent accidental adjustments, along with LED ring lights


Safety heating bath with overheat and dry run protection, featuring ergonomic handles for easy removal/disposal of contents



The Hei-VAP Series of rotary evaporators was developed with an emphasis on the essentials: well thought-out details with a focus on features and functions to facilitate everyday laboratory work. Standard models are designed without vacuum control. These systems are for integration into an existing vacuum system or for configuration with optional vacuum controller. Precise setting of rotation speed and heating bath temperature on the digital touch display or – for quick access during an active process – directly via the knobs on the operating panel.


All Hei-VAP rotary evaporators have a safety heating bath with overheating and dry running protection, ergonomic handles, double wall and an integrated spout. Separate knobs with intuitive LED ring light system not only allow visual process control, but also direct intervention in the evaporation process at any time. The residual heat indicator operates when the function is deactivated and in standby mode, flashing and the display of the residual heat warn of the risk of burns (50 °C).



Click Here to View Product Video


INCLUDED:

The Heidolph Hei-VAP Expert HL/G3 Non Coated Hand Lift w/ G3 Vertical Glassware includes:

- Heating Bath

- Control Panel

- G3 Vertical Glassware

- 1 Liter Receiving Flask

- 1 Liter Evaporating Flask

- Vapor Tube

- Vacuum Seal

- Power Cord

- Operator's Guide

- Full 3 Year Manufacturer's Warranty

Product details
LiftHand lift
Rotation speed range10 - 280 rpm
Rotation speed indicator5" LCD color graphic display
Heating capacity1,300 W
Overheat protection bathcut-off at 5 °C over set temperature via separate PT 1000
Bath temperature setting5" LCD color graphic display
Heating bath temperature controlelectronic / digital
Max. size evaporating flask5 l
TimerYes
Programmable rampsYes
Condensing surface1,400 cm²
Condensing surface XL condenser2,200 cm²
