Square Wave Pulse Ranges
Voltage Range: LV Mode 5 to 500/1 V res, HV Mode 505 to 3000/5 V res
Voltage Accuracy: LV Mode 5%, HV Mode 5%
Pulse Length Range: LV Mode 10 µs to 999 µs/ 1 µs res, 1 ms to 999 ms/1 ms res, HV Mode 10 µs to 600 µs/1 µs
Multiple Pulsing: LV Mode 1 to 120 (10 per sample), HV Mode 1 to 36 (3 per sample), Pulse Interval 0.1 s to 10 sec
Capacitance in µF: LV Mode 3775 µF, HV Mode 85 µF, Voltage Droop 20% Load < 1 K Ω, 10% Load > 1 K Ω
Exponential Decay Pulse Ranges
Voltage Range: LV Mode 5 to 500/1 V res, HV Mode 505 to 3000/5 V res
Voltage Accuracy: LV Mode 5%, HV Mode 5%
Time Constant Range: LV Mode 1 ms to 5.158 S, HV Mode 0.5 ms to 133.875 ms
Multiple Pulsing: Multiple Pulsing 1 to 12 (Rint <100 ohm), 1 to 24 (Rint >100 ohm), Pulse Interval 5 to 30 sec
Capacitance in µF: LV Mode 25 to 3275 µF/25 µF res, HV Mode 10, 25, 35, 50, 60, 75, 85 µF
Internal Resistance (in parallel with load): LV 25 to 1575 Ω / 25 Ω res, HV 50 to1575 Ω / 25 Ω res
Sample Resistance (Load) Exponential Decay or Square: LV Mode PL ≤ 100ms, load ≥ 8-9 Ω, PL >100ms, load ≥100 Ω, HV Mode Load ≥ 40 Ω
Charging Time: LV < 7 sec, HV < 4 sec
Monitoring: Pulse Voltage, Width, Droop % and Sample Resistance
Programmability: Storage over 1000 Protocols
Arc Control: Yes
Interlock Switches: Yes
Pre-Pulse Sample Resistance Check: Yes
Pulse Over Current Protection: Yes
PC Control: Yes
PC Communications: Yes
Log Report: Yes
Remote Operation: Yes
Foot Switch Control: Yes
Dimensions (HxWxD): 324 x 286 x 216 mm
Weight: 7.3 kg
