Agilent
Model
Agilent G1316B TCC SL Thermostatted column compartment
Location
Berkel en Rodenrijs - Netherlands
This item is
for sale
State of item
used
Categories

Agilent G1316B TCC SL Thermostatted column compartment

item image

Description from the supplier

For sale: refurbished Agilent 1200 Series G1316B TCC SL Thermostatted Column Compartment

Also available:
Agilent 1100 series G1316 Thermostatted column compartment (TCC)
Agilent 1100 series and 1200 series modules like pump, degassers, detectors, autosamplers
Complete 1100 and 1200 series HPLC systems

We are not a agent/reseller. All products on our website are in stock and can be delivered with installation by our own service engineers. All systems are delivered with warranty!
The Agilent 1200 Series thermostatted column compartments are stackable
temperature-controlled column compartments for LC. They are available as
standalone modules or as a component of a Agilent 1200 Series system. They
are used for heating and cooling to meet extreme requirements of retention
time reproducibility.
The main features are:
• Peltier heating and cooling from 10 degrees below ambient up to
80 °C(G1316A) or 100 °C (G1316B SL/G1316C SL Plus) with high heating
and cooling speeds for maximum application flexibility and stability,
• holds up to three 30-cm columns and optimized design gives minimum dead
volumes and maximum efficiency,
• two independently programmable heat exchangers contribute volumes of
only 3 and 6 µl,
• G1316B SL features additional heating and cooling devices for low flow
rates, which reduce the risk of additional dispersion,
• G1316B SL and G1316C SL Plus can be supplemented by a kit to install a
small heat-exchanger with 1.6 µl delay volume to reduce the delay volume.
In additon a cooling device with 1.5 µl is available,
• electronic column-identification module as standard for GLP
documentation of column type, and major column parameters,
• optional high-quality Rheodyne® column switching valves with ceramic
stator-face assemblies for prolonged lifetime.
