IKA KS 3000ic Incubator Shaker
Type of Movement
Orbital
Temperature Setting Range
12°C - 80 °C
Speed Range
10 to 500 RPM
Features
- Large LED display for speed and time settings
- Controls with antimicrobial coating for reduction of bacteria
- Integrated PID temperature control (use of two PT 1000 temperature sensors)
- Junction box in the workspace for connection of an additional temperature sensor e.g. PT 1000.60
- Electronic temperature and speed control
- Electronic timer switch: 0 – 999 h (set by the minute or by the hour)
- Optional built-in cooler for connection to an external cooling unit e.g. RC 2 basic / control
- Unit switches off automatically if disturbed
- Unit stops automatically when hood is lifted
- Collecting tray with drain hose on rear of unit
- Simple operation
- All functions can be controlled and documented with labworldsoft
- Attachments are not included in delivery, please order seperatly
This advanced incubator shaker combines innovative design with precise temperature control, allowing for unattended operation in your lab. Featuring orbital movement with a 20 mm stroke and a shaking capacity of 7.5 kg, it offers a speed range of 10 to 500 rpm, displayed on an LED screen. The integrated timer ranges from 1 second to 59940 minutes, supporting both continuous and timed operations. With a heating range of 12°C to 80°C and a 50-liter chamber, this unit ensures accurate and stable temperature control, making it perfect for a variety of laboratory applications.
INCLUDED:
The IKA KS 3000ic Incubator Shaker includes:
- KS 3000 ic control
- PT 1000.80 Temperature sensor, stainless steel
- Clamping screws short (4 pcs.)
- PC 1.1 Cable
- USB A-B Cable
- Power Cord
- Operator's Guide
- Manufacturer's Documentation
- 2 Year Manufacturer Warranty ( + Additional Free 1 Year Warranty Extension with IKA Registration)
IKA KS 3000ic Incubator Shaker SpecificationsType of movementorbitalShaking stroke20 mmPermissible shaking weight (incl. attachment)7.5 kgMotor rating input45 WMotor rating output10 WPermissible ON time100 %Speed min (adjustable)10 rpmSpeed range10 - 500 rpm Speed display LED Speed deviation 1 %Speed control1 RPM stepsTimeryesTimer display7 segment LEDTime setting min.1 sTime setting range1 - 59940 minOperating modetimer and continuous operationHeat output1000 WSet temperature resolution0.1 ±KControl accuracy with sensor (1 vessel 0.5 L H2O, RT 22°C, T=37°C)0.5 ±KTemperature displayyesTemp. stability (0,2l H2O; RT 25°C, T=37°C)0.1 ±KTemperature range (inlet T>3°C)12 - 80 °COperating area inner chamber330 x 330 x 258 mmTotal volume inner chamber50 lRaw material housingSheet metal powder coatRaw material hoodPMMARaw material front foilpolyesterRaw material front panelABS paintedTemperature stability (1 vessel 0.5 L, RT 25°C, T=37°C)0.05 ±KTemperature homogenity (5 vessel 0.5 L; RT 25°C, T=37°C)0.5 ±KHeight with open hood875 mmDimensions (W x H x D)465 x 430 x 695 mmWeight37 kgPermissible ambient temperature15 - 32 °CPermissible relative humidity80 %Protection class according to DIN EN 60529IP 30RS 232 interfaceyesUSB interfaceyesVoltage230 / 115 / 100 VFrequency50/60 HzPower input1120 WComparison of ModelsSpecificationIKA KS 3000iIKA KS 3000icIKA KS 4000iIKA KS 4000icShaking Stroke20 mm20 mm20 mm20 mmPermissible Shaking Weight (incl. attachment)7.5 kg7.5 kg20 kg20 kgMotor Rating Input45 W45 W82 W82 WSpeed Range10 - 500 rpm10 - 500 rpm10 - 500 rpm10 - 500 rpmSpeed Deviation0.010.015 ±rpm5 ±rpmTimerYesYesYesYesTime Setting Range1 - 59940 min1 - 59940 minNot specifiedNot specified.comparison-table tr td:nth-child(3) { background-color: #fffacd; }DownloadsTechnical Specification Download
Operator's Manual Download
Request a Formal Quote
Type of movement | orbital |
Shaking stroke | 20 mm |
Permissible shaking weight (incl. attachment) | 7.5 kg |
Motor rating input | 45 W |
Motor rating output | 10 W |
Permissible ON time | 100 % |
Speed min (adjustable) | 10 rpm |
Speed range | 10 - 500 rpm |
Speed display | LED |
Speed deviation | 1 % |
Speed control | 1 RPM steps |
Timer | yes |
Timer display | 7 segment LED |
Time setting min. | 1 s |
Time setting range | 1 - 59940 min |
Operating mode | timer and continuous operation |
Heat output | 1000 W |
Set temperature resolution | 0.1 ±K |
Control accuracy with sensor (1 vessel 0.5 L H2O, RT 22°C, T=37°C) | 0.5 ±K |
Temperature display | yes |
Temp. stability (0,2l H2O; RT 25°C, T=37°C) | 0.1 ±K |
Temperature range (inlet T>3°C) | 12 - 80 °C |
Operating area inner chamber | 330 x 330 x 258 mm |
Total volume inner chamber | 50 l |
Raw material housing | Sheet metal powder coat |
Raw material hood | PMMA |
Raw material front foil | polyester |
Raw material front panel | ABS painted |
Temperature stability (1 vessel 0.5 L, RT 25°C, T=37°C) | 0.05 ±K |
Temperature homogenity (5 vessel 0.5 L; RT 25°C, T=37°C) | 0.5 ±K |
Height with open hood | 875 mm |
Dimensions (W x H x D) | 465 x 430 x 695 mm |
Weight | 37 kg |
Permissible ambient temperature | 15 - 32 °C |
Permissible relative humidity | 80 % |
Protection class according to DIN EN 60529 | IP 30 |
RS 232 interface | yes |
USB interface | yes |
Voltage | 230 / 115 / 100 V |
Frequency | 50/60 Hz |
Power input | 1120 W |
