Luminex 100 Flow Cytometry System for Multiplex Bioassay Analysis

The Luminex 100 Flow Cytometry System is a versatile, microplate-based analyzer designed for high-throughput multiplex bioassays. Utilizing advanced xMAP Technology, it integrates:

This system simultaneously quantifies up to 100 analytes per sample (80 with magnetic MagPlex beads), achieving a dynamic range of ≥3.5 logs and immunoassay sensitivity as low as 0.061 pg/mL. The instrument reads a 96-well plate in under 45 minutes, supporting throughput up to 12,800 tests per hour, with startup/shutdown times of 30 minutes or less.

Compact and robust, measuring 425 x 320 x 595 mm and weighing 49 kg, the Luminex 100 includes an integrated PC workstation. Its multiplex capability suits molecular diagnostics, immunology, biotechnology, and synthetic biology research, including gene editing assays, bioprocess monitoring, and molecular cloning workflows. Widely adopted in clinical diagnostics and biopharmaceutical production pipelines, it enables efficient, sensitive, and cost-effective multiplex analysis critical for advanced biomedical engineering and biotechnology applications.
