Contact Angle Measuring Devices OCA

Number of stirring positions: 1 Stirring quantity max. per stirring position (H2O): 15 l Maximun loa (more)d: 20 kg Speed adjustment: scale 0 – 6 Speed range: 100 – 1500 rpm Stirring bar length max: 80 mm Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h): +1 K Heating temperature range: 50 – 500°C Heat control: Turning knob Temperature setting resolution of heating plate: 5 K Connection for ext. temperature sensor: PT1000 (not included) Fixed safety circuit: 550°C Set-up plate material: ceramic Set-up plate dimensions: 260 x 260 mm Heating rate (1l H2O in H1500): 5 K/min Dimensions (WxHxD): 300 x 105 x 415 mm Weight: 8.308 kg

Programmable flow rate: 0.00 to 5.00 mL/min, 0.01 mL/min increments Maximum operating pressure: 401  (more)bar Pressure ripple: <2% at 0.5mL/min Flow precision: 2 seconds SD Flow accuracy: 2% of setting Gradient accuracy: <1% between 10 to 90% Gradient precisison: <0.5% RSD between 10 to 90% Gradient delay volume: <60 µL (without mixer), <200 µL (with one 50 µL mixer) Inline degasser channels: 2 Dimensions (HxDxW): 430 x 610 x 305 mm Weight: 27.2 kg

Temperature range refrigerator: 2°C to 11°C Temperature range freezer: -18°C to -26°C Dimensions (Hx (more)WxD): 1850 x 600 x 620 mm Internal dimensions refrigerator (HxWxD): 800 x 500 x 400 mm Internal dimensions freezer (HxWxD): 760 x 450 x 400 mm Capacity refrigerator: 183 L Capacity freezer: 121 L
