Yamato GLD-137CC, 115V Rotary Vane Pump with Rubber Hose Kit, 115V

$3,831.00 (ex VAT)
item image

Description from the supplier

Yamato GLD-137CC, 115V Rotary Vane Pump with Rubber Hose Kit, 115V


Ultimate Pressure
6.7 x 10-3 mbar
Actual Pumping Speed
135 L/min (50Hz) 162 L/min (60Hz)
Weight
27 kg

  • Voltage: 115V
  • Actual pumping speed (CFM): 5.72
  • High performance, low vibration, and noise
  • Oil-back-flow prevention mechanism
  • Large-sized oil level gauge
  • Equips multi-voltage motor and corresponds to international standard
  • Hose Clamp
  • Rubber Hose ID: 16mm/1500mm
  • Hose Port Type Suction Pipe OD: 18mm x M20
  • 50mm Square Adapter for Suction Port
  • Oil Mist Trap
  • Power Cord
  • One Year Manufacturer's Warranty

Product details

Actual Pumping Speed135 L/min (50Hz) 162 L/min (60Hz)
Ultimate Pressure (mbar)G.V. Closed : 6.7 × 10-3 G.V. Open : 0.07
Weight27 (kg)
Inlet Port DiameterKF-25
Overall Dimensions170(W) × 488(L) × 250(H)
