Polyscience 3370P9A11B Model 3370 Liquid-to-Air Recirculating Cooler with Positive Displacement Pump, 120V, 60Hz

$2,405.00 (ex VAT)
item image

Description from the supplier

Polyscience 3370P9A11B Model 3370 Liquid-to-Air Recirculating Cooler with Positive Displacement Pump, 120V, 60Hz3D Visualization of the Polyscience Recirculating CoolerThe rendered image can be freely rotated in a full 360-degree view, allowing you to zoom in, pause, and explore every angle. For enhanced detail, the rendering can also be displayed in full-screen mode.
This 3D model is designed exclusively for visualization purposes and may not accurately represent the actual appearance of your product.
Your browser does not support iframes.

This Liquid-to-Air Recirculator continuously pumps near-ambient temperature water from a reservoir to an external heat source, through a cooling radiator, and then returns cooled water to the reservoir. By blowing ambient air over the radiator, water flowing inside is cooled and the heat is exhausted into the atmosphere.Features

An economical solution for applications where cooling fluid temperature is higher than ambient and temperature control is not required
NOTE: No compressor. Uses fan cooling of cooling fluid
Quiet liquid-to-air cooling
Positive displacement or turbine pump
Built-in low liquid level indicator

  • Power Cord
  • Operator's Guide
  • Manufacturer's Documentation
  • 2 Year Manufacturer's Warranty

Product details

DescriptionLiquid-to-Air Cooler, Positive Displacement Pump
Working Temperature Range °CAmbient +5° to 70°C
Pump TypePositive Displacement
Part Number3370P9A11B
Maximum Pressure (psi)100.0
Maximum Pressure (bar)6.90
Maximum Pressure Flow Rate (gpm)2.40
Maximum Pressure Flow Rate (l/min)9.1
Cooling Capacity @ 20°C (W)500 based on 2°C △T 1000 based on 4°C △T 2000 based on 8°C △T 3000 based on 10°C △T 4000 based on 11°C △T △T = Process water temperature - ambient air temperature
Included HardwareTwo sets of Inlet/Outlet Adapters: ½ inch male NPT, 5/8 inch male NPT
Electrical Requirements (VAC/Hz/Ph/A)120/60/1/5.5
Regulatory ApprovalsTUV
