Yamato SI-601 Natural Convection Dry Sterilizer 159L, Programmable, PID Control
Product Description
Yamato SI-601 Natural Convection Dry Sterilizer
- Circulation: Natural convection
- Capacity: 159 liters
- Operating Temperature Range: Room temperature +5 to 260°C
- Temperature Accuracy: ±2°C (at 260°C)
- Temperature Distribution Accuracy: ±20°C (at 260°C)
- Max Temperature Reaching Time: ~70 minutes
- Heater: Iron chromium wire, 1.36 kW
- Sensor: K-type thermocouple
- Temperature Controller: PID control with digital display
- Temperature Display:
- Measured temperature: green 4-digit LED
- Set temperature: red 4-digit LED
- Timer:
- 1 min to 99 hr 59 min
- 100 to 999 hr 30 min with timer wait function
- Programmable Functions:
- Fixed temperature
- Quick auto stop
- Auto stop
- Auto start
- Program mode: 6 patterns, up to 30 steps per program, pattern repeat function
- Safety Features:
- Self-diagnostics (sensor failure, heater disconnection, SSR short circuit, memory error, communication error, measurement error)
- Overheat prevention device
- Earth leakage breaker
- Additional Features:
- Calibration offset
- Lock function
- Power failure recovery mode
- Construction:
- Interior: Stainless steel
- Exterior: Chrome-free electrogalvanized carbon steel with chemical-proof baked finish
- Exhaust Ports: Two, I.D. 30 mm (top)
- Internal Dimensions (WxDxH): 600 x 530 x 500 mm
- External Dimensions (WxDxH): 700 x 640 x 877 mm
- Shelf:
- Material: Stainless punching metal
- Load capacity: approx. 15 kg per plate
- 2 plates and 4 brackets (bottom plate screwed in place)
- 13 shelf rest steps spaced 30 mm apart
- Power Supply: AC 115V, 11.8A, 50/60 Hz (with plug)
- Weight: approx. 59 kg
Item Stats
Product details
| Circulation Method | Natural convection dry laboratory sterilizers |
| Operating Temp. Range* | Room temp. +5~260°C |
| Temp. Adjustment Accuracy | 2°C (at 260°C) |
| Temp. Distribution Accuracy | 20°C (at 260°C) |
| Max. Temp. Reaching Time | ~70min. |
| Interior / Exterior | Stainless steel / Chrome free electrogalvanized carbon steel sheet coated with chemical-proof baked-on finish |
| Heater | Iron chromium wire heater / 1.36kW |
| Sensor | K type Thermocouple |
| Exhaust Port | I.D.30 mm x 2 (top) |
| Temp. Controller | PID control |
| Temp. Display | Measured temp. display: green 4 digit LED digital display / Setting temp. display: red 4 digit LED digital display |
| Timer | 1 min~99hr 59 min and 100~999 hrs 30 min. (with timer wait function) |
| Operation Function | Fixed temperature, quick auto stop, auto stop, auto start, program (6 pattern: 30 steps x 1, 15 steps x 2, 10 steps x 3, pattern repeat function) |
| Additional Functions | Lock function, auto recovery after power failure, calibration off-set |
| Safety Device | Self diagnostic functions (temp. sensor failure, heater disconnection, SSR short circuit, memory error, internal communication error, measurement temperature error, automatic overheat prevention), overheat prevention device, earth leakage breaker |
| Internal Dimensions WxDxH | 600 x 530 x 500 mm |
| External Dimensions WxDxH | 700 x 640 x 877 mm |
| Internal Capacity | 159L |
| Shelf Plate With Standard Load | ~15 kg/pc. |
| Shelf Rest Step Number / Pitch | 13 steps / 30 mm |
| Power Source (50/60Hz) | AC115V 11.8A (with plug) |
| Weight | ~59 kg |
| Shelf Plate Material | Stainless punching metal |
| Shelf Plate / Bracket | 2pcs./4pcs. (bottom one is screwed) |
