Moticam 4000 4K Microscope Camera with HDMI, USB, and SD Card Storage
Product Description
- Sensor type: CMOS IMX334
- Sensor size: 1/1.8" (8.86 mm)
- Imaging area: 7.68 x 4.32 mm
- Capture resolution: 8MP (3840 x 2160 pixels) for images and video on SD card
- Live display resolution: 4K (3840 x 2160 pixels) via USB and HDMI
- Pixel size: 2.0 x 2.0 µm
- Scan mode: Progressive
- Shutter mode: Rolling shutter
- Data transfer interfaces: HDMI, USB, SD card slot
- Max frame rates: HDMI – 4K @ 30 fps; USB – 4K @ 20 fps (under optimal lighting/computer specs)
- Exposure time range: 0.04 to 1000 ms
- Operating temperature: -10 to +50 °C, non-condensing
- Sensitivity: 505 mV at 1/30s; 0.1 mV at 1/30s
- Lens mount: C-Mount, includes focusable 12 mm lens
- Software: Motic Images Plus 3.1 for Windows, OSX, Linux; onboard software enables live measurements and adjustments
- Functions: Exposure, gain, white balance, color adjustment, sharpness, denoising, zoom, mirror, comparison, freeze, measurement, crosshair, browser mode
- Power supply: External 12 V
- Package includes: CS ring adapter, focusable lens, 30 mm and 38 mm eyepiece adapters, 4-dot calibration slide, macro calibration card, macro tube, universal power supply, HDMI cable, USB cable, USB mouse, USB flash drive with software
- Minimum PC requirements: Core 2 processor 2.8 GHz, 8 GB RAM
- Connects directly to HDMI screens for live viewing and operation without a PC; supports USB connection to Windows and Mac computers for simultaneous display and data transfer.
Item Stats
Product details
| Model | Moticam 4000 |
| Sensor type | CMOS IMX334 |
| Sensor size | 1/1.8"(8.86mm) |
| Imaging area | 7.68x4.32mm |
| Capture resolution info | 8MP (3840x2160 pixels) |
| Image capture resolution (on SD-card) | 8MP (3840x2160 pixels) |
| Video capture resolution (on SD-card) | 4K (3840x2160 pixels) |
| Live display mode through USB | 4K (3840x2160 pixels) |
| Live display mode through HDMI | 4K (3840x2160 pixels) |
| Pixel Size | 2.0x2.0μm |
| Scan mode | Progressive |
| Shutter mode | Rolling Shutter |
| Data transfer | HDMI, SD card, USB (data storage) |
| Max. frames per second (fps*) | HDMI: 4K (3840x2160) @ 30fps ; USB: 4K (3840x2160) @ 20fps |
| Exposure time | 0.04~1000ms |
| Operating temperature | From -10 to +50 Degrees Celsius non-condensing |
| Sensitivity | 505mV with 1/30s; 0.1mV with 1/30s |
| Slot | SD Card |
| Buttons | On/Off |
| Supported OS | Windows 7/8/10, MAC OSX or higher |
| Minimum computer requirements | Core2, 2.8GHz, RAM memory 8GB |
| Lens mount | C-Mount |
| Focusable lens | 12mm |
| Software | Motic Images Plus 3.1 for Windows, OSX and Linux, on board software |
| Functions | Including exposure, gain, white balance, colour adjustment, sharpness and denoising control, zoom, mirror, comparison, freeze, measure, cross, browser function |
| Power supply | 12V (External Power supply) |
| Package includes | CS ring adaptor, focusable lens, 30mm and 38mm eyepiece adapters, Motic 4-dot calibration slide, macro calibration card, macro tube, universal power supply, HDMI cable, USB cable, USB Mouse and USB Pendrive with Motic Image Plus 3.1 |
