Lumenera INFINITY 5-5M Microscope Camera with Sony Pregius CMOS Sensor
Product Description
- Utilizes Sony IMX252 Pregius global shutter CMOS sensor with 2/3” optical format
- Resolution of 2464 x 2056 pixels with 3.45 x 3.45 μm pixel size
- Supports fast frame rates of approximately 75 fps at full resolution (8-bit)
- Dual digital output: USB 3.0 (high-speed USB 3.1 Gen 1) and HDMI compatible monitor output
- Selectable 8-bit or 12-bit pixel data output
- Low read noise of approximately 2.30 electrons and signal-to-noise ratio >72 dB
- Controls include manual and automatic exposure, gain (1-16x), white balance, and ROI full frame
- Integration times range from 42 μs to 59.5 msec (snapshot) and 14 μs to 14 sec (video)
- Camera weight: 330 g; Dimensions: 3.85 x 2.75 x 2.25 inches
- Power requirements: 5 V DC, 1.2 A external supply included; typical power consumption ~4 W
- Operating temperature: 0°C to 50°C; Operating humidity: 5%-95%, non-condensing
- Interface connectors: USB 3.0 and HDMI output; lens mount: C-Mount adapter
- Includes 2 x 2 binning options
- Compatible with Windows 7/8.1/10, Mac OS X 10.13, 32- and 64-bit systems
- Software support: Lumenera INFINITY Capture, third-party software MetaMorph, Micro-Manager, MatLab, LabView, TWAIN, and DirectShow interfaces
- Package includes: INFINITY5-5 camera, USB 3m cable, HDMI 3m cable, power supply, and software DVD
- Backed by a 4-year full warranty
Item Stats
Product details
| Image Sensor | SONY IMX250; CMOS format, monochrome, diagonal 11.1mm array |
| Effective Pixels | 2464×2056, 3.45μm square pixels |
| Frame Rate | 1080P60 (~75 fps at full resolution) in 8-bit |
| Signal/Noise | >72dB |
| Digital Output | 8 or 12-bit |
| Read Noise | ~ 2.30 e- |
| Mass | 330g |
| Power Requirement | External 5VDC – 1.2A, power supply (included) |
| Power Consumption | ~4Watts |
| Operating Temperature | 0° C to 50° C |
| Operating Humidity | 5%-95%, Non-condensing |
| Integration Time | 42μs to 59.5m (snapshot); 14μs to 14s (video) |
| Shutter | Global Shutter |
| ROI | Full Frame |
| Exposure Mode | Automatic / Manual |
| White Balance | Automatic / Manual |
| Gain | ~1 to 16x; manual and automatic |
| Interface Connector | USB 3.0 connector, HDMI output |
| Dimensions (L x W x H) | 3.85 x 2.75 x 2.25 inches |
| Lens Mount | C-Mount lens adapter |
| Binning Options | 2 x 2 |
