Scilogex D160 Homogenizer Package - Drive Motor DS-160/10

$959.00 (ex VAT)
item image

Description from the supplier

Scilogex D160 Homogenizer Package - Drive Motor DS-160/10 The Scilogex D160 Homogenizer can rapidly homogenize, disperse, and emulsify samples from 0.1-250ml solids or liquid media depending on the generating probe. During operation, the suspended material is drawn into the core of the homogenizer by a rotor turning at up to 30,000rpm. The material is repeatedly cycled through narrow slits in the probe where it is rapidly sheared and disintegrated by high shear. Complete homogenization of tissues (muscle, liver, breast tissue, etc.) is usually achieved in a few seconds. Little, if any, heat is produced during the process. Package includes: Drive motor- DS-160/10, 10mm diameter generator, flat head open slot, 115mm immerse length, H-370 stand.

  • H-370 Stand
  • D160 Drive Motor
  • 10mm Dia. Generator Probe
  • 115mm Generator Shaft
  • Holding Clamp
  • Power Cord
  • Operator's Guide
  • Manufacturer's Documentation
  • 1 Year Manufacturer's Warranty

Product details

Speed range8,000-30,000rpm
Sample volume range0.1 - 250ml
Speed control6 position control dial
Motor typeUniversal motor, 130 Watt
pH range2-13
FinenessSuspensions & Emulsion 10-15 & 1-10um
Noise emission54 dB(A) at 30,000 rpm
Dimensions2.5L x 2.5W x 8H inches (drive only)
Weight18lbs (with stand) 1.5lbs (drive only)
Voltage110Volts, 60Hz
