Yamato DVS-602C Programmable Natural Convection Oven 162L, 115V

$3,036.00 (ex VAT)
item image

Description from the supplier

Yamato DVS-602C Programmable Natural Convection Oven 162L, 115V


Temperature Range
Ambient +5°C to 260°C
Temperature Distribution Accuracy
± 5.0°C at 260°C
Chamber Volume
162L

  • Excellent temperature accuracy
  • Easy to use and maintain
  • Equipped with a 6 pattern PID program controller with easy program settings (30 steps x 1, 15 steps x 2, 10 steps x 3)
  • Simultaneous display of set constant and measured temperature
  • Quick Auto stop, Auto Stop, Auto Start operations
  • Increased safety and self-diagnostic functions
  • Calibration off-set function

The Yamato DVS-402C Programmable Natural Convection Oven 99L, 115V offers excellent temperature accuracy and user-friendly operation. It features a 6 pattern PID program controller, capable of executing complex programs (30 steps x 1, 15 steps x 2, 10 steps x 3), and displays both set and measured temperatures simultaneously. This oven operates within a temperature range of room temperature +5 to 260°C, achieving temperature control accuracy of ±1.0°C and distribution accuracy of ±5.0°C at 260°C. It can reach its maximum temperature in approximately 90 minutes.

Constructed with a stainless-steel interior and a cold rolled steel plate exterior with a melamine resin baking finish, the DVS-402C is easy to maintain. It features glass wool insulation, a 1.2kW stainless pipe heater, and includes an observation window made of chemically strengthened glass. Additional features include a cable hole, exhaust ports, a comprehensive timer, and various operation functions like Auto Start, Auto Stop, and Quick Auto-stop. Safety is ensured with self-diagnostic functions and an electric leakage breaker with overcurrent protection. The internal dimensions are 450×490×450mm, external dimensions are 560×601×820mm, and it can support a shelf plate load of about 15kg. The DVS-402C is ideal for precise, programmable heating applications.

  • 2 x Stainless Steel Shelves w/ Brackets
  • Power Cord
  • Operator's Manual
  • Manufacturer's Documentation
  • 1 Year Manufacturer's Warranty

Product details

Circulation methodNatural convection
Operating temp. rangeRoom temp.+5 to 260°C
Temp. control accuracy±1.0°C (at 260°C)
Temp. distribution accuracy±5.0°C (at 260°C)
Max. temp. reaching time~90 min. (Room temp. +5°C to 260°C)
Interior materialStainless steel
Exterior materialCold rolled steel plate with melamine resin baking finish
Heat insulating materialGlass wool
HeaterStainless pipe heater / 1.36kW
Observation window250×280 mm Chemically strengthened glass x 3
Cable hole30 mm l.D.×1 pcs. (right side)
Exhaust port30 mm l.D.×2 pcs. (on top)
Temp. controller3 patterns program controller, PID control by microprocessor
Temp. setting methodOperation menu key and Digital setting by ▲/▼ key
Temp. display methodMeasurement temp. : Digital display by green LED / Setting temp. : Digital display by red LED
Timer1 min. to 99 Hrs. 59 min. and 100 Hrs. to 999 Hrs. 50 min.
Operation functionFixed temperature operation, Program operation, Auto start, Auto stop, Quick Auto-stop
Program modeProgram operation: 6 pattern, 30 steps (30 steps×1, 15 steps×2, 10 steps×3)
Additional functionsCalibration off-set function, Key lock, Uninterruptible power for memory, Pattern repeat function
Heater circuit controlSSR control
SensorK-thermocouple
Safety deviceSelf diagnostic functions (temp. sensor abnormal, Heater disconnection, SSR- short, Memory abnormal, Automatic overheating prevention), Overheat prevention, Electric leakage breaker with over current protection
Internal dimensions (W×D×Hmm)600×540×500
External dimensions (W×D×Hmm)710×651×870
Internal capacity162L
Shelf plate load~15kg / pcs.
Shelf rest step number / pitch13 steps / 30mm
Power source 50/60HzAC115V 13.5A (with plug)
Weight~63kg
