Heidolph Hei-VAP Expert Control HL/G3B Coated Hand Lift w/ G3 XL Vertical Glassware

$13,667.00 (ex VAT)
item image

Description from the supplier

Heidolph Hei-VAP Expert Control HL/G3B Coated Hand Lift w/ G3 XL Vertical GlasswareThe Hei-VAP Series of rotary evaporators was developed with an emphasis on the essentials: well thought-out details with a focus on features and functions to facilitate everyday laboratory work. Hei-VAP Expert Control and Ultimate Control allow to centrally control all process parameters: vacuum, cooling temperature, rotation and heating bath temperature. Promising intuitive operation as all settings are configured centrally on the operating panel. In combination with the Control-Box, the panel can even be used as the central control unit to regulate the vacuum and the Hei-CHILL recirculation chiller as well.

All Hei-VAP rotary evaporators have a safety heating bath with overheating and dry running protection, ergonomic handles, double wall and an integrated spout. Separate knobs with intuitive LED ring light system not only allow visual process control, but also direct intervention in the evaporation process at any time. The residual heat indicator operates when the function is deactivated and in standby mode, flashing and the display of the residual heat warn of the risk of burns (50 °C).

Features:

  • 5" touch display
  • Clear display of all values (Basic/Advanced modes)
  • Timer
  • Max. temperature limitation
  • Multilingual menu with text alerts
  • Optional display of vapor temperature
  • USB and Micro SD plus LAN/RS 232 interfaces (Lab 4.0ready)
  • Control of any vacuum sources and Heidolph recirculation chillers
  • Solvent library
  • Favorites memory
  • Dynamic AUTOaccurate (DAA)
  • Ramp programming

Click Here to View Product Video

  • Heating Bath
  • G3B XL Vertical Glassware
  • Control Panel
  • 1 Liter Receiving Flask
  • 1 Liter Evaporating Flask
  • Vapor Tube
  • Vacuum Seal
  • Vacuum Valve
  • Power Cord
  • Operator's Guide
  • Full 3 Year Manufacturer's Warranty

Product details

LiftHand lift
Rotation speed range10 - 280 rpm
Rotation speed indicator5" LCD color graphic display
Heating capacity1,300 W
Overheat protection bathcut-off at 5°C over set temperature via separate PT 1000
Bath temperature setting5" LCD color graphic display
Heating bath temperature controlelectronic / digital
Max. size evaporating flask5 l
Integrated vacuum controllerYes
TimerYes
Integrated Hei-CHILL controllerYes
Vacuum program Dynamic AUTOaccurate requires AUTOaccurate sensorYes
Programmable rampsYes
Condensing surface1,400 cm²
Condensing surface XL condenser2,200 cm²
