Memmert UN160 Natural Convection Oven 161L, 115V

$4,057.00 (ex VAT)
item image

Description from the supplier

Memmert UN160 Natural Convection Oven 161L, 115V


Temperature Range
Ambient +5°C to 300°C
Convection Type
Natural Convection
Chamber Volume
161 L

  • Large 161 L (6 cu.ft.) stainless steel chamber for versatile storage
  • Temperature range from +5°C above ambient to +300°C for diverse applications
  • 1 Pt100 sensor DIN class A in 4-wire circuit for precise monitoring
  • SingleDISPLAY digital PID-microprocessor controller with high-definition TFT display
  • Natural convection system for even heat distribution
  • Electronically adjustable air flap for controlled fresh air admixture
  • Supports up to 8 stainless steel grids with a max load of 463 lbs
  • Auto diagnostic system with electronic overtemperature monitor for reliable safety


The Memmert UN160 Natural Convection Oven 161L, 115V is designed to meet versatile laboratory needs with a spacious 161 L (6 cu.ft.) stainless steel chamber that accommodates a variety of samples. With a precise temperature range from +5°C above ambient to 300°C, the oven is equipped with a Pt100 sensor DIN class A in a 4-wire circuit, ensuring reliable temperature control. The SingleDISPLAY digital PID-microprocessor controller provides easy adjustments via a high-definition TFT display, while the natural convection system maintains uniform heat distribution throughout the chamber. An electronically adjustable air flap allows controlled fresh air flow, and the oven supports up to 8 stainless steel grids with a maximum load capacity of 463 lbs. Safety is enhanced with an auto diagnostic system and electronic overtemperature monitor, making this oven an ideal choice for rigorous lab environments.

  • 2 Stainless Steel Grids
  • Tilt Protection Wall Bracket
  • Calibration Certificate
  • Power Cord
  • Operator's Manual
  • Manufacturer's Documentation
  • 3 Year Manufacturer's Warranty

Product details

Internal Volume161 L (6 cu.ft.)
Temperature Range+5°C above ambient to +300°C
Sensor1 Pt100 sensor DIN class A in 4-wire-circuit
Set Temp. AccuracyUp to 99.9°C: 0.1 / From 100°C: 0.5
Control PanelSingleDISPLAY, adaptive multifunctional digital PID-microprocessor controller with high-definition TFT-colour display
Convection/FanNatural Convection
Fresh AirAdmixture of pre-heated fresh air by electronically adjustable air flap
ProgrammingAtmoCONTROL software for reading out, managing, and organizing the data logger via Ethernet interface (temporary trial version available for download)
Temp. ControlAdjustable electronic overtemperature monitor and mechanical temperature limiter TB, protection class 1 according to DIN 12880, to switch off heating approx. 20°C above nominal temperature
Humidity (rh)Max. 80%, non-condensing
InteriorEasy-to-clean stainless steel interior, reinforced with deep drawn ribbing and integrated large-area heating on four sides
Interior Dimensions (WxHxD) in.22 x 28.25 x 15.75
Exterior Dimensions (WxHxD) in.29.25 x 43.5 x 23 (d +2.25 in. door handle)
Weight212 lbs. (96 kg)
Power115 V, 50/60 Hz, approx. 1800 W
