Memmert UF160TS Forced Circulation Pass-Through Oven 161L, 115V
Description from the supplier
Memmert UF160TS Forced Circulation Pass-Through Oven 161L, 115V
Working Temperature Range
At least 10°C above ambient to +250°C
Setting Resolution (Temperature)
Up to 99.9°C: 0.1°C / From 100°C: 0.5°C
Chamber Volume
161L (5.68 Cu. Ft.)
- Working temperature range from at least 10°C above ambient to +250°C
- Volume capacity of 161L (5.68 Cu. Ft.) with stainless steel interior
- TwinDISPLAY with adaptive multifunctional digital PID-microprocessor controller and dual high-definition TFT-color displays
- Forced air circulation adjustable in 10% steps, with pre-heated fresh air admixture
- AutoSAFETY system with integrated over- and undertemperature protection
- Supports up to 8 shelves with a maximum chamber load of 462 lbs
- Three freely selectable temperature calibration points
- Function SetpointWAIT ensures process begins only once set temperature is reached
The Memmert UF160TS Forced Circulation Pass-Through Oven 161L, 115V offers advanced precision and reliability with a working temperature range from at least 10°C above ambient to +250°C. Designed with a spacious 161L (5.68 cu.ft.) interior, this oven features a stainless steel chamber reinforced with deep-drawn ribbing, providing both durability and ease of cleaning. The TwinDISPLAY control system, equipped with two high-definition TFT-color displays, allows for adaptive multifunctional temperature management, ensuring accurate control via two Pt100 sensors in a 4-wire circuit for mutual monitoring. Additional features include forced air circulation, adjustable fan speed in 10% increments, and pre-heated fresh air admixture for optimal thermal distribution.
For enhanced safety, the Memmert UF160TS includes the AutoSAFETY system, which provides integrated over- and undertemperature protection, as well as a mechanical temperature limiter (TB) that switches off heating at 20°C above the nominal temperature. The Function SetpointWAIT ensures the process begins only once the set temperature is reached, while the Function HeatBALANCE allows precise adjustment of heating performance. With a maximum loading capacity of 462 lbs, spread across up to 8 shelves, this oven is ideal for demanding laboratory applications requiring consistent, reliable performance.
- 2 Stainless Steel Grid
- Tilt Protection Wall Bracket
- Base Cladding with Screw Connection
- Calibration Certificate
- Power Cord
- Operator's Manual
- Manufacturer's Documentation
- 3 Year Manufacturer's Warranty
Product details
| Volume | 161L (5.68 Cu. Ft.) |
| Working Temperature Range | At least 10°C above ambient to +250°C |
| Setting Temperature Range | +20 to +250°C |
| Setting Resolution (Temperature) | Up to 99.9°C: 0.1°C / From 100°C: 0.5°C |
| Display Resolution (Actual Values) | 0.1°C |
| Temperature Sensor | 2 Pt100 sensors DIN Class A in 4-wire-circuit for mutual monitoring |
| Control Panel | ControlCOCKPIT TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-color displays |
| Timer | Digital backwards counter with target time setting, adjustable from 1 minute to 99 days |
| Function HeatBALANCE | Adjusts heating performance distribution between the upper and lower heating circuits from -50% to +50% |
| Function SetpointWAIT | Process time does not start until the set temperature is reached |
| Calibration | Three freely selectable temperature values |
| Fan | Forced air circulation by quiet air turbine, adjustable in 10% steps for each segment individually |
| Fresh Air | Pre-heated fresh air admixture via electronically adjustable air flap |
| Vent | Vent connection with restrictor flap |
| Programming | AtmoCONTROL software on a USB stick for programming, managing, and transferring programs via Ethernet interface or USB port |
| Temperature Control | Independently working, digitally adjustable electronic microprocessor overtemperature monitor TWW, protection class 3.1 |
| Temperature Control (TB) | Mechanical temperature limiter TB, protection class 1 according to DIN 12880, switches off heating 20°C above nominal temperature |
| AutoSAFETY | Integrated over- and undertemperature protection "ASF", heating switched off in case of overtemperature |
| Autodiagnostic System | For fault analysis |
| Alarm | Visual and acoustic |
| Door | Fully insulated stainless steel doors on two sides |
| Interior | Easy-to-clean stainless steel, reinforced by deep drawn ribbing with integrated and protected large-area heating on four sides |
| Max. Number of Shelves | 8 |
| Max. Loading Per Shelf | 44 lbs |
| Max. Loading of Chamber | 462 lbs |
| Internal Dimensions (W x H x D) | 22" x 28.3" x 15.7" (56 x 72 x 40 cm) |
| External Dimensions (W x H x D) | 29.3" x 48.5" x 22.9" (74.4 x 123.19 x 58.2 cm) |
| Net Weight | Approx. 265 lbs |
| Electrical Load | 115 V, 50/60 Hz, approx. 1800 W |
