IKA RC 5 basic Recirculating Chiller, basic
Working Temp.
-30°C to Room Temp.
Pump Pressure Max.
0.61 bar
Flow Rate Max.
31 l/min
Features
- Speed-controlled refrigeration system with 1400 W cooling capacity (@20°C)
- Natural thermofluid R290
- Designed for cooling applications up to -30°C - RT
- Extended operating temperature range until 80°C
- Excellent temperature stability of about ± 0,1K (@-10°C)
- Speed-controlled pump made of PEEK: (0,6 bar; 31l/min)
- Digital level indicator
This energy-efficient chiller is operated with an eco-friendly refrigerant and reaches a high power density. This results in a comparatively small working space in the lab.
The speed-controlled PEEK pump allows an indirect, continuous adjustment of the maximum pressure and flow rate. Due to its excellent temperature stability of about ± 0,1 K, the RC 5 can handle even sophisticated applications. The isolated, high-quality 7l bath has an integrated hopper and drain valve, ensuring a safe and clean handling of the thermofluid. A hose can be connected to empty the bath in order to avoid direct contact with the thermofluid. The easy-to-open front flap allows an easy cleaning of the cooling unit’s air filter.INCLUDED:
The IKA RC 5 basic Recirculating Chiller, basic includes:
- Hose olive NW 8 (2 pcs.)
- Hose olive NW 12 (2 pcs.)
- USB Cable - USB A to Micro-B, 2 m
- Power Cord
- Manufacturer's Documentation
- 2 Year Manufacturer's Warranty
Appliance type | Recirculating chiller |
Cooling agent | R290 |
Cooling agent quantity | 90 g |
Cooling agent pressure max. | 21 bar |
Cooling capacity (@20°C) | 1400 W |
Cooling capacity (@10°C) | 1200 W |
Cooling capacity (@0°C) | 950 W |
Cooling capacity (@-10°C) | 650 W |
Cooling capacity (@-20°C) | 450 W |
Cooling capacity (@-30°C) | 200 W |
Working temperature | -30°C to Room Temp. |
Operating temperature min. | -30 °C |
Operating temperature max. (with external heating) | 80 °C |
Temperature display | yes |
Temperature control | PID |
Working temperature sensor | PT 100 |
Working temperature display | LED |
Temperature stability DIN 12876 | ±0.2 K |
Display resolution | 0.1 K |
Warning function optical | yes |
Warning function acoustic | yes |
Warning function excess temperature | yes |
Sub-level protection | yes |
Filling volume | 5.0 - 7.0 l |
Pump type | Pressure- / suction pump |
Pump capacity adjustable | yes |
Pump pressure max. (0 liters discharge flow) | 0.61 bar |
Pressure pump (suction side) (0 liter flow) | 0.45 bar |
Flow rate max. (0 bar back pressure) | 31 l/min |
Pump connection | M16x1 |
Calibration option | yes |
Technical data complies with the standard | DIN 12876 |
Permissible ON time | 100 % |
Noise level | 61 dB(A) |
Dimensions (W x H x D) | 310 x 546 x 490 mm |
Weight | 37.5 kg |
Permissible ambient temperature | 5 - 32 °C |
Permissible relative humidity | 80 % |
Protection class according to DIN EN 60529 | IP 21 |
RS 232 interface | yes |
USB interface | yes |
Voltage | 100 - 115 V |
Frequency | 50/60 Hz |
Power input | 1100 W |
